Ingersoll-rand Centrifugal Compressor Spare Parts

 PART NO.Part Name
167742213The big gear shaft
247675718001Cooler core
347675717001Cooler core
424575300The vent valve
517959125Gasket kit for 12SP895 5
617959124Gasket kit for 12SP896 5
794900644Transition tube 4CI S2
894695194IRIPNEUMATIC ACTUATOR
970422803ASSEMBLY PACKING CASE WI
1070415922ASSEMBLY CUP 5
1170415914ASSEMBLY CUP 3
1242459735ASSEMBLY PACKING CASE PH
1368235944Three stage diffuser
1467585125PINION-3CII 50HZ 3RD 8X1
1524276057dry type coupling
1622686570Second stage diffuser
1717959126Gasket kit for 12SP894 5
1817043381The main coupling
1923729304Y type sealed cooler copper core
2023724552Y type sealed cooler copper core
2123466865element filter
2223448145element set E9300lG
2323448038ELEMENT KIT FOR 23447527
24KIT-SEAL-350The seals
25KIT-SEAL-200Fan seal
26KIT-BRG-350bearing
27KIT-BRG-200-FANbearing
2896749759M6 * 35 bolt
2996740345M8 * 45 bolt
3067830786Sliding bearing
3147674713001Hangzhou Risheng 105RJ006LRD22C 1
3247673932001Omron intermediate relay
3347672545001XE control upgrade package 5_DEMAKE
3447672544001XE control upgrade package 4_JOY
3547672543001XE control upgrade package 3_4CI_M0
3647672542001XE Control upgrade package 2_C3000_
3747672541001XE Control Upgrade package 1_5CII 5
3847665512001Spare parts, main oil pump seal assembly
3947620661001Oil cooling
4022086110Water gas separator C3000 S2
4196704945Bolt M16X70
4268158518PROBE-PROXIMITY B/N 1X36
4368017151CABLE-EXTENSION B/N 1X30
4467582072Gas seal casing
4547672550001Electrical control box specifications _ Upgrade DEMAKE
4647672549001Electrical control box specifications _ Upgrade JOY
4747672548001Electrical control box specifications _ Upgrade 4CI_M0010
4847672547001Electrical control box specifications _ Upgrade C3000_V82
4947672546001Electrical control box specifications _ Upgrade 5CII5CIIB
5047671968001C950 Control cabinet upgrade kit
5147671967001C700 Control cabinet upgrade kit
5239918362Intake valve
5324493405Intake valve
5422973911Temperature control valve
5522886618Second stage diffuser
5622769426PUMP AUXILIARY OIL
5747674429001[P] IR SS-16 fumigated wood
5847673927001TECO motor parts
5947673926001TECO motor parts
6047673925001TECO motor parts
6147673924001TECO motor parts
6247673923001TECO motor parts
6347588575001Brey 12″ inlet control valve
6468137447Oil pressure gauge
6567934026HEADMACH 2AHPS2-50HZ
6667933804HEADMACH 2AHPS1-50HZ
6747673841001Motor bearing
6847651305001Spare parts for TECO motors
6947653643002oil filter element
7024621443Inlet valve 20″ ANSI 150 HART
7122813000Diffuser S3
7224621450Bypass valve 8″ ANSI-DIN 150
7323512023C1000 impeller 100%
742409325450Hz two and three rotors
75F1818200868the bare shaft roots blo
7668013838HEADMACH 2AHPS3-60HZ
7767971697COUPLING-DRV-HUB 3X3988
7867614115COUPLING-DRV-SPACER.5X17
7967567677Half coupling
8067559856COUPLING – DRV – MOTOR H
8194578119Gasket ANSI 8 “300 lb
8247671864001Electric cabinet C950
8347671862001Electric cabinet C700
8415657232Gear coupling DIST=600
8543137314Maxi Gasket kit S1-S4
8647671477001Pressure gauge positioner
8768209394Oil temperature switch
8823632631Guide plate C1000
8922555692Rotor 5CIIB class C
90E47643636001-N5 ciibs3 cooler
91E47643635001-N5 ciibs2 cooler
92E47643634001-N5 ciibs1 cooler
93E24816332-NCooler C400 – S2
94E24816324-NCooler C400 – S1
95E24776122-NCooler 3 SEC – S3
96E24776114-NCooler 3 SEC – S2
97E24776106-NCooler 3 SEC – S1
98E24776098-NCooler C980 – S1
99E24776080-N2 acii cooler/C950 – S3
100E24776072-N2 acii cooler/C950 – S2
101E24776064-N2 acii cooler/C950 – S1
102E24688376-NCooler CV2 C700 – S3
103E24688368-NCooler CV2 – C700 – S2
104E24688350-NCooler CV2 C700 – S1
105E24578320-NCooler 5 SEC – S2
106E24578312-NCooler 5 SEC – S1
107E24144842-NCooler 3 cis1 – S4
108E24144800-N4 cis1 cooler – S4
109E24016123-NCooler C250 – S3
110E24012726-NC250S2 / C350S3 cooler
111E24011009-NC250S1 / C350S2 cooler
112E23948482-NCooler C3000 – S3
113E23948474-NCooler C3000 – S2
114E23948466-NCooler C3000 – S1
115E22459937-NCooler CV1 – S2
116E22444301-NCooler CV1 – S1
11739590468The flow valve
11868080225VANE-PLATE 7X14376
11942603803ROTOR 2A-HP S1 325 PSIG
12023577737To take over
12123557416To take over
122VIBR-BSB-125-60Damping piece
123CKV-D-5118-16Check valve
12467649640INSERT-BRG, TPJ 5CII S1
12539590286valve
12624072845Diffuser 5CII STG C
12723217375Thrust bearing
12823217342Thrust bearing
12923217318Thrust bearing
13022947790Diffuser 5CIIB STG B
131293365ROTOR,5CII S2 50HZ 65MM
13267626044Thermometer oil circuit 02
13323626427Vibration detector 70MM
13447588574001Brey 10″ inlet control valve
135AAP1405555-00801Sealing strip
136680431573 ci guide plate
13747669715001Xiangtan 1000kW 10KV motor
13847669714001Inlet electric butterfly valve DN500
13947669713001By-pass electric butterfly valve DN200
14047669712001Outlet check valve DN400
14147669711001Gear box lubrication and cooling system
14243077072joint
14324598328Sheet metal parts for housing
14415655343screw
145CPG-1080-T20Coupling complete
146A050910200Air filter C2001 /Greata
14795447496Elbow 90
14895056032sloper
14978-04-00-000-H-Fbearing block
15075-15-07-000-A-Fshaft
15170471537GASKET VALVE SEAT, 14.5 9
15270471529GASKET VALVE SEAT 24X9 P
15370467881RING WEARING 9 X 9 PS4
15470467840RING PISTON 9 X 9 PS4
15568231745SEAL-AIR,CV5 BOOSTER
15650-15-07-000-C-Fmain shaft
15747667853001Electric cabinet
15825-17-00-000-0-FDEEP GROOVE SINGLE ROW B
15924504086IMPELLER CUT C950 S3 TA
16024504078IMPELLER CUT C950 S1 TA
16123880040Pipe to tee D.12
16223879263Joint angles
16323878945Pipe joint 1/4 “NPTXD. 12
16422521108IMPELLER, CUT C950 STG2
16517269887FILTER AIR INTAKE 12 X 1
16647668750001Motor bearing, Drive end, 3CI
16722834741Impeller C700 S2
16843083260DIFF.PRESSURE SWITCH 0-5
16947668749001Bearing, motor, non-drive end, 3CI
17024614711The motor bracket
17167956714KIT-CV1A/REV TH BRGS1 C1
17247668382001Rear cooler (GKL-1006)
17343005552DIFFUSER, FM CV1A/
17442570762ROTOR, S/A CV1A S2 50HZ
17523652340C1000 nose seal kit
17617958909MAINTENANCE KIT FOR DRY
17717958908MAINTENANCE KIT FOR DRY
178476668300013ACII Control upgrade kit
179476661740012K hour maintenance kit C700
180476661730012K hour maintenance kit C950
181476661720014K Hour maintenance Kit C700
182476661710014K hour maintenance kit C950
183476661700014K Hour maintenance kit C950NA
184476661690018K hour maintenance kit C700NA
185476661680018K hour maintenance kit C700
186476661670018K hour maintenance kit C950NA
187476661660018K hour maintenance kit C950NA
188476661650018K hour maintenance kit C950
18922676795diffuser
190R014092100Kit 2 Bagues porte segme
19180281090Diffuser assembly C3000 Stage 3
19268200732Diffuser stage 3
19368181239Intake valve assembly
19431174667Secondary intake valve seat repair kit: 39
19530550628The seat cushion
19630336317bolt
19724160277C1000 rotor
1982351421950Hz first stage rotor
19922362529The main oil pump
20022228522Diffuser assembly C3000 Class 1
20122227912The transition pipe
20223959281Cooler AIR CV1 S1 STD S
20395774550Internal connector.12″ X6.0″
20424577314Temperature sensor gas
20524606642Temperature sensor oil
20622628408Pre-lubricating oil pump
20747664829001BEARING TIMKEN TS
20847664828001BEARING TPR.RLR. #JH2117
20947664827001GASKET BRG RET-S6 RDCR H
21047664825001RETAINER BEARING HS MH60
21147664543001C1000 Field service Kit
21267912337Impeller S3
21349110117Refrigeration compressor RC2-100B-W-T
21468052505Diffuser cover plate
21522017719Contactor contacts
21647664919001Non standard self cleaning filter IR SS-56
21747592286001C1000 overhaul kit
21842973438CV1A/B cooler seal kit S2
21947651327001Spare parts for TECO motors
22068080217Diffuser body S4
22124160475Two and three rotor assemblies
22224050379Option intake assembly stage 2
22324050361Option intake assembly level 1
22494938255Gasket ANSI 16 “150 lb
22594893252Gasket ANSI 14 “150 lb
22694812815[P140] 5CII secondary nose
22749180862Big gear shaft key
22823463029The big gear key
22923279870Large gear C1000 50Hz STD
23047663991001Plate
23147663990001Tuthill Pump
23247663989001Screw
23347663988001Gasket
23447663987001Screw
23547633063001Metal wound gasket 106DP210 D35
23622738868PROBE- VIBRATION
23722368138COOLER- STG 3 AIR EXTERN
238CKV-D-5118-10Discharge Check Valve
23943142330coupling
24023449838Grade five rear bearing
24122811772Thrust bearing 5CII S3
24219047604600HP star triangle starter cabinet
24394727039Gear coupling 450
24443078211The check valve
24542973990GASKET KIT 3CII 3ST
246429739743ACII cooler seal kit
24742973958GASKET KIT 3CII 1ST
24823811896Level 3 rotor
24923811888The secondary rotor
25023811870Level of the rotor
25123598634The vent valve
25223529282Dc power supply
25323427024Diffuser 5CII stage 3
25423189806Diffuser 5CII stage 2
25543192236Complete seal
25623495583The auxiliary oil pump
25723459506The main oil pump
25822492532Impeller S1
25947663347001Ac contactor 105JCQ127
26047663346001Heating protector 502WDBHQ001
26147663345001Thermal relay 105RJ026
26247662849001TA6000 paired with flange batch, American standard
26347650970001Vetli card hoop 10″
26447650969001Vetley clamp 6″
26568118108First stage diffuser 7×14679
26667889535o-rings
26743196351C950 Cooler seal kit S3
26824607731Exhaust expansion joint 12 “150#
26922738769Vibration probe
27024647463Bypass expansion joint 8 “150#
27124607723Exhaust expansion joint 12 “150#
27224604829Intake expansion joint 24″ 150#
27322605265Second stage nose
27422605257First stage nose
27524287013Oil plug
276KIT-BRG-575-FANBearing Kit
27747589895001SEAL CARTRIDGE ASS’Y AIR
27847589395001SEAL CARTRIDGE ASS’Y AIR
27942916098C1000 to install a
28042586388rotor s1
28142996280Four stage diffuser
28242920959Diffuser 4CI S4
28322531941Three-stage rotor assembly
28468192236Three stage diffuser vortex ring
285KIT-SEAL-450SEALING KIT FOR SERIES 4
286KIT-BRG-450-FANBEARING KIT FOR SERIES 4
287CPG-TSC0135DIRECT FLEX COUPLING JOH
28849194129Exhaust valve
28922821987Diffuser C700 S2 79%
29067512517Gear ring for diffuser
29147625569001Unloading solenoid valve
29267510602Diffuser intake ring
29347660147001Rear cooler,3CI
29423520927Bushing inlet valve
29595446647Pipe joint
29648861066Elbow, 1.25 FNPTX1.25 “FNPT
29748861058joint
29848861041joint
29948860985The tube motor is lubricated and produces oil
30048860977Tube motor lubrication oil intake
30142973396CV1 cooler seal kit S2
30242973370CV1 cooler seal kit S1
30339590435The vent valve
30424321028Rubber gasket
30524321010Rubber gasket
30647590764001PLAIN BEARING N2 ASSEMBL
30747590598001SEAL CARTRIDGE ASS’Y AIR
30822815450Second stage rotor assembly
30922795132First stage rotor assembly
31019031269The temperature control switch
311RSPINIONGear shaft coating repair
312RGPINIONGear shaft vibration zone grinding
31395987491Pipe joint
31495079778bolt
3159478160618 “gasket ANSI 150 lb
31685655355KIT-OVERHAUL-CV1B
31768164417Intake control valve
31868109156Auxiliary oil pump motor
31967979691Expansion joint 8″
32067904409Right Angle connector
32167693820Muffler 6 * 10
32267652321First stage diffuser
32367500140nozzle
32449002462Electric oil mist assembly kit
32547658418001Spare parts electrical control box internal material C3000
32647625184001Bray locator mounting accessories
32747625183001Bray locator Iy module
32847625182001Bray valve positioner 6A
32947621982001Electric oil mist separator
33047595612001[140] Oil cooler
33147572126001Rear pipe filter
332245783125CII first stage cooler
33324263980Pressure transducer
33424050478Deflector stage 2 100%
33524050437Diffuser stage 3 100%
33624050411Diffuser stage 2 100%
33724050395Diffuser class 1 100%
33823992233The center pipe
33923857022ELETTROPRELUBE PUMP
3402365821450Hz first stage rotor
34123633340Guide plate C1000
34223632987Guide plate C1000
34323600901First stage guide plate
34423045107Rotor C700 S3 125#
34523027048Diffuser 5CIIPI stage 1
34622978837COOLER, OIL S.S.SHELL
34722915029First stage diffuser
34822900294Rotor assembly S2
34922798615Rotor C700 S3 50HZ
35022797575Rotor C700 S2 50HZ
35122796338Rotor C700 S1 50HZ
35222676738Diffuser C950S1
35322668289Diffuser C700 S1 69%
35422664411Diffuser C700 S1 63%
35522656821Diffuser C700 S2 63%
35622530794ROTOR 5CIIPI 1ST STG
35722509277Impeller S3
35822027098Clamp 10″
35922019996Thrust bearing 5CII S2
36022019939Thrust bearing 5CII S1
361386987ROTOR – CH6 2 SEC 50 hz S1.1
362379198Wiring duct 40 ft
36347658420001Spare parts joint material C3000 Au Light
36447658419001Spare parts are now equipped with pipe material C3000 AU
36547569273001The motor 3 ciidf
36642973412CV1A/B cooler seal kit S1
36723857055Auxiliary oil pump 10576SP
36847590056Two-stage front bearing
36947579737First stage front bearing
37022772677Bypass valve 8″ ANSI-DIN 150
371KIT-BRG-100-FANSeal kit
37224050494Deflector stage 3 100%
37324050452Deflector stage 1 100%
37423060122DOUBLE TEMP ELEMENT
37523060056Pressure sensor 0-10 bar
37623060049Pressure sensor 0-5 barg
37785709137actuator
37867502013Diffuser 3C S2
379KIT-ORINGS-675O-RINGS KIT FOR SERIES 6
380KIT-BRG-675-FANBEARING KIT FOR SERIES 6
38190-16-40-000-B-FCAST IMPELLER (40DEG VAN
38290-12-ZA-GAS-E-FCAST LABYRINTH SEAL WITH
38390-08-ZA-CST-C-FCAST LABYRINTH FOR BEARI
38422798243Rotor assembly S3C700
38522796957Rotor assembly S2C700
38622795595Rotor assembly S1C700
38723449002Adjustable gap gasket group
38868221894IMPELLER-MAX 3AS1 J110 M
38968001197Coupling 1 x21256
39022746028Bypass valve 8″ ANSI-DIN 150
39147655518001Risheng drying machine after cold replacement of stainless steel
392429740555CII cooler seal kit S3
393429740305CII cooler seal kit S2
394429740145CII cooler seal kit S1
39595041588o-rings
39694805603Coupling 5 SEC
39768230671The secondary rotor
39868187194Medium and small centrifugal 3C stage 5 rotor
39968117845Bypass valve
40047655517001Heater inner bladder 106JRQD178
40142522714Level 3 rotor
40242522698Level of the rotor
40343030808Intake valve 24″
40467500637hose
40567500629The hose clamp
40637980976Intake valve
40723542335Level of the rotor
40823401870The secondary rotor
409222312375CII three stage rotor assembly
41068110782DRIVER, PUMP MOTOR
41168092568PUMP-OIL,WITHOUT DRIVER
41267888453Inlet and outlet pipe assembly
41347655008001Thermal relay
414F015150100NX8 Roots blower head
415F014170100NX5 Roots blower head
41667816231Radial bearing
417248731846 inlet air filter
41822011662Dry coupling
41943105139Bypass valve 4″ hot drain
42023700487Bypass valve
42123614910Two stage diversion plate
42218998450Gate window NEMA12
42322910038diffuser
42447552259001Bray 3″ bypass control valve
42547552257001Bray 8″ inlet control valve
42622934038Rotor C700 S3 50HZ
42722897938Plain bearing S2 3CIIB
42822896542Sliding bearing
42967688374HEAD MACHINING (STG 2)
43047651369001Spare parts for TECO motors
43147651366001Spare parts for TECO motors
43247651360001Spare parts for TECO motors
43347651355001Spare parts for TECO motors
43447651354001Spare parts for TECO motors
43547651352001Spare parts for TECO motors
43647651350001Spare parts for TECO motors
43747651349001Spare parts for TECO motors
43847651348001Spare parts for TECO motors
43947651346001Spare parts for TECO motors
44047651344001Spare parts for TECO motors
44147651343001Spare parts for TECO motors
44247651342001Spare parts for TECO motors
44347651341001Spare parts for TECO motors
44447651340001Spare parts for TECO motors
44547651339001Spare parts for TECO motors
44647651338001Spare parts for TECO motors
44747651335001Spare parts for TECO motors
44847651332001Spare parts for TECO motors
44947651331001Spare parts for TECO motors
45047651326001Spare parts for TECO motors
45147651323001Spare parts for TECO motors
45247651322001Spare parts for TECO motors
45347651319001Spare parts for TECO motors
45447651318001Spare parts for TECO motors
45547651316001Spare parts for TECO motors
45647651311001Spare parts for TECO motors
45747651308001Spare parts for TECO motors
45847651307001Spare parts for TECO motors
45923930761The motor
46024600231Vibration probe
46167927244Actuator diaphragm
46267886721The main oil pump
46323530371Intake filter
46422378244Main oil pump coupling 3CIIB
46595992269screw
46649023864Temperature transmitter
46747653404001Cover plate 1.008.228
46824279655The temperature probe
46923601230Three stage diversion plate
47050-16-74-000-A-FCAST IMPELLER SHORT HUB
47147621848001Integrated vibration (velocity) transmitter
472429732973CI cooler seal kit
47328-85-00-000-0-FO’RING COIL 1/16 OD DIA.
47423137193Pressure gauge
47547653328001Fan host oil storage assembly :KIT-
47648999908Screw pump 370
47724784324VALVE ACTUATOR BRAY S93
47822398390coupling
47915641327Diffuser 5CIIB STG C expansion
48095511358pin
48195033619The plug
48267711358screw
48367596965Replaced by 96703962
48447652927001TECO motor 725HP-10kV SF1.1
48547652926001TECO motor AEJE HP – 725-6 p
486SEAL-99215SPEEDY SLEEVE # 99215
48785709129actuator
488AAP1401581-01547The check valve
489AAP3403893-00429Vibration sensor
49047651709001Unit cooler 205HLQ001 (carbon
491AAP0540089-00111TRANSDUCER.PRESSURE
492AAMB409950-13848Main engine maintenance kit
493AAMB409810-00600Heat exchanger sealing gasket STAGE=1 2&
49447553672001BRAY CONTROL VALVE FILTE
49543005537GASKET KIT CH5
49624804171IV 8′”‘ ANSI300#
49724783562BYPASS VALVES ANSI 300#
49823104987MATING FLANGES CV 1450SP
49922320261Coupling C3000 450MM
50068208040First stage diffuser
50124783771Large centrifugal temperature probe
50224716269Instrument gas filter
50394814407Level 3 impeller
504491462443 SEC by-pass valve
505491462363 SEC intake valve
50623548837Diffuser C3000 class 2
507IS-THER-RTD100-01RTD PLATINE 100 OHMS 3 W
50822969752Oil temperature control valve
50922910178Stainless steel diffuser
51024034332Circuit breaker 3P 9A
51123512031C1000 impeller 100%
51294800067Three-stage rotor assembly
51347650186001Cooler core stainless steel 205HL079
51424776098Cooler SS C980S1
515PAD-70151Cushion 16 moq size is different
51668155134Vibration probe 1X36389
51767829580C950 three stage rotor shaft
5184764643900110 “seal ring Victoria card hoop
5194764643800112 “Seal ring Victoria card hoop
5204764643700114 “seal ring Victoria card hoop
52124054017Temperature transmitter
52224019200Oil pressure switch
523P168200400HEAD PLATE + PLUGS NX/VT
524P165222104DEFLECTEUR SA NX EA 173
525P165212104DEFLECTEUR TOLE BPS NX E
526P148502042GEARS – SET OF GEARS FOR
527C170607007ASS.EXPANSIBLE TLK 300 D
528C120722501JOINT TORIQUE DIA.72 X 2
529C027007008SEAL PACKING 070X090X10
530C021010005RONDELLE DE RETENUE DIA.
53196702857nut
53295685897CAPSCREW,HEX SOC 1/4SS
53395587937INDICATOR SIGHT FLOW of 1.5
53495320446Steel ball
53595200945LOCKNUT N13 O.D 3.38mth
5369505185012 “gasket
53795018370O-RING 14 X 14-1/2 X 1/4
53894938073gasket
53994938065gasket
54094900768Transition tube 4CI S4
54194587912tube
54294415676CYLINDER 7″ DIA
54370459599RING PISTON 7X9 PHE-9 NL
54470422399RING WEAR – 4.5
54570422381RING PISTON X9 4.5 CFT is
54668113190DIFF-FM,CH6 2CII VANED,D
54767739193Gasket ANSI 14″ 150#
54867651216Radial bearing
54967618553casing
55067506253The DIFF – GE – 3 c S1.3201 E6-2
55154635693VALVE,THERMOSTATIC
55249233182The piston rod
55349025943SURGE VOLTAGE SUPRESSOR
55447617508001COUPLING TLKS-0500-X088-
55547606393001GASKET KIT CH5XB
55647595905001OIL PRESSURE GAUGE FOR G
55747002258KIT DE MAINTENANCE STD N
55839590237VALVE DISCHARGE
55939488713VALVE-THERMOSTATIC
56039486204GASKET FR/OUTER HEAD PHE
56139329313VALVE DISCHARGE
56239316898RING,PACKING
56339169925Conveyor belt of vulcanized rubber
56437982873VALVE SUCTION W/UNLOADER
56537982196SEAT DISCHARGE
56637980422The seat components
56737980414SEAT SUCTION
56837944550PLATE VALVE
56937897998PLATE VALVE
57037794377SEAL OIL CRANK SHAFT
57134578799NUT PISTON
57234004960PLATE DAMPING
57333426917SPRING CLOSING
57433426412SPRING CLOSING
57530589568WASHER LOCK STAR 7 STK
57630565675NUT JAM 7 INCH STROKE
57730562094GASKET
57830508741SPRING VALVE RELIEF
57930427140The oil pump
58030253892COVER SHAFT
58128-88-00-000-0-FFUSED WINDOW SIGHT 3/4-N
58228-67-00-000-C-FAXIAL FAN PM MOTOR CO. #
58324648214Intake valve
5842408379224 “flange ANSI150
58524016123COOLER,AIR INT C250-S3
58624012726COOLER, AIR C250 S2 C35
58724011058COOLER, AIR 4C150 STD
58823833395Bearing fastener
58923823123Expansion section 12″ 150#
59023743842DIFFUSER HALF GEAR END 4
59123652639C1000 Shaft seal kit S2 S3
59223652159C1000 Plain bearing kit S3
59323652134C1000 Plain bearing kit S2
59422677785Vibration probe
59522571889OIL FILTER CARTRIDGE
59622372411Transition tube C3000 S3
59722027148Bypass expansion joint 8 “150#
59819012459Circuit breaker 2P 6A
59919012442Circuit breaker 1P 4A
60017958534POSITIONER FOR 19SP1431
60117958533POSITIONER FOR 19SP1430
60217934256Bolts & nuts for coupling
60317277278TRANSFORMER STEP-DOWN CS
60424144842Air cooler 3CI
60524017774Three stage cooler 5CII
60623754336Pressure sensor HART
60790127465Anchor bolt
60824776080Cooler SS C950S3
60924577439Temperature control valve SS304
61023530389Large centrifugal filter element
6112475913619SP2918 BV 4″ ANSI150
61247630554001Oil cooling end plate
61322404313The rotor level 5
614P158502042NX12 Roots blower standard repair kit
61596767009bolt
61696764485Bolt M5X16
61796764469pin
61896764451pin
61996762174bolt
62096761846screw
62196760418Bolt M10X50
62296760251The elastic pin
62396760244pin
62496756556tee
62596756366Right Angle connector
62696743802Flat mat
62796742507bolt
62896741244bolt
62996741210Bolt socket hexagon M10 X 85
63096740865Nut M8
63196740659Bolt M8 X1.25 X40
63296725130Bolt M16x60 LONG
63396717616bolt
63496713367bolt
63595999678bolt
63695991493Pipe joint 2.0″
63795990743Bolt. 38 x. 75″
63895990727bolt
63995990370bolt
64095567319GASKET VALVE SEAT
64195253852The pipe clip
64295210365PACKING,R&S
64395051827gasket
64495030276o-rings
64595023461o-rings
64694943743Non-standard muffler
64794938198gasket
64894938081gasket
64994938057Gasket ANSI 1/2 “150 lb
65094938032Gasket ANSI 1-1/2 “150 lb
65194815099Hexagon socket set screw M10x15-1
65294813573Bearing cover S3
65394812153GASKET 12IN
654947941532 SEC rotor
65594427697ROD PISTON 17 X 9 HSE
65690169715screw
65790148594GASKET KIT 4CI S5
65890125840The nozzle
65985647881SEAL,PUMP SHAFT
66085640472Non-drive end bearing 902-60
66170477005RING-WEARING 4 X 5 ESV
66270476999RING-PISTON 4 X 5 ESV NL
66370459623RING-WEAR
66470459615RING,PISTON
66570459607RING-WEAR
66670452958Double piston rod PHE-7
66770430889RING- WEAR 9
66870430871RING- PISTON
66970430855RING- PISTON 17′”‘
67070334636ASSEMBLY ROD PISTON 7 &4
67170268602Level of China
67270268594First stage crosshead
67368249267IGV body
67468241256bolt
67568232057Diffuser c950 S3
67668225580Diffuser c950 S2
67768215003The MOP ring C3000
67868212752Diffuser C950 S1
67968202985Impeller screw, Grade 1
68068192186Gas water separator CV2 STG3
68168179688Thrust bearing
68268090489Coupling protection cover
68367980524joint
68467970467coupling
68567946665Pinion shaft 4C150 stage
68667904649Big gear 5CII 50HZ LP
68767867549ROTOR-2ACII 2ND 50HZ.7X1
68867844571IMPELLER-MAX CV2-33 S3 5
68967782755Main oil pump support
69067778241Pin 6 mm X 20 mm
69167763508Tee connection pipe
69267739201The gasket
69367728147Clamp connector 10″
69467631192VALVE-CHECK LIQUID 1X489
69567590430Seal cover big gear 5CII
69667582353Coupling protection cover
69767581066Big gear shaft key
69867573196Impeller level 4CI
69967513747RING-INT-DIFFUSER INTAKE
70054577440RING-WEAR-4′”‘
70154503115RING SCRAPPER 2.0 INCH R
70254416417The filter
70354370697First stage intake valve gasket repair kit: 38
70454370663GASKET VALVE SEAT A28
70554365648Secondary intake valve gasket repair kit: 38
70654364104TRANSDUCER,HP, 0-500PSIG
70749199805Diffuser option first stage
70849199714Diffuser first stage
70949196561The tubing
71049196553The tubing
71149159056Leakage switch
71249137805CMC Control System
71349133259Gear box of 50 hz
71449002819Vibration of cable
71549002801Vibration probe
71649002553Oil level sensor
71749002546Temperature sensor 0-500F
71849002538Differential pressure sensor 0-30psi
71949002520Pressure sensor 0-200psi
72049002512Pressure sensor 0-50psi
72149000912The rotor
72247634202001tube
72347631066001Bearing spare parts
72447618579001ASC components
72547614084001Bearing, motor
72647614083001Bearing, motor
72747612305001Risheng desiccant 104XFJ201
72847612304001Air source filter core 180LX1379
72947608760001Y-100 thermometer minus 30 to 140
73047606353pressure transducer
73147597908001OIL COOLER E7094295
73247597747001Rubber ring
73347597746001Rubber ring
73447595904001OIL PUMP FOR GEARBOX MH6
73547595903001OIL SLINGER FOR GEARBOX
73647595611001Oil cooler
73747593938001LOW SPEED GEAR SET MH600
73847593937001HIGH SPEED GEAR SET MH60
73947593267001Low speed drive end bearing
74047593266001High speed non-drive end bearing
74147583238001Cooler copper tube copper fin S1 C100
74247578493001Pipe line
74347578492001Pipe line
74447578491001P[140] Lubricating oil pipeline
74547578490001hose
74647570258001Heater C950
74747566369001Temperature control valve
74847554375001COUPLING-JOHN CRANE TSC-
74947550835001LIP SEAL LUFKIN E9020300
75047549227001Motor C700 {P140}
75146865655Oil inlet hose 1/2″
75246848057Joint M27
75343190503GASKET KIT 2CIIPI S3 N2
75443176874COUPLING 3.500.935-1
75543167873DISCH.VALVE 4′”‘ 2576 DI
75643099134bolt
75743095017The steam trap
75843078658CONDENSATE TRAP BEKOMAT
75943051135Check valve 14″ ANSI 150 H
76042973859GASKET KIT 2ACII 2ND STG
76142973834GASKET KIT 2ACII 1ST STG
76242973495GASKET KIT CV2 3RD STG
76342973479GASKET KIT CV2 2ND STG
76442973453GASKET KIT CV2 1ST STG
76542641183Second stage diffuser option
76642611160Small centrifugal C950 third stage rotor group
76742608836Second stage rotor assembly
76842589861Two stage diffuser option
76942589218ROTOR, 3CIIB SC 50HZ TA
77042587071ROTOR, 3API S3 50HZ 2AS
77142437921Piston rod assembly
77239914791VALVE INLET WITH U/L
77339656202UNLOADER INSIDE OPERATED
77439592688VALVE DISCHARGE HCA 55-3
77539592324VALVE DISCHARGE 7 X 7 PH
77639590278VALVULA DE DESCARGA EXCL
77739550199GASKET FRAME HEAD PHE
77839550090GASKET OUTER HEAD PHE
77939487038COOLER-370PSI
78039331368VALVE,SAFETY-90 PSI
78139323332PACKING,R&S
78239322334RING,PISTON
78339322318RING,WEAR
78439321690RING-PISTON-7′”‘
78539321245RING PACKING,R&S
78639249339SET MATCHED BANDED BLTS,
78739169933Vulcanized rubber transmission belt
78838326898Primary air valve limiter
78937995529Secondary intake valve spool repair kit: 39
79037986635ASSEMBLY UNLOADER
79137982907VALVE SUCTION
79237982287PLATE SPRING
79337982279PLATE VALVE
79437982121O-RING
79537982113SPRING
79637981933RING CRUSH
79737980612GASKET
79837980588SEAL
79937980570O-RING
80037980554SPRING
80137163755First stage exhaust valve
80237038064GASKET VALVE COVER
80333426024SPRING CLOSING
80433013889NUT LOCK
80530678452VALVE INLET COMP A28CS1E
80630586127GASKET PACKING CASE
80730551253VALVE DISCHARGE A28CS2EW
80830550842GASKET VLV COVER CU SHRO
80930550636GASKET VALVE COVER 20X11
81030549885GASKET VALVE SEAT
81130336887GASKET PACKING CASE PROC
81228-96-00-000-A-FISOLATOR SEAL PROTECH #L
81328-35-00-000-0-FHOSE BARB 90 DEG. ELBOW
81428-32-00-000-A-FCONSTANT LEVEL OILER 5
81525-37-00-000-0-FO’RING #2-161 (VITON)
81625-26-00-000-0-FBEARING LOCK WASHER W13
81725-25-00-000-0-FBEARING LOCKNUT N13
81825-12-00-000-0-FCARBON RING SERIES-25
81925-04-00-000-E-FBEARING HOUSING SERIES-2
82024877417contactor
82124864084Air filter shell
82224816332Cooler (SS TUBE) S2
82324816324Cooler (SS TUBE) S1
82424787186Stainless steel center tube S2
82524784423VALVE ACTUATOR BRAY S93
82624784407VALVE ACTUATOR BRAY S93
82724776122Cooler SS 3CIIS3
82824776106Cooler SS 3CIIS1
82924776064Cooler SS C950S1
8302477151112 “intake valve
83124764714Bypass valve 8″
83224721359Protective cover coupling 3ACII
83324688376Cooler CV2 STG3
83424688368Cooler CV2 STG2
83524688350Cooler CV2 STG1
836246441893 aciidf big gear
83724524811Electric cabinet
83824518763PRESSURE TRANSMITTER 0-7
83924518755Pressure transducer
84024492712Over 2 “NPT
84124474413Large centrifugal bearing
842244720295CII three stage diffuser
84324314510HSG-PUMP, C950 OIL 50 HZ
84424279648temperature transmitter
84524267429Bearing RTD
84624263972Pressure transducer
84724262974DIFFUSER, MACH 3CII S3
84824144800Air cooler 4C150
84924083743Flange 12 “ANSI150
85024083727Flange 8 “ANSI150
85124054009Temperature sensor
85224034571Expansion joint 12″
85324034381Oil cooler
85424028508COOLER, AIR 2ASB S2 STD
85524027773Cooler core group 3S C1000
85624017758First stage cooler 5CII
85723985120DIFFUSER 5CIIPI 3RD STG
85823978711C950 cooler assembly drawing is the same as :2477
85923972383C950 cooler assembly drawing is the same as :2477
86023972276C950 cooler assembly drawing is the same as :2477
86123948482C3000 three stage cooler
86223948474C3000 secondary cooler
86323948466C3000 stage cooler
86423897465DRY MAIN COUPLING
86523878952Pipe joint 1/4 “NPTXD. 6
86623872864KIT, SS N12 3CIIM3
86723872856KIT, SS N12 2ACIIM3
86823872823KIT, SS N12 2ACIIM2
86923804263SUPPRESSOR TRANSIENT SUR
87023790439Differential pressure switch
87123749823Clamp 8 inches
87223688716OIL COOLER
87323652621C1000 Shaft seal Kit S1
87423652118C1000 Plain bearing kit S1
87523626245Vibration detector 280MM
87623577695Coupling bushing 437mm
87723547029Three stage diversion plate
87823547011Two stage diversion plate
87923547003First stage guide plate
88023542970Air cooler copper tube bundle assembly
88123515265Diffuser S3 stainless steel
88223484371Oil mist separator electrically driven
88323458425Impeller 5CIIPI stage 1
88423447113Adjustable gap gasket group
88523440852gasket
88623421795Temperature control valve
88723417140COUPLING
88823170608VALVE- CONTROL BYPASS 2′
88923148364Big gear shaft seal housing
89023123391Rotor assembly S3
89123100654BULL GEAR C950
89223031784Intake valve
89323027089hose
89422970040Rotor C700 S1 50HZ
89522922546Gear coupling
89622847255ROTOR C3000 3RD STG
89722839716Diffuser C700 S3 75%
89822810428FLEXIBLE HOSE
89922724298ROTOR C3000 3RD STG
90022723761ROTOR C3000 1ST STG
90122708622ROTOR C3000 2ND STG
90222678130Diffuser C700 S2 74%
90322677793cable
90422676746diffuser
90522619464Rotor assembly S1
90622613772Rotor assembly 3ACII
90722606719Rotor assembly C3000 class 3
90822605232First stage bushing
90922605224Second stage bushing
91022568653Rotating shaft C3000 class 3
91122557607PINION, MACH 2ASB S1 325
91222557599PINION- 2ASB S3 50HZ 325
91322557573PINION, MACH 2ASB S2 325
91422557532Pinion shaft
91522541247IMPELLER, MAX 3CII S2 J
91622533251Flat mat
91722524946Gasket 3 SEC S1
91822516520Rotating shaft C3000 class 1
91922513543Rotating shaft 5CIIB class A
92022493027Gasket rotor 5CII stage 1
92122471304Pinion shaft 5CII Class 1
92222347256coupling
92322299721DIFFUSER 3RD STG
92422289177Assembling vibration probe
92522238083Impeller C400 S2
92622234769IMPELLER, CUT 2CII S1 1
92722227920Nose C3000 class 3
92822099279Converter bridge
92922027304MINI GASKET KIT C950 S3
93022011316DIFF. PRESSURE TRANSM.
93119068261Oil mist separator shell is high
93219055656Cooler gasket II
933190464163ACII hot connection pipe machine processing
93419045350Control transformer 500VA
93519027820Capacitance 100 u
93619025295Sealed gas pipe 0.5″
93719011568Outlet pipe assembly
93819011501Intake pipe assembly
93918991166Tube Assembly (Oil filter differential pressure meter HP)
94018991158Tube Assembly (Oil filter differential pressure gauge LP)
94117934573Motor bearing
94217934572Motor bearing
94317926286CMC Program Upgrade
94417436833Oil mist separator
94517328378VALVE SAFETY 6010HGM01-K
94617285149VLV SAFETY SET AT 960 PS
94717276841GASKET WATER COVER 6.5c
94816561565Have a screw
949379180Wiring duct 36 ft
95023476518The thrust block
95167979609Exhaust expansion joint
95224776114Cooler SS 3CIIS2
953R015210100NX12 Roots blower standard maintenance
954R015092100NX12 Roots blower standard repair kit
955P155206902VTB810XL Roots blower tee connection
956476482090018″ seal ring Victoria card hoop
95739259254The CONTROLLER INTELLISY control
95822823694Diffuser C700 S3
95922822290Impeller C700 S3
96047646252001Channel 14 # B (140 * 60 * 8)
96122696835Vibration sensor
96240-01-00-DR0-A-FINLET HEAD SERIES-4, 12
96323780554CMC to Xe-145F PnP kit
96422542526Impeller C700 S3
96523873037The controller
96647640691001Spare parts, oil filter 47630723001 oil
96747640690001Spare parts package, oil filter 47630723001
96847632868001The pipe
96947632867001Door plank
97047632866001Door plank
9712472401520 “150 # flange
97249109531Refrigeration compressor SZ185
97394590312screw
97494589322The gasket
97567646331Pinion shaft S2 50HZ
97647630849001Pressure transducer
97737995511VALVE SUCTION W/UNLOADER
97823914914Coupling cover plate
97922435259Coupling bracket
98022411805Hexagon socket set screws M6X6
98147630851001Temperature sensor
98267651224Thrust bearing
98324662777Thrust bearing 3ACIIDF
984248731502 inlet air filter
98547557569001[large centrifugal P140] check valve 6″
98647612303001Rear filter core 108LXXX098
98721978093Air storage tank,E-445L/ 1.38mpa/country
98847609823001Oil pump with motor 380V-415V 50H
98924793689Standard filter IRG-66-8H-360
99024793671Standard filter IRG-42-8H-360
99124793663Standard filter IRG-126-8H-25
99224793655Standard filter RG-66-8H-250
99324793648Standard filter IRG-42-8H-250
99424793622Standard filter IRG-126-8H-1
99524793614Standard filter IRG-66-8H-120
99624793572Standard filter IRG-126-15H-0
99724793382Standard filter IRG-66-8D-360
99824793374Standard filter IRG-42-8D-360
99924793366Standard filter IRG-126-8D-25
100024793358Standard filter IRG-66-8D-250
100124793341Standard filter IRG-42-8D-250
100224793325Standard filter IRG-126-8D-12
100324793317Standard filter IRG-66-8D-120
100424793309Standard filter IRG-42-8D-120
100524793275Standard filter IRG-126-15D-0
100615871817Oil removal filter IRG-1800-50H-
100715871809Oil removal filter IRG-1800-50H-
100815871791Oil removal filter IRG-1800-50H-
100915871775Oil removal filter IRG-900-40H-5
101015871767Oil removal filter IRG-900-40H-
101115871759Oil removal filter IRG-900-40H-35
101215871742Oil removal filter IRG-480-25H-7
101315871734Oil removal filter IRG-480-25H-5
101415871718Oil removal filter IRG-480-25H-35
101515871692Oil removal filter IRG-180-15H-5
101615871684Oil removal filter IRG-180-15H-4
101715871676Oil removal filter IRG-180-15H-3
101815871650【C675】 Dust filter IRG-18
101915871643【C675】 Dust filter IRG-18
102015871635【C675】 Dust filter IRG-18
102115871619【C675】 Dust filter IRG-90
102215871601【C675】 Dust filter IRG-9
102315871593【C675】 Dust filter IRG-90
102415871585【C675】 Dust filter IRG-48
102515871577【C675】 Dust filter IRG-48
102615871569【C675】 Dust filter IRG-48
102715871551Dust filter IRG-480-25D-35
102815871536Dust removal filter IRG-180-15D-5
102915871528【C675】 Dust filter IRG-18
103015871510【C675】 Dust filter IRG-18
103115866650【C675】 High pressure cold drying machine D306HP
103215866619【C675】 High pressure cold drying machine D102HP
103315866601【C675】 high pressure cold drying machine D51HP7
103415866270【C675】 High pressure cold drying machine D554HP
103515866262【C675】 High pressure cold drying machine D475HP
103615866247【C675】 High pressure cold drying machine D316HP
103715866239【C675】 High pressure cold drying machine D237HP
103815866221【C675】 High pressure cold drying machine D158HP
103915866213【C675】 High pressure cold drying machine D92HP5
104015866015【C675】 High pressure cold drying machine D2850H
104115865868【C675】 High pressure cold drying machine D499H
104215865835【C675】 High pressure cold drying machine D285HP
104315865827【C675】 High pressure cold and dry machine D214HP
104415865819【C675】 High pressure cold drying machine D143HP
104515865686【C675】 High pressure cold drying machine D1027H
104615865629High pressure cold drying machine D2706HP35A
104715865454【C675】 High pressure cold drying machine D385HP
104815865447【C675】 High pressure cold dry machine D321HP
104915865421【C675】 High pressure cold drying machine D193HP
105015865413【C675】 High pressure cold and dry machine D128H
105115865405【C675】 high pressure cold drying machine D74HP3
105215865397【C675】 High pressure cold and dry machine D36HP3
105315865116【C675】 High pressure cold drying machine D636HP
105415865074【C675】 High pressure cold drying machine D405HP
105515865066【C675】 High pressure cold drying machine D347HP
105615865058【C675】 High pressure cold drying machine D289HP
105715865041【C675】 High pressure cold drying machine D232HP
105815865033【C675】 High pressure cold drying machine D173HP
105915865025High pressure cold drying machine D116HP30A
106015865017【C675】 High pressure cold and dry machine D67HP3
106115865009【C675】 High pressure cold and dry machine D32HP3
106215871726Oil removal filter IRG-480-25H-4
106368122456The center pipe CV2S3
106424886343coupling
106524886335coupling
1066C1000S01C1000-1st Dynamic balance S140
106723826472At the top of the panel
106822853253The impeller
1069AAP3810030-00001COOLER.OIL.GENERAL
107046851622Control transformer 1000VA
107149159254LOVEJOY COUPLING C700
107249159247LOVEJOY COUPLING C700
107347620276001Pressure sensor 105CGQ085 MEAS
107447620270001Drain valve 104ZJF301 1/2′
107547620268001Valve position feedback 104XWKG203 KP
107647620243001Muffler 104XYQ102 3/4′
107747620242001Muffler 104XYQ101 1/2′
107847620225001Two position five-way solenoid valve 104EWTF106
107947620205001Blower suction filter 104GFJPJ
108047620177001Inner bladder of electric heater 106JRQD183
108147620172001Pneumatic butterfly valve 104QDDF57 DN125+
108247620098001Control air source filter element 108LX1
108347621203001Dew-point meter
108447621201001Temperature sensor
108547621197001Two five way solenoid valve
108647621192001Porcelain ball
108715476757Precision water system scale remover :SE0
108815476765Water system rust and scale remover (D99)
108924876690Solberg electric oil mist separation core
109067931063joint
109147617310001Non-standard self-cleaning filter IRSS-16
109247615786001Armored twisted-pair shielded cable ASTP-
109347615780001Non-standard filter
109447612937001The meter on the self-cleaning filter is inflated
109547577785001Large centrifugal oil filter element
109647549402001[P674] Heater 30KW
109747611136001Muffler 104 xyq106
1098AAP3793119-00134Auxiliary oil pump coupling
109924876682Solberg electric oil mist separator
1100AAP1900086-00011NUT.HEAVY 1-1/8-12 (1-13
110119047554HUADA motor 600 HP / 380 v
110223486509Diffuser S2
1103AAP1401428-09050PUMP.OIL.PD
110447596090001IControl – switches
110524356495Standard filter FA30ID
110624232159Standard filter FA190IA
110749073075Person D342INRI – A
110849110729Standard drying machine HCR6H ZP D
110949110620Standard drying machine HCR6H D
111049073067Person D294INRI – A
111149073042Person D108INRI – A
111249073034Person D72INRI – A
111349029242Standard suction dryer DM312IER D
111449029234Standard suction dryer DM282IER D
111549029135Standard drying machine DM312ILR D
111649029127Standard cold drying machine DM282ILR D
111747545761001[C675] Standard drying machine D312IERi
111847545760001[C675] Standard drying machine D282IERi
111947545759001[C675] Standard drying machine D216IERi
112047545758001[C675] Standard drying machine D126IERi
112147545757001[C675] Standard drying machine D72IERi4
112247545740001[C675] Standard drying machine D312ILRi
112347545739001[C675] Standard drying machine D282ILRi
112447545738001[C675] Standard drying machine D216ILRi
112547545737001[C675] Standard drying machine D126ILRi
112647545736001[C675] Standard drying machine D72ILRI4
112724489775High pressure drying machine D126IHPD360
112824489767High pressure drying machine D66IHPD360
112924489759High pressure drying machine D42IHPD360
113024489742High pressure drying machine D126IHPD250
113124489734High pressure drying machine D66IHPD250
113224489726High pressure drying machine D42IHPD250
113324489718High pressure drying machine D198IHPD120
113424489700High pressure drying machine D126IHPD120
113524489692High pressure drying machine D66IHPD120
113624489684High pressure drying machine D42IHPD120
113724489650High pressure drying machine D126IHPD080
113824489585High pressure drying machine D126IHPD055
113924489577High pressure drying machine D66IHPD055
114024489510High pressure drying machine D126IHPD035
114124356511Standard filter FA30IH
114224356487Standard filter FA30IA
114324349607Standard filter F216IU D
114424349599Standard filter F150IU D
114524233124Standard filter FA110IG
114624232274Standard filter FA230IG
114724232258Standard filter FA230ID
114824232233Standard filter FA230IA
114924232217Standard filter FA190IH
115024232191Standard filter FA190IG
115124232175Standard filter FA190ID
115224232134Standard filter FA150IH
115324232118Standard filter FA150IG
115424232092Standard filter FA150ID
115524232076Standard filter FA150IA
115624232027Standard filter FA110ID
115724232001Standard filter FA110IA
115824231938Standard filter FA75ID
115924231912Standard filter FA75IA
116024231896Standard filter FA40IH
116124231854Standard filter FA40ID
116224231821Standard filter FA40IA
116319049535D350IL non-thermal adsorption dryer
116415866627【C675】 High pressure cold drying machine D153HP
116567929679Connect the head
116647586142001High efficiency heat exchanger C950 stage
116740049942Unloading solenoid valve
116839198494Temperature switch
116996740832Nut M6
117047547238001Standard drying machine D312IERi20
117147547237001Standard drying machine D282IERi20
117247547236001Standard suction dryer D216IERi20
117347547235001Standard suction dryer D126IERi20
117447547234001Standard suction dryer D72IERi20
117547547185001Standard drying machine D312ILRi20
117647547184001Standard drying machine D282ILRi20
117747547183001Standard suction dryer D216ILRi20
117847547182001Standard drying machine D126ILRi20
117947547181001Standard suction dryer D72ILRi20
118024356503Standard filter FA30IG
118124231870Standard filter FA40IG
118223693856Standard cold drying machine D360INA D
118323693849Standard cold dry machine D300INA D
118423693831Standard cold drying machine D240INA D
118523693815Standard cold drying machine D144INA D
118623693781Standard cold dry machine D54INA D
118723693773Standard cold drying machine D42INA D
118823693765Standard cold drying machine D25INA D
118923693757Standard cold drying machine D12INA D
119019049527Standard suction dryer D275IL D
119119049501D150IL non thermal adsorption dryer
119223569346Sealing ring
119323600588Auxiliary oil pump 380/440 V 50/60
119424231953Standard filter FA75IG
119547580181001Selected switch
119622379218Impeller S2
119723601719shell
119823586761shell
119994761749Metal hose
120047577326001108 lx1004 filter element
120167835702COLLAR – TH – THRUST CH6.3 X1
120296720172Bolt M8 X 20
120347562662001The filter element
120424019945gasket
1205C9500003C950-3 rd of dynamic balance
1206C9500002C950-2 nd dynamic balance
1207C9500001C950-1 st of dynamic balance
1208C7000003C700-3 rd of dynamic balance
1209C7000002C700-2 nd dynamic balance
1210C7000001C700-1 st of dynamic balance
1211C4000002C400-2 nd dynamic balance
1212C4000001C400-1 st of dynamic balance
1213C3000S01C3000-1st Dynamic balance S140
1214C3000003C3000-3 rd of dynamic balance
1215C3000002C3000-2 nd dynamic balance
1216C1000003C1000-3 rd of dynamic balance
1217C1000002C1000 to 2 nd dynamic balance
12186CH000016 ch 1 st of dynamic balance
12195CII00035 SEC (B) – 3 rd of dynamic balance
12205CII00025 SEC (B) – 2 nd dynamic balance
12215CII00015 SEC (B) – 1 st of dynamic balance
12225CH000015 ch 1 st of dynamic balance
12234CI000054 ci – 5 th dynamic balance
12244CI000044 ci – 4 th dynamic balance
12254CI000034 ci – 3 rd dynamic balance
12264CI000024 ci – 2 nd dynamic balance
12274CI000014 ci – 1 st of dynamic balance
12283CII00033 SEC (B) – 3 rd of dynamic balance
12293CII00023 SEC (B) – 2 nd dynamic balance
12303CII00013 SEC (B) – 1 st of dynamic balance
12313CI000053 ci – 5 th dynamic balance
12323CI000043 ci – 4 th dynamic balance
12333CI000033 ci – 3 rd dynamic balance
12343CI000023 ci – 2 nd dynamic balance
12353CI000013 ci – 1 st of dynamic balance
12362CV000032 CV – 3 rd of dynamic balance
12372CV000022 CV – 2 nd dynamic balance
12382CV000012 CV – 1 st of dynamic balance
12392CII00032 SEC – 3 rd dynamic balance
12402CII00022 SEC – 2 nd dynamic balance
12412CII00012 SEC – 1 st of dynamic balance
12422ACII0032 acii – 3 rd dynamic balance
12432ACII0022 acii – 2 nd dynamic balance
12442ACII0012 acii – 1 st of dynamic balance
12451CV000021 CV – 2 nd dynamic balance
12461CV00001CV – 1 st of dynamic balance
12471CII00021 SEC – 2 nd dynamic balance
12481CII00011 SEC – 1 st of dynamic balance
12491ACV00021 acv – listed 2 nd dynamic balance
12501ACV00011 acv – 1 st listed dynamic balance
12511ACII0021 acii – 2 nd dynamic balance
12521ACII0011 acii – 1 st of dynamic balance
12530CV000020 CV – 2 nd dynamic balance
12540CV000010 CV – 1 st of dynamic balance
125524231987Standard filter FA75IH
125622509640Flange tubing S2 TO S3
125767863688The rivet
1258LUB1000005The coolant
125924252777Pressure sensor 0-500 pSIG
126095720330Cooler gasket
1261A050910350Empty filter
126296760137Right Angle bend
126323703291Bypass valve DN150 PN10
126424751885Oil filter differential pressure transmitter
126570472097The oil filter
126623356553bolt
126795720314o-rings
126823584071o-rings
126922738819Vibration probe
127049161383Centrifuge service wrench set
127185564516F71IH 042SCFM-BSPT filter
127295452215Inner and outer wire joint
127396764170o-rings
127496764162o-rings
127596764154o-rings
1276
127796742499Screw machine screw M4 X 10 FSHC
127896742424Bolt M6X45
127995946174Pipe joint
128095934923gasket
128195420279Retaining ring
128295135505Retaining ring
128395051843gasket
128495051835Gasket 8.0″
128595023172o-rings
128695023081o-rings
128795021812o-rings
128895008215O-ring 7X7-.25 X.12
128994572948GASKET KIT 3ACII 3STG
129094523685Flexible Hose
1291944754805″ flange gasket
129290171778Gasket 6.0″
129385687028KIT-PARTS- OVHL- C250
129468250372Gaskets main pump
129568249671Gasket nose cover
129668245158Two stage diffuser
129768244557Three stage diffuser
129868209931Take over NPT2″
129968185263First stage nose
130068184233Lubricating oil hose
130168146448Radial bearing 5CIIPI S1
130268106657Control the intake valve
130368104280Bypass valve
130468088566Intake valve
1305679795918 “expansion joint
130667952572Air intake filter differential pressure switch
130767940460Hose Assembly 1.0 X 46″
130867923250Blind flanges
130967903336Hose Assembly 1.0 X 51″
131067903138hose
131167901025Hose Assembly 1.25 X 30″
131267893958Sliding bearing
131367881938Bolt socket hexagon M6X30
131467829317seal
131567792945Oil pump without drive
131667746834Adjustable gap gasket
131767728139Clamp connector 8″
131867693838Bypass muffler
131967671586Thrust bearing 3CI-4CI
132067671578Thrust bearing 3CI-4CI
132167649632Seal nitrogen 4CI S1
132267590299Reverse thrust bearing big gear 5CII/B
132367589994Gasket thrust bearing cover
132467585851Pin 3 mm X 10 mm
1325675609954 ‘flange
132667509877Intake ring 4CI S1
132767504944Seal gas 3 ci ci – 4
132854766712SEAL OIL SHAFT 5.00 X 6.
1329490552392 “joint
133043151653u-bolt
133142973313GASKET KIT 4CI-4C150
133242591446Large centrifugal 3CII second rotor group
133342589283Rotor S3 3 SEC
133442531178ROTOR,S/A C250 S3 50HZ
133542531152ROTOR,S/A C250 S2 50HZ
133642531137ROTOR,S/A C250 S1 50HZ
133738440947PNLD control line assembly
133838326880Primary intake valve spool repair kit: 38
133937189669ROD CONNECTING 11 STK
134030203384BUSH X HD PIN 11 STK
134130203335BUSHING CRANK PIN 11STK/
134230181598Main bearing bushing
134324822066cooler
134424784340VALVE ACTUATOR BRAY S93
1345247784253 “by-pass valve
134624764029ELECTROPNEUMATIC POSITIO
134724680431Auxiliary oil pump motor
134824575334THERMOSTATIC VALVE
134924366924Temperature transmitter
135024186082Flange 8 “ANSI300
135124054033Temperature sensor
135223856495The auxiliary oil pump
135323854862IMPELLER,3CII STG-3 50HZ
135423834443GASKET KIT 2AHP 3ST
135523777402The tubing
135623777196The tubing
135723772106Air cooler C1000 STG2
135823772098Air cooler C1000 STG1
135923653058The tubing
136023618408Adapter flange
136123599632coupling
136223590847The tubing
136323590839The tubing
136423557689Connecting pipe
136523552896coupling
136623539786Oil filter assembly
136723499940Exhaust valve 6″
136823479967Oil cooler
136923457690Radial bearing 5CII S3
137023449812Sliding bearing
137123449796Sliding bearing
137223449770Sliding bearing
137323408990The relief valve
137423273816OIL COOLER
137523235831COOLER, AIR MOD 3C RIVET
137623164692Oil cooling support
137723064231OIL COOLER 3 ACII
137823033145rotor 5CII
137923025828Multiphase ac motor
138022933329Metal hose
138122933022hose
138222921407Diffuser S1 3CII
138322910186diffuser
138422839419Impeller C700 S3
138522824155SEAL KIT 3RD STG
138622824148SEAL KIT 2ND STG
138722824130SEAL KIT 1ST STG
138822815476Diffuser C700 S2 95%
138922801070Thurst Bearing 3CI 4TH
13902279520750Hz first stage rotor assembly
139122783328Impeller CUT S2
139222698013VALVE, CHECK GAS 10′”‘
139322608202Second stage rotor assembly
139422533418IMPELLER, CUT 2ACII S3,
139522524953Gasket 3 SEC S2 / S3
139622515423Rotor C700 S1 125#
139722435580VALVE- CONTROL BYPASS
139822425029Four stage diffuser
139922409312Sliding bearing
140022373567BEARING- BULLGEAR-COMPR.
140122369540COUPLING POP
140222271639Thrust ball bearing
140322271621BEARING-TH-FIXED/TAPERED
140419068279Oil mist separator housing low
140519002880Hose assembly pipe inner diameter 1″ total length 31
140617283698Shaft seal spindle alloy steel
140716527533The oil pump
1408465922hose
1409379131Wiring duct 18 ft
1410379073Wiring duct
141195038147casing
141219025568C700 probe takes over 3S
141323686873Spindle oil pump seal
14142295359050Hz three stage rotor assembly
141519002880Hose assembly INNER diameter 1″ total length 31″
141695156410O-ring 16 X16.38 X.188
1417232181342CV secondary air cooler core
141822SP1877Pressure transmitter
141924518748Pressure transmitter
142095160123o-rings
142195156394o-rings
142295000139o-rings
142368242684Three stage diffuser vortex ring
142468237338Large gear shaft seal assembly
142568237346The secondary shaft seal
142668237353SEAL,AIR/OIL DCC S1
142768237379Two-stage front bearing
142868237387PLN,BEARING C250/350 S1
142968226216KIT-GASKET, C350 3S-3C
143068212489Gasket assembly MAXI 3S-3C C250
1431488643KIT-VALVE-CONTROL-INLET
1432488593KIT-POSITIONER-VALVE C23
1433488536KIT-VALVE-CONTROL-BYPASS
1434468520KIT-OIL PUMP-OIL PUMP 2A
1435416834KIT-BEARING-TH-2CV/2CC 3
1436416826Sliding bearing
1437416818KIT-BRNG-TH-2CV/2CC 2ND
1438416800Sliding bearing
1439415729KIT-BEARING-TH-2A/3RD/TH
1440400531Three-stage front bearing
1441400606Two-stage front bearing
1442278523Level 2 seal
1443264713KIT-SEAL-DBL-LIP CV1 C19
1444264721Vulcanized rubber seals
144567937292KIT,GASKET,3CII 3STG BOO
144667910562Vulcanized rubber seals
144767841056gasket
144867834614Mechanical seal
144967791152Double rear bearing
145067791145Three-stage rear bearing
145167765842KIT-BEARING-TH-2ND STG C
145267765859KIT-BEARING-PLN-2ND STG
145367768473KIT-BEARING-PLN-1ST STG
145467750752Secondary seal
145568242601Triple seal
145667696187Service seal assembly
145767658120KIT,GASKET,5CII-MAXI
145867611681KIT-GASKET-MAXI-FII-DF-2
145967603670Seal assembly
146067501346KIT,GASKET,C110/1
146167501338Service seal
146222828065The oil pump
146322757850OIL MAIN PUMP POP-MOP 2C
146422743959Pump auxiliary belt drive
146517047788The main oil pump
146616527574The main oil pump
146780279847Pump belt drive
146822274542Gasket Kits Gasket Kits
146916515355DOUBLE OIL FILTER KIT
147043199306GASKET KIT 4CI S5
147143199181GASKET KIT S1-4 N2
147242969436Complete seal assembly
147342935148Gasket package 5CII S3
147494517372KIT DOUBLE OIL FILTER
147594530979GASKET KIT 3ACII 3ST
147694796232KIT OIL FILTER ELEMENT
147794866936GASKET KIT CV1A S2
147894535739Full set of sealing assembly 3CII
147990170887Gasket Kits Gasket Kits
148090151986Vent valve maintenance kit
148190148222Full set of sealing assembly 3CI
148215641707DIFFUSER C3000 2ND STG
148322027833DIFFUSER 3API 3RD ST
148443154541Rotor Assembly 6CH
148594528585Level 3 shaft seal
148690147521SEAL KIT 2CII 2ST
148790147455KIT SEAL AIR/OIL STG-1
148867512624Diffuser cover plate
148967551044Diffuser cover plate 3CI-4CI
149067645929Diffuser 4CI S4
149142989509The auxiliary oil pump
149267513309SEAL-OIL,3C&4C-ALL STG
149367668038Sliding bearing
1494402115ROTOR-3CII S3 50HZ 2A2 7
149568131580Nose C700 HOT STG3
149668194018Three-stage cooler
149768191659SEAL-BG-OIL DCC250/350 7
1498681876732 asb cooler
149968191626SEAL-AIR-OIL-DCC 250/350
150068191642The primary shaft seal
150168188317Big gear
150268188358Large gear bearing, main engine side
150368196559Thrust ball bearing
150468196567BEARING-TH-FIXED DCC250
150568196575Thrust ball bearing
150668196583BEARING-PLN-FIXED DCC250
150768196591BEARING-PLN-FIXED DCC250
150868196609BEARING-PLN-FIXED DCC250
150968176965Back plate of diffuser
151068167170Diffuser S3 3CII
1511462747ROTOR-3API S2 50HZ 2API
1512460568ROTOR-3CII S2 50HZ 45MM
1513460477ROTOR-3CII S1 50HZ 55MM
151468157080First stage plain bearing
151568080530CVR-DIFF-4C S4 2A2100-CV
151668104116LINEBORE-SAE
151768030196HEADMACH 6CC/CH6
151867965756VANEPLATE – 3 c S2 2 a1112. 7
151967905802Plain bearing 3CIIB
152067884189BEARING-BG-2ACII-325# TH
152167874628Sliding bearing
152267869958Sliding bearing
152367903757Big gear
152467834002Air compressor accessories – rotor
152567802603Large gear and shaft assembly
1526677820943ACII Hothead Secondary and tertiary connections
152767907519gear
1528454884Third stage rotor assembly
152967792580The big gear set
153068223460First stage rotor assembly
153167768945RING-INT-MACH CV2-31 3RD
153267773002Cast iron inner ring for secondary diffuser
153367773010Two stage diffuser inner ring
153467678052Gas seal casing
153567672618Thrust bearing
153667688309Thrust bearing
153767582064Gas seal casing
153867582106Thrust ball bearing
153967582163Radial bearings for large gears
154067582213Sliding bearing
154167512335Gasket oil pump
154294847837MAIN OIL PUMP
154368242569Three stage diffuser
154495336921Joint sensor
154522742670Temperature transmitter
154622671333PRESSURE TRANSMIT. 0-25
154715649429PRESSURE TRANSD.
154867528737Sealing gas 3CI-4CI S5
154967976845Coupling bushing
155067968016Coupling liner
155167968024COUPLING-DRV,SPACER
155267508275Sliding bearing
155367653048Sliding bearing
155467654335Sliding bearing
155567643205seal. air&oil
155667643213Steel seals
155767638981Sliding bearing
155867637421Sliding bearing
155967629196Seal stop ring 5CII S2-S3
156022684138C950 radial bearing S2
156168147313Nose end bolt impeller
1562680854305 x16153 shaft seal
156368074715BEARING-TH,ASSY CV1B-S2
156468071133BEARING-PLNASSY CV1B-S2
156568076470BEARING-PLNASSY CV1B-S1
156668037647Air compressor accessories – components
156767514372Sliding bearing
156868017490Sliding bearing
156968017482BEARING-THASSY 2A 325#
157068017474BEARING-TH-ASSY 2A 325#
157168015981Sliding bearing
157267995175Steel threaded bearing bush
157367995209Sliding bearing
157467995217BUSHINGTPJ MACH 2AS1-32
157567929133Seal stop ring 5CII S1
157667909614Gasket – Waffle
157767896860Finned tube
157867854265Sliding bearing
157967854257Sliding bearing
158067845982Sliding bearing
158167839787Pinion shaft CV2
158267839761Pinion shaft CV2
158367839332Pinion shaft CV2
158467840579PUMP-OIL-OIL PUMP CH5 CH
158567841734Sliding bearing
158667834812BEARING-PLNASSEMBLY CH6
158767834978BEARING-THTHRUST CH6
158867820977C700 150# Three stage thrust bearing
158967819052Radial bearing 4CI S1 TPJ
159067797803Sliding bearing
1591677988503ACII Hothead three-stage nose
159267507699Sliding bearing
159367794891Bearing 3 acii 1 st
159467763235Radial bearing
159567763227Radial bearing
159667757997Transition tube C700 S3
159767751487IMPELLER-CUT 4C-S3 112%
159867750539Sliding bearing
159967750554Radial bearing 4CI S4 TPJ
160067727909Four-stage front bearing
160167718916IMPELLER-2ACII S3 130% 5
160267700401Radial bearing
160367685487Third stage water gas separator
160467683458Second stage water gas separator
160567676593Radial bearing 3C S5 TPJ
160667677781First stage water gas separator
160767676601Radial bearing 3C S1 TPJ
160867677716Gasket – Waffle
160967662049Reverse thrust bearing 3C 4C S5
161067650036Seal nitrogen 5CIIB
161167651265Sealed gas – oil 3CIIB
161267543918SEAL AIR-OIL_2CII-1ST_SE
161385688539Sliding bearing
161422677744VIB.TRANSMITTER SHINKAWA
161516524001TRANSMITTER
161615646987The sensor
161780282874PROBE VIBRATION RAM 3300
161843009190Vibration probe
161942964791PROBE BENTLY AXIAL 4248S
162042951376Sensor extension cord
162142951350PROBE VIBRATION BENTLY N
162242951335Vibration sensor
162316518326COUPLING M.O.P.
162467559823GASKET,COUPLING F-3
162567541391Thrust washer 3CI-4CI
162667544718Thrust block 3 ci – 4 aci
162768182286The main oil pump
162868172626The main oil pump
162968116102The flange gasket
1630376921Probe to take over
1631379156Wiring duct 24 ft
1632379149Wiring duct 20 ft
1633379099Wiring duct – 14 ft
1634379081Wiring duct to 12 ft
1635355792Check valve 1.25″
163667971531COUPLING-DRV-HUB.3X3991
163767969840Motor end coupling
163867978593COUPLING-DRV-PHENOLIC H3
163968166867Check valve 6″ 3X30028
164067707430VALVE CHECK 3-CENT 1A/CV
164167662460Air seal
164267662452SEAL,N2-3CII LP STG 1
164367649624Seal nitrogen 5CII S2 S3
164467649616Seal nitrogen 5CII S1
164568090208o-rings
164668027259The thrust ring STG1/2
164767836908The impeller 3 aciis3 nose
164867811547The thrust ring
1649677587223S2C three-stage connection pipe
165067766667Washer impeller S3
165167761908Impeller bolts
165267762179Impeller gasket
165367767723Tie rod
165467695841Impeller nose
1655676681945 ciib nose ring
165667687806The thrust ring
165767658757Steel tapping screws
165867645077Steel tapping screws
165967645093Square head screws of steel
166067677955o-rings
166167677971o-rings
166267627083Impeller bolts
166367587311Bearing cover gasket
166467581108Large gear bearing cover gasket
166567573535Seal nitrogen 3CI-4CI
166667590091Steel bolt
166785667582RING- MOTOR OIL.3A236C02
166885667574bearing
166985668754SEAL- BEARING DE/ODE 3A2
167095252839Right Angle joint 1.5″
167167739268Gasket 3.0″
167267739284The gasket
167367739219The flange gasket
167485671154Main oil pump oil seal
167567506287Air compressor accessories – diffuser diversion pipe
167624360166seal air switch
167795990735The plug
167867514067Fixed clip vibration probe
167967514174Variable diameter set
168090136607Oil heater
168194761400Oil cooler
168294775772COUPLING CV2/C700
168394895497Stage 3 condensation net
168494895430Stage 2 condensation net
168594895372Stage 1 condensation net
168694571296coupling
168743142983Coupling 3ACII (MM400)
168895647194COUPLING-DRV,FLEXIBLE
168923398472Cover for rectifier
169023027147Air switch
169123341324FOUR RELAY MODULE
169295533543pin
169323575038PNEUMATIC ACTUATOR SR60
169423458912Oil pump bearing and seal 24SP5222
169517052044BOLTS KIT 3.500.933 X
169622703573REGULATOR PRESSURE
169743120914Sealing gasket for main oil pump
169824518730Pressure transducer
169923779879Pressure gauge
170022629158Diffuser C700 S1
170122547699Diffuser C700 S3
170267503581GASKET-GASKET-COOLER 216
170367503573GASKET,CASE-TO-COOLER
170467503565GASKET,CASE-TO-COOLER
170567503557GASKET,COOLER-TO-COVER
170667503508GASKET-GASKET-COOLER.215
170767503490GASKET,CASE-TO-COOLER
170867503433GASKET-COOLER-TO-COVER 2
170995211645O-rings ID28 X0.25 “”
171095041760O-RING,14-1/2X15X3/16
171195030342O-rings ID14 X0.25 “”
171295041448O-rings ID10.5 X0.25 “”
171395023982O-rings ID9.0 X0.25 “”
171495027843O-rings ID7.75 X0.25 “”
171595026993O-rings ID5.5 X0.188 “”
171695026951o-rings
171795041927O-rings ID9.5 X0.125 “”
171895024022o-rings
171995044772o-rings
172095022398o-ring
172195915682O-RING 20A11EM167
172295023164o-rings
172395028809o-rings
172495210290o-rings
172594677994Pressure gauge
172642983973Metal hose
172794762184FLEXIBLE HOSE 1.7/16 ‘”‘ X
172843010453FLEX.HOSE 2 L=600′”‘
172994905783THRUST BEARING 3CI-4CI
173094899119FINAL DEMISTER CV1 S2
173194899051PRIMARY DEMISTER CV1 S2
173294898996FINAL DEMISTER CV1 S1
173394898939Oil mist filter
173490171018The valve device
173594500352ACTUATOR PNEUMATIC BLEED
173667728121Clamp connector 6″
173767722041RTD-W/O TRANSMITTER.1X83
173867731182ELEMENT,INLET AIR FILTER
173967500892Filter parts – filter element
174067700260PUMP-OIL,WITHOUT DRIVER
1741675404271*60 vibration probe
174267654343coupling
174367654350COUPLING-DRV-NUTS & BOLT
174467654418The coupling comes with screws
174567654368COUPLING-DRV,NUTS/BOLTS
174667646489Separator element
174767637561VALVE,CHECK LIQUID
174867633396VALVE-THERMOSTATIC 1X501
174967626028GAUGE-TEMPERATURE.1X4670
175067772608bolt
175167772616bolt
175267623223SCREW CAP M22X2. 5 x60 HEX
175367623165Bolt M8X40
175467620534CABLE-EXTENSION B/N 1X44
175567619288ELEMENT,OIL FILTER
175668197839Vibration probe
175768196898DRIVER,PUMP MOTOR
175868196872Oil pump coupling
175968196666HOSE-FLEX.1X37565
176068195056PUMP-OIL,WITHOUT DRIVER
176168188473SUPPRESSOR TVSS
176268157254KIT,THERMOSTATIC ELEMENT
176368155423Vibration probe
176468155100PROBE-PROXIMITY B/N.1X36
176568153972Air compressor accessories
176668149145The valve core
176768119312GAUGE-PRESSURE 1X35246
176868103126Vibrating transmitter
176968095538Oil filter differential pressure switch
177068091099HOSE ASMBLY,DRY TECH
177168076355Lithium ion battery
177267587790Sealing gasket
177368039254The relief valve
177467587980bolt
177568019686Safety valve 200 PSIG
177668014919VALVE-THERMOSTATIC.1X302
177768014695VALVE-PRES RELIEF 1X3020
177868181429hose
177968181411hose
178068179464THERMOSTAT,OIL HEATER
178168093426Bolt M6x1 55 l
178268081587bolt
178368153543M6 * 40 bolt
178468010545TOOL-5CII.1X21739
178568010537Seal gear 5CII-5CIIB
178667996892Right Angle connector
178767993808The differential gauge
178867994244VALVE, CONTROL-BYPASS
178967991497Lock washer
179068132026Bolt M10X70
179168153535Bolt M10X50
179267996181O ring 3 c / 5 ciib
179367987289The main oil pump
179467984435GAUGE, DP DWYER 0-20′”‘
179567979500Intake expansion joint
1796679779754 “expansion joint
179767977553Exhaust expansion joint
179867969816The oil pump
179967988998diaphragm
180067967539actuator
180167986141Actuator new :85709129
180267958975Big gear shaft seal
180367951012Sealed big gear 3CI-4CI
180467945113Auxiliary oil pump motor
180567947853Big gear seal
180667940478Hose Assembly 1.0 X 20″
180767912048Dual oil filter
180867917708Oil pressure drive valve
180967917161Air filter
181067910331POSITIONER,REPAIR PARTS
181167906628Temperature sensor
181267675421Seal 1/2″
181367922211Directly to the head
181467904466Directly to the head
181567902940Temperature control valve
181667901009Direct head 1.25 X 1 STR
181767901033Directly to the head
181867889634Resistance type temperature sensor
181967888016Temperature sensor
182067880559gasket
182167879163OIL-CV-O-5 GAL..  1X15023
182267876920Temperature control valve
182367516948Sliding bearing
182467856351Pressure transducer
182567535658The heater
182667843912Two-stage rotor assembly
182767843557ROTOR-CV2 33 S1 50HZ.1X1
182868192095bolt
182967822718The auxiliary oil pump
183067839639Level 3 rotor
183167532622PROBE
183267853036Heater tank
183367792119Main oil pump coupling
183467793315coupling
183567973552COUPLING-DRV-LOVEJOY L-0
183667962480Auxiliary oil pump coupling
183768188937pin
183867975151pin
1839342980ROTOR,CH6 2CII 50HZ S1
184068185891pin
184115646433The check valve
184243187855The relief valve
184343031061By-pass valve 8″ ANSI 300# C
184443031046Inlet valve 20″ ANSI 150# C
184543030964Pneumatic drive valve
18464303094919 sp558 intake valve
184743030923Bypass valve
18484303090719 sp556 intake valve
184942980409Check valve DN150 PN10/16
185043038710Oil temperature control valve
185123442536IV 6
185223820103BV 2′”‘ ANSI-DIN 150 PTF
185323380116EL. / PNEUM. POSITIONER
185423109697TEMPERATURE CONTROL VALV
185522677082TEMP.CONTR.VALVE 2′”‘ANS
185617044686CHECK VALVE
185716562191Bypass valve
185816562175Intake valve
185994724119Bypass valve
186067503052GASKET-GASKET-COOLER.187
186167503045GASKET,GASKET-COOLER
186295749222The retaining ring
186395738449Hole with ring
186495738431Hole with ring
186594864881Temperature control valve 2 “ANSI
186624054041Temperature converter
186722018287Secondary air filter element
186822018261First stage air filter element
186994720968Oil mist separator electrically driven
187094907193Check valve 6″ 300LB H PED
187194941499Expansion joint 6″ ANSI300
187216558181Five stage air cooler
187395233326CAPSCREW,HEX SOC 1/4X2 S
187495067732bolt
187522786792Water flow switch
187643006998Condensing drain water collector
187742964379The steam trap
187823843675The oil level switch
187924479594Oil pump 399 LPM
188095005807Check valve 1.5″
188195005799Check valve 1.25″
188290160227Pneumatic drive valve
188394941663VALVE-CHECK 1042SP
188494526225Check valve 10″ 150LB C PED
188590151176C.V.8IN ANSI 150LB C
188694524444Check valve 6″ 300LB C
188743119684Radial bearing 5CIIPI S2
188843119668Radial bearing 5CIIPI S1
188943118967Thrust bearing 3C S4
189080280498The check valve 3″
189194811833Gasket cooler
189294817277o-rings
1893379081Shielded copper wire stranded
18943X4727-10Shielded copper wire stranded
1895379073Shielded copper wire stranded
189624776072Cooler SS C950S2
189768157056Third class plain bearing
189867988493Coupling motor end
189967970475Coupling host end
190067931584Auxiliary pump
190167618728Condensing discharge tray
190267500090Condensing discharge tray
190322619498Rotor assembly S1
190468156751Washer impeller S1
190567570325The gasket
190668153105Steel bolt
1907678393812 nd C700 nose
190867792515Rotor leading edge cone
190967782292Rotor leading edge cone
191067695858Rotor leading edge cone
191167629089Nose end block impeller
191285564516Standard filter F71IH D
191367745588Gasket impeller 5CII
191467792507Gasket impeller
1915SE003709Differential pressure transmitter Rosemont 3051
1916SE003694Pulse switch ZB2BZ101C
1917SE002929The handwheel M12
1918SE003682Pulse controller DMK-4CSA
1919SE003679The differential gauge 0-2000 pa
1920SE003673Coil 400325-642?  24VDC
1921SE002923E type seal ring φ 418
192267633479The impeller 3 aciis2 nose
192367687764Steel washer
192467544072Small centrifugal steel washer
192567762187Gasket impeller
1926SE002926Solenoid valve 1.0 “, 24VCD
192722676977Diffuser C700 S1
192868014364Small centrifugal C400 dynamic balance bolt
192967917807Gasket cooler
1930SE003652Self-cleaning filter core (including 2 filter cartridges)
1931SE003643Self-cleaning filter core (including 2 filter cartridges)
1932SE003640Self-cleaning filter core
1933SE003637Self-cleaning filter core
1934SE003634Self-cleaning filter core (fast card type)
1935SE003631Self-cleaning filter core (fast card type)
1936SE003628Self-cleaning filter core (fast card type)
1937SE003625Self-cleaning filter core
1938SE003622Self-cleaning filter core
193924705485Self-cleaning filter core
1940SE003616Self-cleaning filter core
19412279668450Hz secondary rotor assembly
194295359691o-rings
194368192160Gas water separator CV2 STG1
194443069194Water gas separator
194567758896The thrust ring CV2
194667500793Siamese
194724873143Secondary air filter element replacement 67731158
194824873135Primary air filter element replace 67731166
1949237769742 PASS oil cooling
195022796841Rotor assembly S2
195122795314Rotor assembly S1
195222780613Diffuser C700 S3
195322779649Diffuser C700 S2
195422675904Diffuser C700 S1
195518990614Pipe assembly (up to 3ST water collector)
195623599004Coupling bushing
195723546757Coupling motor end
195867839472Three-stage impeller nose
195967768903C950 three stage hot core tube
1960SE003430Self-cleaning filter core φ 350*660
196196716337Bolt M20X60
196267970327coupling
196395023156O-ring.101″WX 5.399″ I.D.
196495021747o-ring
196568092014Key.25 X.25 X.62″
196668091735Key.62 X.62 X 2.50″
196767970319coupling
196867939363seal
196967909309Oil pump shell
197067764076Spacer ring oil pump CV2
197167763532Cycloid ring
197224853079RTD temperature
197324577306Pressure sensor 0-50psi
197467919654C950 water cooled oil cooler
1975247240496 “150 # flange
197624724031150 # 10 “flange
197722676712diffuser
197868017961Impeller bolts, stage 3
197919066901Communication module PM-160
198094588456nut
198168017987Impeller bolts, Grade 1
198267829358Bolted rotor 1/2″-13UNC
198367589564Bolted rotor 1/2″-13UNC
198467669150Gasket cooler
1985953001586 ‘”‘ flange
198667965699Impeller bolt 3CIib-S1
198723453624Bolt the impeller
198823453616Bolt the impeller
198923453608Bolt the impeller
199023829757Bypass valve
199167965707Dynamic balancing bolt
199268097799Low flow differential pressure switch
199367988980Intake valve leather bowl
199467707422Check valve
199524751901Temperature sensor dual support
199695060125O-rings. 125. “”
199723431141Brazed plate oil cooler
199868026673Bolt. 31 “X5.38”
199995428124o-rings
200095022331O-ring 82.14×3.53 SAE AS
200195786885O-rings ID47.0 X0.25 “”
200268147511Radial bearing 5CII S2 TPJ
200367956268Thrust bearing 5CII S1
200467945139Thrust bearing 5CII S2
200567906735Thrust bearing big gear 5CII/B
200667904664Big gear 5CII 50HZ
200767793224Thrust bearing 5CII S3
200867666388Radial bearing
200967662163Radial bearing 5CII S1 TPJ
201067649608Sealing oil 5CII S1
201167649590Seal gas 5CII S1
201267628883Sealing oil 5CII S2 S3
201367590968Thrust bearing big gear 5CII/B
201467590059O-ring cooler ID40.160″
201567589911Sealing gas 5CII S2 S3
201642974501Gasket 5CII class
201715654569o-rings
201823408982plunger
201924680936Motor rear bearing
202024680928Motor front bearing
202146836045Cooler C400 S2
202267867135C980 three stage oil gas seal
202368107259C980 two-stage radial bearing
202468107242C980 three stage radial bearing
202568107234C980 grade radial bearing
202623268667C980 three stage thrust bearing
202723268659C980 first stage thrust bearing
202823268642C980 two stage thrust bearing
202923480692460/60 hz auxiliary oil pump
203068024017C980 first stage oil gas seal
203124667719Temperature sensor
203246846572Temperature controller oil heating
203368155092The probe
203467590182Air seal
203567590018Oil seal
203667580944Air seal
203767580936Air seal
203867580928Oil seal
203924684482Set the filter material
204067795211Driver oil pump motor
204195034559Internal connector.12 X2.50″
204224326720Temperature measuring element for motor bearing
204395603163o-rings
204495438909o-rings
204595295879o-rings
204667917146The pressure regulating valve
204767755447Thrust bearing assembly
20482463789427 kw heater
204924637662Muffler 3″
205067750745C950-s1 oil gas seal assembly
205167750703C950-s1 rear thrust bearing
2052400598C950-s1 front bearing assembly
205342964668Vibration probe RAM330
205424577298Pressure sensor 0-200psig
205542964684Vibrating cable RAM
2056SE002170Non-standard self-cleaning filter core φ 324
205724623795Self-cleaning filter core
205824623787Self cleaning strainer assembly
205924623761Self cleaning strainer assembly
206024623753Self cleaning strainer assembly
206124623746Self cleaning strainer assembly
206224623738Self cleaning strainer assembly
206324623720Self cleaning strainer assembly
206424623712Self cleaning strainer assembly
206524623704Self cleaning strainer assembly
206624623696Self cleaning strainer assembly
206724623688Self cleaning strainer assembly
206824623670Self cleaning strainer assembly
206922831788Vibrating transmitter
207024054025Temperature sensor
207124627200Two stage air filter core
207224627192First stage air filter core
207324597643Oil cooler
2074SE002098Water system rust and scale remover (Agent B)
2075SE002095Water system rust and scale remover (Agent A)
207624525115RTD 9S-80
207724017766Secondary cooler 5CII
207868157064Second stage plain bearing
207968105956Valve positioner
208067982413Plain bearing S3 3CII
208167796300Plain bearing S1 3CII
208267677674First stage thrust bearing
208396720446Nut M20
208423779911Pressure sensor 0-500 pSIG
208567757914Thrust bearing CV2
208668017946Bolted rotor 1/2″-13UNC
2087676451193CI impeller bolt
208868055128Radial bearing 4CI S4 TPJ N2
208967720367Oil level indicator
209023797327Integrated multi-machine controller
209167501247Thrust bearing 3CI-4CI
209222696827Vibration probe
209368005362Bolt rotor M20
209468055110Radial bearing
209568055102Radial bearing 4CI S2 TPJ N2
209668055094Radial bearing 4CI S4 TPJ N2
209767819466Cv0 dynamic balance bolt
209867750513Radial bearing 4CI S5 TPJ
209967662064Thrust bearing 3CI-4CI
210067589473Small centrifugal 2CII rear thrust bolts
210167522599Thrust bearing 4CI S1
210295058194O-rings 5.50 X. 137
210368157924Bolted impeller S1
210468157718Bolt impeller S2
210596740964Bolt M5X35
210622532816Third stage impeller
210795656823o-rings
210895656336o-rings
210995603148o-rings
211095438990o-rings
211195135471O-ring 19.0 X19.38 X.188
211295041893o-rings
211395990396Lock washers
211495641734O-rings ID10.5 X0.188 “”
211595254173Flange 4 x150
211695106233Flange 8 “150 #
211795067674Hexagon socket bolt
211895005815Check valve
211994949641GASKET KIT 5CII S3
212094925476Three stage back thrust seal gasket
212194899630Pneumatic drive valve
212294892809Switch valve
212394880887Locking gasket 8,4 SS
212494761467Oil cooler
212594695194Pneumatic actuator new :94695194
212694679255Pneumatic actuator
212794590130Assemble vibration probe 5CII
212894589660Air compressor accessories
212994588837PIN DOWELL D40XL70
213094581600ELEMENT-FILTER.14SP009
213194562808The positioning pin
213294532884The oil filter
213394524774PUMP – OIL. 2.503.178-3
213485699916Ac motor (380
213585696771The oil filter
213685686988KIT-PARTS- OVHL- 2ACII
213785686939KIT-PARTS- OVHL- 2CV S3
213885686921KIT,PARTS, OVHL, 2CV S3
213985686905KIT-PARTS- OVHL- 1ACV
214085676807Vulcanized rubber block
2141856478736 “clamp seal ring
214285644482GASKET, VICTAULIC 8 INCH
214385644474GASKET, VICTAULIC 10 INC
214485641751POWER SUPPLY,DC
214568249820O-rings ID781X6. 98
214668249812O-rings ID946X6. 98
214768249572Diffuser baffle ring
214868249556Thrust bearing C3000 S3
214968249523Thrust bearing C3000 S2
215068249366Thrust bearing C3000 S1
215168249317Thrust bearing
215268249309Thrust bearing
215368248269Bearing C3000 S3 TPJ
215468248244Bearing C3000 S2 TPJ
215568248137Bearing C3000 S1 TPJ
215668248053Sealed gas oil C3000 S3
215768248046Sealed gas oil C3000 S2
215868248038Sealed gas oil C3000 S1
215968247105Big gear C3000 50HZ
216068244821Three stage diffuser
216168243757O-rings ID1056X6. 98
216268242502Thrust bearing 5CIIB A B C
216368224823Air cooler – cooling core
216468224781Air cooler – cooling core
216568223445Two stage diffuser
216668220789Cooler (air) INTL DCC3
216768219633Large gear bearing, motor side
216868217371Cover plate CV2
216968216316Sealed big gear C3000
217068215995Cooler (air) INTL DCC2
217168215615Cooler (air) INTL DCC2
217268214071Three stage diffuser
217368213537Oil pump shell
217468213180BEARING-TH-FIXED DCC250
217568213172BEARING-TH-FIXED DCC250
217668213164BEARING-TH-FIXED DCC250
217768211374Two stage diffuser
217868205731C950 three-stage heat discharge housing
217968204684Nose first stage
218068204635First stage diffuser
218168204619Drive gear
218268202977Bolt dynamic balance
218368202837DIFF-FM,C950 S3 2A3130,D
218468200807Dynamic balancing bolt
218568200799DIFF-FM,C950 2ND
218668199405Three-stage rear bearing
218768199397Double rear bearing
218868199389First stage back bearing
218968197680HEAD 2CC/C700 CART STG 2
219068197672HEAD 2CC/C700 CART STG 3
219168195791Third stage thrust bearing
219268195783Second stage thrust bearing
219368195767Impeller bolts
219468195700COUPLING-DRV,HUB H2 FLEX
219568195692COUPLING-DRV,HUB H2 FLEX
219668193804Impeller bolts
219768192178Gas-water separator C
219868187582DIFF-C950 S2 2API
219968187517Diffuser diversion jacket
220068187038Diffuser diversion jacket
220168185628Hot head secondary and tertiary connecting pipe
220268185305Hot head Second stage nose
220368106319Air way check valve
220468074707BEARING-THASSY CV1B-S1
220568013788Oil pump bushing
220667904623Big gear
220767763136Large gear and shaft assembly CV2
220867704395Rotor 3 ci S5
220967676585Radial bearing 3C S4 TPJ
221067676577Radial bearing 3C S3 TPJ
221167676544Radial bearing 3C S2 TPJ
221267503425Thrust block
221354491386RING SCRAPPER 1.5-inch R
221454491378RING SCRAPPER 1.5-inch R
221543190644OIL COOLER
221643184795CONVERTER PT100/4-20MA
221743119163Gasket cooler
221843119148Gasket cooler
221943119122Gasket cooler
222043119106Gasket cooler
222143099209screw
222243098748Locking gasket A10,5 SS
222343098201Locking gasket A6 SS
222443069251liner
222543032861TRANSMITTER-VIBRATION.42
222643017086Elastic pin 6×50 SS
222742964080Vibration probe
222842935163GASKET KIT 5CII S2
222942695924The rotor
223042692731ROTOR- FR-III S3 50HZ
2231426095522ACII three stage rotor assembly
2232426030432ACII primary rotor assembly
223342590497First stage rotor assembly
223442590463First stage rotor assembly
223542589838ROTOR- S/A 3API S2 50HZ
223642539924ROTOR,S/A C950 S2
223742533489ROTOR-S/A 2ACII S3 50HZ
223839592613VALVE DISCHARGE HCA
223938440962Ball valve
224037068293GASKET COVER CORK
224123820111Bypass valve 8″ ANSI-DIN 150
224223677677The main oil pump C1000
224323456742Adjustable gap gasket group
224423449036Adjustable gap gasket group
224523447055Adjustable gap gasket group
224623446719Adjustable gap gasket group
224723441900Oil mist separator core
224823257827Main oil pump repair Kit (mechanical seal)
224923243769MAXI GASKET KIT
225023186679GASKET KIT 4C150 (1 TO 4
225123185671Oil mist separator
225223170798Bypass valve
225323145311Gasket package
225423081128150# large gear assembly
225523066905Oil pump bushing
225623064223Oil cooler
225723032972RTD KIT FOR MOTOR BRGS
225822980098VALVE- CONTROL-BYPASS
225922980080VALVE- CONTROL-INLET
226022873095Diffuser C700 S3
226122832422Diffuser C700 S3 110%
226222829220Diffuser C700 S2 107%
226322790265Rotor 5CII stage
226422773097Rotor C700 S3 125# 100%
226522772669INLET VALVE
226622766182Metal hose
226722764500GASKET KIT 3CIIB STG.AB
226822757835MAIN OIL PUMP COUPLING
226922744874FLEXIBLE HOSE 1′”‘ 1/4
227022709505Diffuser C3000 class 2
227122704621Gear box stage 3
227222690739FILTER ELEMENT
2273226845592ACII Radial bearing S3
227422684120bearing
227522677769Vibration of cable
227622658686Hose Assembly 1-7/16 X 23″
227722645642Flat mat
227822644454Second stage diffuser
227922631246SS diffuser S3
228022631188Diffuser S2
228122631162DIFFUSER- MACH C950 S2
228222627483Seal assembly
228322619449Rotor assembly 3ACII
228422616478Diffuser C700 S2
228522614614Spare gasket package 5CII
228622614556GASKET KIT 5CIIB 2ST
228722608731Rotor S2 3 SEC
228822606644Rotor assembly C3000 class 3
228922606453Rotor assembly C3000 class 2
229022606222Rotor assembly C3000 class 1
229122591994The auxiliary oil pump
229222585343The main oil pump
229322573836Oil filter 3″
229422573828Oil filter 2″NPT
229522571095Oil filter core
229622545461COUPLING FOR POP
229722545370KIT OIL PUMP
229822516710Radial bearing seat
229922516702Radial bearing seat
230022516694Radial bearing seat
230122501399Gasket rotor 5CII stage 3
230222473151COOLER-AIR 1CII S1 ‘”‘SU
230322470660Rotating shaft 5CIIB class b-c
230422464382OIL FILTER ELEMENT – RB
230522454573Gear coupling
230622408363GASKET KIT C3000 3ST.W/A
230722396154DIFF STG3 C3000
230822383327aftercooler
230922379242IMPELLER- 3API S3
231022377519Air compressor accessories – rotor
231122375851Connect the hose
2312223717773CI washer whole piece 3CI Maxi
231322369532COUPLING M.O.P
231422362461KIT MINI C3000 S3
231522362453KIT MINI C3000 S2
231622362446KIT MINI C3000 S1
231722362396PLAIN-BRG KIT C3000 S3
231822362362SEAL KIT C3000 S3
231922362354SEAL KIT C3000 S2
232022362347SEAL KIT C3000 S1
232122357859Air compressor accessories – diffuser
232222329254COUPLING P.O.P.
232322312920coupling
232422309736Water gas separator
232522309728Water gas separator
232622308720Radial bearing 5CII S1 N2
232722307847Radial bearing 5CII S2 N2
232822306898Radial bearing
232922289193Assembling vibration probe
233022267900GASKET KIT 2CII 3ST
233122219125Complete machine gasket
233222206460Double oil filter
233322162382O-ring cooler
233422162374O-ring cooler
233522162366O-ring cooler
233622162358O-ring cooler
233722162341O-ring cooler
233822162333O-ring cooler
233922086367Cooler gasket C3000
234022086102Water gas separator C3000 S1
234119055201Heater 2.1 kW440V60Hz
234216523987VIBRATION TRANSMITTER BE
234315641145Diffuser S2 3CII
234467563460Diffuser 3C S2
234523309586OIL COOLER
234624145880Muffler RSXSQ – I
234724145666Diffuser RSKS – DN100A
234824145641Diffuser RSKS – DN200
234995703070O-rings ID16.5 X0.25 “”
235095675443Hole with ring
235195603155o-ring
235295160115O-ring 14 X17.38 X.18
235395135489o-rings
235495041463O-rings ID11.5 X0.25 “”
235595024139o-ring
235695023420o-ring
235795000089o-rings
235885643682Motor bearing
235985641678Motor bearing
236068212117Oil mist separator core
236168210624Cooler C950
236268210418PAS dynamic balance bolt
236368208545PAS dynamic balance bolt
236468208537PAS dynamic balance bolt
236568207315Impeller gasket
236668199421Siamese
236768194588PAS dynamic balance bolt
236868193093gasket
236968172014Bypass control valve
237068167188Bolt impeller S3
237168165513Cooler C950
237268165505Cooler C950
237368158617Check valve (grade 3 outlet)
237468157957PAS dynamic balance bolt
237568156199Bolt the impeller
237668156181Bolt the impeller
237768153824Gasket heater
237868152842Oil filter core
237968147883Gasket preheat oil pump
238068147305Bolt rotor M20
23816814049055 gallons of centrifuge coolant
238268122001Plain bearing S1 N2
238368121995Plain bearing S3 N2
238468121987Plain bearing S2 N2
238568119155C950 thrust bearing stage 3
238668117647Thrust bearing
238768117613Thrust bearing
238868117415Thrust bearing
238968112051Temperature control valve
239068107226Radial bearing
239168107218Radial bearing
239268107200Radial bearing
239368107119Plain bearing CV2
239468107101Plain bearing CV2
239568107093Plain bearing CV2
239668105964Intake valve
239768104868Pressure transmitter
239868088558Resistance type temperature sensor
239968088095Resistance type temperature sensor
240068063973Bolt impeller M10X115
240168052695Oil filter
240268049154Bolt impeller M10X108
240368024363Bolt rotor M20
240468022573PAS dynamic balance bolt
240568019223Bolted rotor 1/2″-13UNC
240668017979PAS dynamic balance bolt
240768017953PAS dynamic balance bolt
240868013150Bolt the impeller
240968013051Large centrifugal 3C/4C PAS dynamic balance
241068012343PAS dynamic balance bolt
241168012269Bolt the impeller
241268011717Bolts 3 aciis3
241368011709PAS dynamic balance bolt
241468011691PAS dynamic balance bolt
241568010941Bolt impeller M12X150
241668010933PAS dynamic balance bolt
241768009778PAS dynamic balance bolt
241868005172Bolt rotor M20
241967999896PAS dynamic balance bolt
242067970368Motor side coupling
242167969824coupling
242267964270Bolt rotor M20
242367955146PAS dynamic balance bolt
242467939603Big gear shaft seal
242567931212Big gear shaft seal
242667931204Large gear shaft seal
242767927368Three-stage rotor assembly
242867919662Oil cooler
242967909341Three-stage plain bearing
243067909333Two-stage plain bearing
243167909325First order plain bearing
243267909192The primary shaft seal
243367909184Secondary seal
243467909176Triple seal
243567902973The oil filter
243667902965Oil filter core
243767893040Oil cooler water cooled
243867875146Corrugated hose
243967861500Sealing stud.38″
244067844290Large centrifugal 4C2 PAS dynamic balancing screw
244167839431Washer impeller CV2 S1
244267838599Class 3 rear bearing
244367829564Bolted rotor 1/2″-13UNC
244467829325Seal STG3
244567829309seal
244667819250Nut NPT2
244767813220Gasket components
244867800920Nut M10
244967792499Bolt the impeller
245067765453Table of the differential
245167765362Intake air filter core
245267763169Seal STG3
245367763151Seal STG2
245467763144Seal STG1
245567758904Bolted rotor M8x1.0″
245667758631Thrust bearing CV2
245767754101Empty filter
245867739524Clip 2″
245967739276Gasket 2″
246067739250Shim 4″
246167739227Gasket 8.0″
246267732826Big gear bearing
246367731364Gaskets gasket
246467731166Air filter replacement :24873135
246567731158Air filter replacement :24873143
246667710392Oil and gas sealing
246767707380Exhaust valve
246867693812Muffler bypass 6000-9000
246967690057gasket
247067688325Oil and gas sealing
247167688275Oil and gas sealing
247267687798Bolt the rotor
247367682732First class shaft seal kit
247467661959Bolted rotor 3/4″-16 UNf
247567653063Class 2 front bearing
247667647636Sliding bearing
247767647107Bolted rotor 1/2″-13UNC
247867647099Bolt the rotor
247967647073Bolt rotor M20
248067645051PAS dynamic balance bolt
248167632463Impeller gasket 3ACIIS2
248267590083Gasket impeller 5CII
248367581256Gasket – Waffle
248467580910Oil seal
248567570713Service seal assembly
248667550921Gasket nestle
248767543801Class 2 rear bearing
248867543793Class 1 rear bearing
248967541383Reverse thrust bearing
249067531061PAS dynamic balance bolt
249167514117Secondary shaft seal kit
249267508234Gasket cooler
249367500181Table temperature
249446869731Sealing kit C1000
249543083427Oil mist filter core
249643083401Oil mist separator core
249743063486thermocouple
24983845959020 liters of centrifuge coolant
249924189508Motor ointment NLGI 2
250024036303Flat bottom tapered filter 12″
250124036295Flat bottom tapered filter 8″
250224036287Flat bottom tapered filter 6″
250324036212Inlet cone filter for trial run
250423948409Cooler core group 2S C1000
250523947609Circuit breaker 2P 16A
250623940919Cooler core group 1S C1000
250723909948joint
250823909930tube
250923758964Temperature control valve
251023605397Heater 380 V
251123533532Control module FMM
251223533524Display module DCU
251323500275Vibration probe
251423500259Vibration probe
251523500242Vibration probe
251623485543Check valve
251723483456Three-stage radial bearing
251823483449Two-stage radial bearing
251923483431First grade radial bearing
252023441892Oil mist separator assembly
252123426711Temperature control valve seal
252223412935Intake valve
252323393994Thrust bearing
252423367535Oil and gas sealing
252523367469Oil and gas sealing
252623148356Large gear thrust bearing
252723067184The main oil pump
252822738751Vibration probe
252922683569Vibration of cable
253022682868Vibration sensor
253122677777Vibration sensor SEC
253222677751The vibration probe
253322676886diffuser
253422658835Diffuser C700 S3 65%
253522419394Spare gasket package S5
253622419386Spare gasket package S1-S4
253722300149Complete set of gaskets
253822123566PAS dynamic balance bolt
253919030253Tank heater 4.0kW
254019030246Tank heater 2.1kW
2541190194130-160 psi pressure gauges
25421901243424V DC power supply 100W
254315654627Oil filter core
254415654544Oil filter core
2545329771gasket
254668026681Bolt. 31 “X4.13”
254718998146Seal the air pressure gauge head
254818998120Sealed air pressure switch 6psig
254918997858Selection switch 110V
255018997791Intermediate relay seat
255118997783Overcurrent protector 2.8-4A
255218997775Ac contactor 16A
255367730671Temperature sensor
255418998443Grating window with fan NEMA12
255596950696gasket
255695973434Flange clamp hoop
255795853602Hexagon socket bolt 5/16″
255895758751O-rings 6 x6. 38 x0. 188
255995720280o-rings
256095531240The internal and external screw
256195529210O-rings. 062 “W
256295025409o-rings
256395023115o-rings
256490180720Gasket 3.0″
256580277718The nose level
256668231307Rotor assembly stage
256768166859Control valve
256868136241Diffuser S1
256968109958Thrust bearing stage 2
257068077403Bearing gear
257168047976diffuser
257268031699Sealing ring
257367970301Coupling compressor end
257467906230Main oil pump housing
257567902650Hose.75″ X 49.0″
257667893032Oil cooler
257767764340Tank heater
257867755421Big gear 50 hz
257967748251Water gas separator level 1
258067726109Intake filter
258167709881Pin 0.18 X1.25
258267696302Thrust bearing stage
258367693804CV1 bypass valve muffler
258467643577Plain bearing stage
258567570069Bushing main oil pump
258667569798Waffle gasket S1
258767568261No motor for main oil pump
258867500785Condensing discharge tray
258943030667Intake valve
259043007020Exhaust check valve
259123486491Diffuser S2
259223486475Diffuser S2
259323441934Plain bearing stage 2
259422388136Rotor assembly S2
259522388110Rotor assembly S2
259619055649Cooler gasket I
259719030238Tank heater 2.1kW
259818998138Pressure regulator
259918997874Indicator light yellow 110V
260018997841Emergency stop button 110V
2601428219Rotor assembly S1
2602423871Rotor assembly S1
260367570051Big gear seal
260446848446Gasket kits C400
260519002153CV1 Auxiliary oil pump (blue)
260619001932CV1 auxiliary oil pump motor
260796741202Hexagon countersunk head bolts M10X35
260896739883Hexagon countersunk head bolts M20X 70MM
260995992392Plug. 50 “NPT
261095899175Pipe joint
261195857520Spring pin 3/32 X 1/4
261295439006O-ring 17 X 17.38 X.18
261395438917O-ring 15 X15.38 X.188
261495373775Woodruff key
261595333282Hexagon thread bush 1.50″
261695326039bearing
261795269320O-ring 13 X13.38 X.188
261895223038Hole with ring
261995223012Hole with ring
262095156402O-ring 11.5 X11.87 X.18
262195058053O-ring 5 X 5.25 X.12
262295026977O-ring 5.25 X 5.62 X.18
262395026860O-ring 3.88 X4.25 X.188
262495026845O-ring 3.62 X4.0 X.188
262595023149O-ring fluororubber 5.25X.44 X
262695022364O-ring fluororubber
262795005781Check valve
262890171695The flange gasket
262985668366Contactor normally closed Ui690V/10A
263085668333Emergency stop button 110V
263185650950Disturbance suppressor 10A 120V
263285647600Relay 2 110V coil package
263385645455Pressure regulator
263468188978Hexagon countersunk head bolts M10 X 25
263568187434Manual valve
263668173947The auxiliary oil pump
263768144013hose
263868142462Vibration sensor 0-4mils
263968135052Vibration probe
264068135045cable
264168109354Directly to the head
264268095488Resistance type temperature sensor
264368093251Wiring duct – 8 ft
264468087675Pressure transducer
264568087485Resistance type temperature sensor
264668054469Temperature control valve
264768009786Rotor stud
264868009760Rotor bolt
264968007277Pressure switch action setting 6PSIG
265067992834Liquid level indicator
265167970285coupling
265267932517Large gear shaft seal
265367889642Check valve
265467889626Lubricating oil filter
265567889618hose
265667889592hose
265767889576hose
265867889550hose
265967889519Directly to the head
266067877050Oil cooler
266167876912The relief valve
266267869990Temperature sensor
266367829895Pressure sensor 0-200psig
266467829887Pressure sensor 0-50psig
266567820910Quick insert right Angle coupling.25″ X.25″
266667793190Oil filter
266767773499Oil filter core
266867761221Gasket waffle CV1
266967754259Rotor washer
267067753525Rotor leading edge cone
267167748616Radial bearing
267267889576hose
267367889550hose
267467889519Directly to the head
267567877050Oil cooler
267667876912The relief valve
267767869990Temperature sensor
267867829895Pressure sensor 0-200psig
267967829887Pressure sensor 0-50psig
268067820910Quick insert right Angle coupling.25″ X.25″
268167793190Oil filter
268267773499Oil filter core
268367761221Gasket waffle CV1
268467754259Rotor washer
268567753525Rotor leading edge cone
268667748616Radial bearing
268767748475Adapter (probe)
268867742825Thrust bearing
268967739235gasket
269067735761shim
269167730721seal
269267729707Quick insert direct head 1/4″ X1/4″
269367729699Quick insert direct head 1/2″ X1/2″
269467729665Quick plug T connector 1/2″
269567729657Quick insert reducer 1/4″ X1/2″
269667727743Nylon tube 1/4″
269767719583Graphite seal ring
269867649368Stud seal.25″
269967643585Bushing seal assembly 1.25
270067642835seal
270167638932Bearing flange gasket
270267584920Rotor thrust stud
270367561001The flange
270467516112Manual valve
270567502914button
270654364096Pressure transducer
270743030642Bypass valve
270843030626Intake valve
270939571310The thermal resistance
271039185038Screw warning board
271138446076Insulated housing ENL 6HP
271238441226PNLD II 28(Stainless steel valve)
271338441192High liquid level alarm assembly (6.89 BAR)
271436854925bearing
271522516017Condensing filter
271618997916Disturbance suppressor 10A 250V
271723137565Pressure gauge
2718240160322 SEC cooler
271942607002C950 S2 150# 50 rotor assembly
272047701498001Centrifuge flange batch
272168183995ROTOR-3C S4 50HZ 1A 7X31
272267861658Gear shaft 3 ci
272367710319Gear shaft 3CI class 3
272422567341Rotating shaft C3000 class 2
272522027874Pinion shaft 3CI grade five
272647664972001BULL GEAR 2ACII-SB ASSEM
272724600652Rotor assembly C3000 class 3
272823279839Big gear 50 hz
272923279698Gear C1000 S2/S3 50 HZ H
273023279672Gear C1000 S1 50HZ HP
273122086128Water gas separator C3000 S3
273247699406001High voltage cabinet (reactance start) 1500KW
273396952023o-rings
273494588589CAP SCREW
273567883124VALVE,CHECK LIQUID 1X152
273667595132COUPLING COUPLING – DRV, SPACE
273767595116COUPLING DRV-Hub
273824046005Rotor assembly, C1000 S2/3 50H
273923756547seal
274047697297001Switching module
274147697296001Remote controller
274247697295001Breaker auxiliary switch
274347697294001Breaker breaker breaker coil
274447697293001Circuit breaker closing coil
274547697292001Energy storage power switch device
274647697155001Fan and Motor, 3CI 310082
27474767693001029.74 * 2.95 o-ring
274849109911Purifier LJ – 76-1.0 – I
274947696831001ABB motor oil pressure gauge
275047695590001KIT FOR COUPLING 13SP759
275194592714Bolt (x 100
275294588118GASKET
275394545456GASKET ANSI 6IN150LB
275490145319Large centrifugal cone pin
275547696076001Motor fan, 3CI 310082 electric
275647695877001Shaft seal, 5CIIB Main oil pump 1704778
275747695833001Diaphragm coupling
275847695486001Rotor assembly S3
275947603376001Impeller -MAX 2ACII STG. 35 -A
276047568919001OSP [P140] Electrical control box C700
276147563600001AUTOMATIC CIRCUIT BREAKE
276243046051Cable distribution tube options
276324776130Metal hose
276423204159EXTERNAL COOLER 4CI
276522763502GASKET
276622747364GASKET
276722689913SQUARE SCREW M24X80
276843150267AUXILIARY TRANSFORMER
27692465547430SP040 ALIMENT. 24VDC 5
277023124449AUTOMATIC CIRCUIT BREAK.
277194894482Reducer connector 1/8″NPTX3/8″NPT
2772ATH23066C950 full stage heat recovery heat exhaust transformation package
277343196732Clamp 20″
277467523878VALVE-PRES RELIEF.1X905
277524363525TEMP.TRANSMITTER
277668028729IMPELLER_MAX 2CII S3
277722532907IMPELLER MAX. DIA. 2ACII
277895082830Welding ring. 50 NPT
277994587854CONNECTOR .50″ MALE *99
278090193475ELBOW, .50′”‘ MALE
278170415732CUP PACKING CASE 2A PHE-
278267960195DIFFUSER MACHINING (CV2-
278367601054DIFF-ASM,ASSY 5CII S2 ST
278447694034001Upper computer monitoring software options
278547669116001Pipe joint, T6 – T6
278647669115001Pipe joint, T12 – T12
278747669114001Pipe is connected to tee D12
278847669113001Pipe joint 1/4 “NPTXD. 12
278947669112001Pipe joint 1/4 “NPTXD. 6
279047669111001Joint angles
279147669110001Pipe connection right Angle 1/4″NPTXD.6
279247624447001O-RING, 5 MM X 260 MM ID
279347694030001IRCT- High pressure liquid soft starter cabinet
2794AAP1807040-02018GASKET.COUPLING.VICTAUL
279542600528Impeller assembly, C950 S/A S1 50
279622970149MAXI GASKET KIT C700
279722949291BASEPLATE 5CII
2798AAP0540222-12002hose
279990234824NIPPLE special joint
280090182478FITTING CE12L-3/8
280190118241Bypass valve body
280243142389Oil filter
2803TA900002Centrifugal maneuvering balance TA9000 S2&
2804TA900001Centrifugal maneuvering balance TA9000 S1
2805TA600002Centrifugal maneuvering balance TA6000-S2&S3
2806TA600001Rotor dynamic balance TA6000-S1
2807TA300002Centrifugal maneuvering balance TA3000 S2&
2808TA300001Centrifugal maneuvering balance TA3000 S1
2809TA200002Centrifugal maneuvering balance TA2000 S2&
2810NX800003Centrifugal maneuver balanced NX8000 S3
2811NX800001Centrifugal balance
2812NX1200002Centrifugal maneuvering balanced NX12000 S2
2813NX1200001Centrifugal maneuver balanced NX12000 S1
281470415773CUP 1 PACKING CASE PHE-9
281547672572001locator
281623611106Limit adjustment connector
281722689921First stage rotor assembly
281822606578Two-stage rotor assembly
281995736310STUD 1/4 IN X 8.75 IN
282067841403The impeller
282147691639001Maintenance Service Package
282247672566001locator
282347630723001Double oil filter
2824TA200001Centrifugal maneuvering balance TA2000 S1
282522862544First stage diffuser
282622364095diffuser
282767956060Oil pump belt motor
282847651310001Spare parts for TECO motors
282947554041001Rotor assembly 3ACII STG 2 2A1
283047554040001Rotor assembly 3ACII STG 1 50H
283123975733IGV 16″ 150#
28329506465512 a5c2 washer
283367818773pinion
283423464761IGV 20″ANSI 150#
283522963243GASKET KIT C700 3ST
283622915342First stage diffuser option
283722360572diffuser
283894973732hose
283994521010joint
284022862544First stage diffuser
284122364095diffuser
284267956060Oil pump belt motor
284347651310001Spare parts for TECO motors
284447554041001Rotor assembly 3ACII STG 2 2A1
284547554040001Rotor assembly 3ACII STG 1 50H
284623975733IGV 16″ 150#
28479506465512 a5c2 washer
284867818773pinion
284923464761IGV 20″ANSI 150#
285022963243GASKET KIT C700 3ST
285122915342First stage diffuser option
285222360572diffuser
285394973732hose
285494521010joint
285567995944Impeller S1
285667882548Impeller level 2
285749023799Rotor assembly, 3API S3 50HZ
285894632429coupling
285922615744Rotor Assembly 3API 3RD STG
286022283824diffuser
286119027812Indicator light white 110VAC
286223513104Impeller _CUT C1000 3RD STG
2863IS-THER-01-09TEMPERATURE GAUGE ASHCRO
286423451024Rotor assembly S2
286567914085Small centrifugal 3C class 4 rotor assembly
286642996934Large centrifugal 3CI three stage rotor assembly
286722020994Small centrifugal 3CI primary rotor total
2868466383Large centrifugal 3CI secondary rotor assembly
286994794385The primary impeller
287067622761Water gas separator before 5CII S3
287167622753Water gas separator 5CII S3 after
287223356454Gear C1000 S1 50HZ STD
287323279771Gear C1000 S2/S3 5OHZ ST
287423072895Diffuser stage 2
287547691243001TECO motor bearing RTD
287647691242001TECO bearing RTD
2877FLEX-60BV-10FLEX CONNECTOR CENTRIFUG
2878FLEX-60BV-08FLEX CONNECTOR CENTRIFUG
287995051777gasket
288094589645bolt
288194536885bolt
288247690502001TA6000 with flange a batch of carbon steel
288347687644001Pressure gauge 0-1bar Original :IS-PRES
288415657000The relief valve
2885A050910150FILTER, ELEMENT C1501S
288667848390Diffuser stage 3
2887678400412 CV impeller
288867732685Two stage diffuser
288967691170Diffuser stage 1
289042587808The rotor
2891IS-INDF-DWY20-20DIFFERENTIAL PRESSURE GA
2892FLEX-60BV-24FLEX CONNECTOR CENTRIFUG
2893FE-02-0044FILTER ELEMENT WIRE MESH
289490-07-00-FLX-C-FOIL RESERVOIR OPPOSITE S
289547554380001THERMOCOUPLE-DYNATHERM 1
289647553682001BRAY, physical/S93-0933
289794868940Gear coupling 762MM
289847689813001Instrument gas assembly
289947688304001Cooler core
290094938263gasket
290194782380GASKET
290294782323Gasket ANSI 14 “300 lb
290394545423Gasket ANSI 3 “150 lb
290443074947KIT DEMISTER
290542586990ROTOR, 3CIIB SA 50HZ
290622799969KIT DRAWING, GASKET 5CII
290722628655ROTOR 3CIIB STG C
290868235191BEARING-THR, C750 STG 1
290968231828HOUSING-BRG PLN TPJ ST2
291068231810HOUSING-BRG PLN TPJ ST1
291168047281BUSHING,TPJ-PLAIN S1CV2E
291224603128Rotor assembly C3000 class 3
291323539596First stage rotor assembly
291423175615ROTOR, C750 S2 50HZ
291522441653ROTOR C750 STG.1 50HZ
291622349500SEAL- AIR/OIL STG1
2917DJDX0004Motor overhaul (for compensation)
291824599656Motor 10 kv1200hpodp
2919243249232021900-001 Gasket, 1.5″
2920243249152021900-001 Gasket, 2″
292147688189001Wichita touch screen includes programs
292247687635001Air water separator core 8320-0051
292378-07-00-FLX-B-FOIL RESERVOIR OPPOSITE S
292423735921The check valve
292523808348Pipe joint
292623279151actuator
292723158991Expansion joint
292816558744Expansion joint
292947687643001AIR FILTER ELEMENT
293047687642001AIR FILTER ELEMENT
293147687641001Air filter core 8320-0054
293247687640001Air filter core 8320-0055
293347687639001Instrument air source filter core 8320-00
293447687638001Instrument air source filter core 8320-00
293547687637001Instrument air source filter core 8320-00
293647687636001Air water separator core 8320-0071
293723456668VICTAULIC 6″
293822816334Gear coupling
2939ESA60300General rubber flexible cable YC4* 2.5m
294096751250Bolt M24x110
294194587417joint
294267561019The flange
294367519447Coupling bracket
294424839110OSTerminal block
294523789605Intake filter C950
294622532766Gear – C950 – STG3 – TAPERED
294719025329Sealed gas pipe 0.5″
294896768296screw
294995469037Plug 1.625
295068187558Gear box
295167963744gasket
295247615869FLESS.ASA
295346080164Steel washer
295422796965C700 S2 60HZ 1
295519032705Control tube assembly.50″
295619025303Sealed gas pipe 0.5″
295767934695Right Angle connector
295867786707Gear shaft 3CI class 2
295967769505pin
296024082711C800 secondary cooler
296119053255shim
2962R242080700TS32 Roots blower gear spare parts -S
296396725494Hexagon countersunk head bolts M16 X 100
296496715354bolt
296595034997Joint 1/4 “LG = 4-1/2”
296667595694nut
296747591134001Remanufacture centrifuge nameplate
296842607002Rotor assembly C950 S2 150# 50
296924586356Rotor assembly CV1B 2ND STG
297022984652Rotor assembly S/A C700 S2 60H
297122798151Rotor assembly, S/A C700 S3 12
297218991208Stainless steel elbow for control air pipe
2973WJM20015REWORK POC C700 SN:18544
2974SZM00025Nameplate of centrifugal fan
2975POCC950C950 FOR POC RE-TEST
2976POCC700C700 FOR POC RE-TEST
2977POCC400C400 FOR POC RE-TEST
2978KIT-SEAL-100SEALING KIT FOR SERIES 1
2979FE-E7091404Gearbox oil filter element
2980C010055701Seal seal
2981ATR41001Sf2-12 Roots fan
2982ATR29001Nx-12 for other items, see technical Agreement
2983ATR28001Nx-2 for other items, see technical Agreement
2984ATR27001Nx-3 For other items, see technical Agreement
2985ATR26004Roots fan SF250
2986ATR25004Roots fan SF100
2987ATR24004Roots fan SF200
2988ATR23004Random data
2989ATR17001Roots fan SF0-3 does not include the main engine
2990ATR16005The belt
2991ATR16002NX3 air filter element
2992ACB04001Other parts of the fan do not include spare parts
2993ACB03011DN400 non-return valve
2994ACB03010Outlet emptying electric butterfly valve DN200
2995ACB03009Outlet manual butterfly valve DN400
2996ACB03008Inlet control valve (including electric actuator
2997ACB03006Gear box GSG200YS(oil-containing station embellish
2998ACB03003motor
299996965173Round head drive screw
300096769955Screw machine gasket, PRODUCT
300196765441Hexagon socket bolt
300296765409Round head bolts
300396765391Countersunk head bolt M10X40
300496765383Hexagon socket bolt
300596749700Nut (
300696743943Bolt inner hexagon M6X45LG
300796742895bolt
300896742887bolt
300996742861Hexagon head bolt M8*50
301096742770Cup head screw
301196742549stud
301296742473bolt
301396741731Double end stud M20X90
301496741723Double end stud M16X120
301596741707stud
301696741236Bolt inner hexagon M20X80
301796741194Bolt socket hexagon M10X30
301896740766Bolt M24X70
301996740535bolt
302096740220Bolt M20X110
302196740071Locking washers
302296740022Lock washers
302396739875bolt
302496726880Hex bolt M20-2.50 X 30
302596720131gasket
302696716329Bolt M20X55
302796713250bolt
302896704937bolt
302996702816Bolt M8x16
303095999348bolt
303195993507joint
303295990958bolt
303395990933nut
303495990560pin
303595990461bolt
303695990453bolt
303795970398Wire to take over
303895931564nut
303995923058Nut. 25 to 28
304095918983In the joint
304195901831Pipe joint
304295876991WASHER.26A5S1122-00Z
304395866026The rivet
304495720348o-rings
304595701256Inner and outer connector.375 X 12 NPT
304695676250Tee 80 2000 LB.75 FNPT
304795575577Adapter 1/4″T X 1/8″NPTF
304895494134Quick insert Right Angle connector.24″ X 12″
3049
305095479325External reducing joint
305195464285cross
305295451217In the joint
305395444196Pipe joint
305495438925RING-RETAINING 182A13SXR
305595433934nut
305695431318Plug 1.875″
305795410288SWAGELOK connector
305895373767bolt
305995352571Pipe joint
306095331666Tapping bolt #8×1/2″
3061953117261/2 “plug
306295300711Quick insert direct head.25″
306395295747connector
306495280681Direct head NPT2.5
306595278503SWAGELOK CONNECTOR MA
3066952770671/2″ tee connector
306795271599Quick insert Right Angle connector 1/4″
306895260097tee
306995256863sloper
307095254397connector
307195254322Adapter 1/4″X 1/4″NPTM
307295254314Quick insert direct head 1/4″
30739525415790 ° bend
307495249975Pipe joint
307595249603The plug
307695245346connector
307795239943PIN DOWEL
307895226650Cock 1/4″
307995152062IMbolt
308095148581Internal connector.12″ X8.0″
308195105458Steel screw
308295101168Directly to the head
308395085403In the joint
308495083218joint
308595067062The valve
308695064622gasket
308795063426Pipe fittings
308895051819Gasket 051819
308995051793Gasket new: 39454525
309095051785Gasket 2.5″ pipe
309195050597GASKET FULL FACE FOR 150
309295050027The pipe joint for “X3.0 2.50.”
309395049946In the joint
309495041117Four-way joint 1/2-125#BRASS
309595034963Internal connector.12 X4.0″
309695034898In the joint
309795034781In the joint
309895034724C700 pipe joint
309995034542In the joint
310095033171Plug 2.5″
310195030771ELBOW STREET 3/4
310295026910o-rings
310395001962Connector 0.125 to 0.5
310494941903The valve
310594938453Gasket 1.25″
310694902160The coupling is attached to the shaft
310794874542Bolt M6x45
310894591088Pin 6 x20 DIN1481
310994590569Elastic pin 10×80 SS
311094589264The gasket
311194589207The gasket
311294587482joint
311394586872Bolt M20x80
311494538063Piece of lubricating oil
311594520129Gasket ANSI 6″ 600 LB
311690235029NIPPLE 3/4′”‘ NPT X 90 M
311790234279NIPPLE 3/4″ NPT X 40 MM
311890232711Tubing to 1/4″NPT X D.6
311990232315Pressure relief valve
312090180647Variable diameter joint
312185687713The palm wood frame
312280289168Carbon steel joint
312380277098Gasket thrust bearing
312480274517Coupling guard
312570477989GASKET VALVE SEAT 8X9 PS
312670477971GASKET VALVE SEAT 12X9 P
31277047796319.5 X9 GASKET VALVE SEAT
312870474473Pump – drive shaft
312970474465IMInternal gear oil pump model 8369 pump
313070472048RING WEARING 8X9 PS4
313170472030RING PISTON 8X9 NL PS4
313270471545GASKET VALVE SEAT 6X9 PS
313370470299The crankshaft set
3134704679312.00 ROD RING PACKING
3135704679232.00 ROD RING PACKING
313670431150Reducer pipe (size head)
313768249259Gasket inspection plate
313868248129Gasket thrust C3000
313968217173Main oil pump housing
314068204692C700 first stage head 60Hz
314168199512Gasket spring M5
314268193515GASKETLUBE PUMP BRACKET
314368193077GASKETDCC ALL
314468185586Thrust bearing cover
314568185396Gear box
314668156538VANEPLATE,DIFF 5API S2
314768156447Retainer CV2S3
314868156397retainer
314968156371retainer
315068149947Tube plate inlet CV2S1
315168149939Tube plate exhaust end CV2S1
315268149913Tube plate inlet CV2S2
315368138197Impeller -CUT CV1B-S1 170 5X1
315468136274Impeller -CUT CV1B-S1 210 5X1
315568135870Oil cooler
315668135342The main oil pump 60 hz
315768135318Main oil pump housing 60Hz
315868134394C400 two stage diffuser
315968133776The impeller – COM_PRE – MACH CV
316068131754Impeller -CUT CV1B-S1 220 5X1
316168130921hose
316268093400connector
316368065010bolt
3164679962563 ciib O ring
316567992362Right Angle connector
316667981803Bolt inner hexagon M6X50
316767970277Coupling 3X3950 motor
316867969485Terminal block
316967958611pin
317067930768Fit joint
317167929810sloper
317267929034Fixed rod
317367928499Fit joint
317467924100The plug
317567923359Hair use flange
317667919191Directly to the head
317767910547Double end stud M16X215
317867909580Fixed rod
317967906578Fixed rod
318067905596Oil filter differential pressure support
318167904425Right Angle connector
318267903351Directly to the head
318367890236The auxiliary oil pump
3184678788011-5/8 SAE plug
318567839779Gear CV2 STG.3 60HZ 125#
318667838359Large gear bearing cover
318767825943Cover plate
318867792598CV1 second stage rotor
318967789909Desiccant label
3190677896853/8 “nut
319167787200Impeller 3CI 4
3192677789446.0 “150 # flange
319367778746CV1 first stage impeller
319467778480CV1 first stage rotor
319567769497pin
319667765495pin
319767764902Inner and outer wire joint
319867764803Nozzle 1/8″NPT CV2/C700
319967764498Cover thrust CV2
320067763128Big gear C700
320167761247Gasket 5/16″
320267752030Shipping flange 2″
320367752022FLANGE2″ 80# SHIPPING
320467752014FLANGE4″ 150# SHIPPING
320567744664Asbestos free gasket 4″
320667744367Quick insert straight head 1/2 X 3/8
320767743336PINION CV1 1ST 60
320867735902Main oil pump bracket cover
320967727941Gear shaft 3CI grade 4
321067710582gasket
321167679787Flat plate thrust bearing
321267657932Diffuser 5CII stage 2
321367637207Gear 1ACII STG.1 60HZ
321467635680nut
321567633883Bearing cover
321667611657gasket
321767604462stud
321867592246Seal 1″
321967582114Bearing cover
322067581132Lubricating oil filling spacer
322167581116Hole peep cover gasket
322267581074Hole into flat
322367580977Vibration probe bracket
322467561241Flange 10″
322567561233Flange 8″
322667561225Flange 6″
322767561209Flange 4″
322867560672Hair use flange
322967545681Sealing cover
323067506527Diffuser baffle
323167504043Diffuser 3C S1
323267503649Nose end bolt impeller
323367503623Nose end bolt impeller
323449183452Blind flange 2 “DIN
323549169204Stainless steel cable joint
323649145451Oil cooler
323749133283Gear box of 60 hz
323849133275VIMC700 gear box 3STG 60HZ
323949133275Gear box of 60 hz
324049133267VIMC700 Gear box 2STG
324149133267Gear box of 50 hz
324249078348Vibration to take over
324349066046Tubing assembly 1.5
324449066038Tubing assembly 0.5
324549066012Tubing assembly 0.5
324649038946Applique remind
3247476804750013 SEC motor 2000 HP
324847679454001The motor
324947678444001Controller upgrade package _C3000_V7449
325047674863001Upgrade XE control cabinet specifications _V6124
325147657528001Auxiliary contact, CAL5X-11
325247655084001Pipe filter DYHF-LX-001
325347651325001Spare parts for TECO motors
325447645486001Oil cooling
325547624777001Adjust the gasket group
325647623118001Parker dryer evaporator, high density
325747620662001Oil cooling
325847617180001Gas-water separator
325947615870FLESS.ASA
326047615503001plug
326147613571001The CX45 fan is cooled after use
326247610582001Elastic block of main oil pump coupling
326347606649001C400 blue cylinder head 2S original 8027772
326447606648001C400 blue cylinder head 1S original 8027771
326547606647001C400 blue gear box original 2412265
326647606354TEM.TRASM
326747604941001tie
326847603453001Analog electric case centrifuge
326947598605001Thrust bearing cover plate
327047598604001C700 blue S3 cylinder head
327147598603001C700 Blue S2 cylinder head
327247598602001C700 Blue S1 cylinder head
327347598601001C700 blue gearbox
327447598487001Centrifugal fan host 100.06
327547597785001The control panel
327647596358001C950 third stage hot exhaust nose
327747596348001Pipeline 2s to 3s
327847596347001C950 gear box
327947596078001Cover plate
328047595622001Thrust bearing cover
328147593152001Impeller -MAX 2ACII STG. 35 -A
328247592894001Impeller -CUT 2ACII STG. 35 -A
328347581746001Condensed water pipe
328447581745001Condensed water pipe
328547581744001Condensed water pipe
328647581743001Condensed water pipe
328747581742001Condensed water pipe
328847581741001Condensed water pipe
328947581740001Condensed water pipe
329047578066001Guide plate STG3
329147578065001Diffuser STG3
329247576535001Rotor Assembly 3API 3ST (1A)
329347568617001Large centrifugal oil filter
329447557568001[large centrifugal P140] check valve 4″
329547556887001Centrifugal fan host 575.06 12/12
329647001474Roots fan host NX12
329746873360Integral package C1000
329846871075Lubricating oil packing case
329946870556Motor 1.5 HP220V60Hz
330046435830Fan host
330146435533Centrifugal fan 475.08 HIBON
330246435475Hibon multistage centrifuge head
330346435103Bearing temperature measuring device
330446435095Shaft seal
330546434817The fan body
330643184126PRELUBE OIL PUMP 3ACII 9
330743103308TUBE, 6 MM OD NYLON
330843017995Locking gasket SS
330942976977Elastic pin 12×120 SS
331042975540The rubber gasket
331142975524The rubber gasket
331242975508The rubber gasket
331342955336gasket
331442919134Name plate to
331542676668CV1B S2 60Hz rotor assembly
331642676296C700 S3 60HZ 1
331742676288C700 S2 60HZ 1
331842630418Option diffuser C700 S2
331942611046Rotor assembly, 2ACII S3 60HZ
332042610873Rotor assembly C950 S3 50 HZ
332142609875Rotor assembly STG.3
332242607085Rotor assembly C950 S2 60HZ 12
332342601583C950 first stage rotor assembly
332442600809Rotor assembly C950 S1 60HZ
332539165212Bolt # 6 * 0.38
332637983111The valve body
332737284601spring
332833426909Steel spring
332933426115spring
333024889339tube
333124877490Water solenoid valve
333224877482Water solenoid valve
333324848491Motor 500 hp440v60hzodp
333424846818Crossover sub
333524812620Pipe joint
333624793432The motor bracket
333724780124Pipe assembly
333824775504chassis
333924764599Joint 1/8 “BSPP – 1/2” NPT
3340247645651/2″ pipe, stainless steel
334124764540Shafting analysis report
334224751927stents
334324751760Flow meter
334424719031joint
334524695603Double oil cooler
3346246887156 “gasket
334724688228bolt
334824635856Go trough 1250 mm
334924600272Gate window
335024600256Electric cabinet fan
335124597478C400 standard housing assembly
335224597460C400 standard housing assembly
335324589285joint
3354245783205CII secondary cooler
335524468282Line bypass
33562436743511 kv/TEFC motor 900 HP /
335724341349CD/software
335824320590Gas pressure differential meter
335924268062Motor 800 HP / 380 v/ODP
336024263998Pressure transducer
336124126476The motor
336224122657C400 60HZ gear box
336324083644Oil cooler
336424036048Spare parts for spare parts of spare parts
336524036030Bulk box muffler
336624035149Packaging bags
3367240351312 mm gasket
3368240351231 mm gasket
3369240351150.5 mm gasket
3370240351070.2 mm gasket
337124035040Return pipe
337224035024Pipe outlet
337324035008Into the tubing
337424034019The motor
337524020307COOLER,AIR-INTL C350 S1
337624020091Reducing connector 1/8*1/4
337724016339Hose MOP out
337823930720The motor
337923900970Flange joint
338023806714Level 3 rotor
338123746431Motor 1500 hp3300v
338223746423Adjust the gasket
338323746415Adjust the gasket
338423667041C1000 pinion
338523504954Use flange DN100 PN16
338623487358C1000 high pressure gear 50HZ
338723458151C1000 high pressure gear 60HZ
338823453335Gasket for gear box peephole cover plate
338923451768Gasket for gear box peephole cover plate
339023433113gasket
339123433105gasket
339223433097gasket
339323433089gasket
339423408974bolt
3395233559443 STG diffuser
339623325657C980 water gas separator stage ii
339723325624C980 water-gas separator stage 1
339823279714C1000 pinion
339923199227diffuser
340023084023Big gear C950
340123080898Big gear C950
340223067200Main oil pump C950 60Hz
340323038979DIFFUSER ASSY 3ACII S3 (
340422999254bearing
340522999247bearing
340622999148bearing
340722999130bearing
340822999114bearing
340922954911Rotor assembly C700 STG.2 60HZ
341022941835Rotor assembly, S/A C700 S2 15
341122833701Diffuser C700 S2
341222798557Rotor assembly STG.3 C700 125#
341322798359Rotor assembly class C700
341422798250C700 S3 60HZ 1
341522796122Rotor assembly STG.1 C700HV25
341622795629C700 S1 60HZ 1
341722795603C700 S1 60HZ 1
341822795397Assembly, ROTOR, S/A C700 S1 12
341922795157Rotor assembly C700 STG.1 60HZ
342022793905Two stage diffuser
342122792824Gear box
342222783088Diffuser C700 S3 70%
342322694368C3000 auxiliary oil pump
342422677348Diffuser C700 S2 69%
342522676928diffuser
342622676829diffuser
342722661151Small centrifugal C950 third stage rotor group
342822661086Rotor assembly, S/A C950 S3 50
342922631287C950 third stage diffuser
343022606636ROTOR C3000 3RD STG
343122606420ROTOR C3000 2ND STG
343222606180ROTOR C3000 1ST STG
343322605273Third stage nose
343422605240Third stage bushing
343522530042ROTOR ASSEMBLY
343622520035Impeller COM C950S2
343722517114The screw
343822385132Gear box
343922378947Impeller -CUT CV1B S2 5-AXIS
344022345987DIFFUSER, MACH C3000 S2
3441223292395 ciib nose ring
344222245831DIFFUSER, MACH C3000 S3
344322222947retainer
344422206312diffuser
344519067594Shell packing case
344619053883Shims C950
344719053248shim
344819053230shim
344919053198shim
345019042498C700 export packed wooden cases
3451190412843acii package bag
3452190340652000HP/10kV standard motor
345319032721Control tube assembly 0.5″
345419032713Control tube assembly.50″
345519032697Control tube assembly.50″
345619032598Right Angle connector
345719025311Sealed gas pipe 0.5″
3458190215003 acii tube assembly
3459190214843 acii tube assembly
346018991281Motor 800 HP / 10 kv / 50 / ODP
346118991190Stainless steel elbow for control air pipe
346218982272Motor steering sign (Chinese)
346317959127OIL FILTER ELEMENT
346417269879FILTER AIR INTAKE 10”X1
346517050238The main oil pump
346616558587MAIN OIL PUMP 9616SP
34671000004124050387MOX – OPT, DIFFU
3468485888Tube sealing gas S1 & S2
3469475863Pipe assembly pressure release
3470391664CV1B S1 60Hz rotor assembly
3471376913Probe to take over
3472167858First stage diffuser kit
347368202431bolt
347447630721001Temperature of the RTD DUAL
347524601502Motor 4 ci
347622403224Rotor assembly S1
347724122582PT100/4-20MA SIGNAL CONV
347822679245Pressure transducer
3479AAP1802993-04960GASKET.COOLER
348068096718Intake valve
348142583260ROTOR, 5CII S2 50HZ TAPE
348222468284Gasket seal D12.3/18
348347553683001BRAY ACTUATOR, S93-1192/
3484679962723 ciib O ring
348567996264RING BACKUP 1X20763
3486679962493 ciib O ring
348767815316Radial bearing
348867639559Seal plate big gear 3CIIB
348949092851The impeller
349047684865001Spare backflow valve 6 inch
349147683847001[P140] Dry coupling qianjiang
349247683073001Bearing seal, 10323662,95%,2
349347683072001Bearing seal, 10173333,140*9
349447683071001Bearing seal, 10496260, 168*
349547683070001P140]12738504,SINGLE RTD
349647683069001Bearing, 6218 C4, 14445252
349747683068001Bearing, 6220 C4, 10170459
349824316457Rotor 5 ciipi S3
349942431791Stuffing box assembly
350039111877Water solenoid valve
350123600315coupling
350247684380001Motor matching cooler
350347620660001Oil cooling
350468049089Large centrifugal impeller 4CI class 5
350547653645002FILTERING ELEMENT
350649023534Oil temperature adapter
350724784381VALVE ACTUATOR BRAY S93
350894938230Gasket ANSI 2 “150 lb
350994578093Gasket ANSI 4 “300 lb
351016555021AUTOMATIC SWITCH
3511E24020307-NCooler C350S1
351247678445001Electrical control cabinet _ Upgrade _C3000_V7449
351395028734O-RING 3 X 3-1/8 X 1/16
351424905507Pressure sensor 0-500 pSIG
351568102003Four stage diffuser
351667830216PINION-4C110 S2 50HZ FEM
351742979690Level of the rotor
351822150056The motor
351967512053RING-INT,DIFFUSER
352047682545001Big gear service spare parts
3521426021102ACII primary rotor
352249169774Motor 800 hp10kv50hzodp
352347552258001Bray 2″ bypass control valve
352447552256001Bray 6″ inlet control valve
352547681578001Pressure relief valve
352624305740Motor 900 HP / 10 kv/IP55
352767944926PUMP-OIL,WITH DRIVER
352847656527001Cable vibration
352947656526001Vibration sensor
353047649042001Vibration sensor
353124320616Pressure sensor 0-200psig
353222793863First stage diffuser
353347682037001Pressure gauge
353447674862001XE Controller upgrade package _V6124
3535294488Option oil pump 50HZ CV2
353643153345MINI GASKET KIT SIL.3CI
3537248731683 inlet air filter
3538AAP0540061-00350The oil level switch
353923672645C1000 cooler seal kit
354018301341The coil assembly
354147680221001Spares, diaphragm FLX-450, for
354247665509001Electric cabinet
354347621986001coupling
354424598369DN250 DIN flange RF
354547678700001Oil cooling pads
354649018435Oil scale
354739590294Exhaust valve
354837982642Intake valve
354937980331ACTUATOR MULTI STACK
355023268469Gear coupling
355122495030Impeller 5CII stage 3
355247552260001Bray 4″ bypass control valve
355323479090Rotor 5CII stage 2
355423478704Rotor 5CIIPI stage 1
355523478514Rotor C3000 S3
355623476583Rotor C3000 S2
355723476575Rotor C3000 S1
355823239494Rotor 5CII stage 3
355924783045actuator
356024483315Vent valve assembly
356147679524001Coupling repair kit
356224011009COOLER,AIR INT C250 S1 /
356339918438VALVE INLET WITH U/L HCA
356447588576001Bolei 4″ bypass control valve
356542956524Screw diffuser
356622615454The rotor level 3
3567955628563/8 “bolt X1-1/2”
356824784399VALVE ACTUATOR BRAY S93
356947678291001Locta263 for fastening thread (impeller)
357042980607The check valve
3571466375Level 4 rotor
357295038576COUPLING 1/4″ 3000LB
357395022802O-RING 1/4 X 3/8 X 1/16
357490231614Variable diameter joint
357567775346Right Angle connector
357667729681Right Angle connector
357724320509Direct head 0.50
357824320491Right Angle joint 0.50
357924320467Connect wire bundle 0.5
358022150049The motor
358167559807Coupling gasket
358247678290001Loctite 454 cooler door pad
358322864128The rotor
358422863336The rotor
358522863252ROTOR C3000 1ST STG
358622859540The rotor
358722555676The rotor
358822555619The secondary rotor
358947678040001Self-cleaning air intake filter core
359018986661Wire AWG16 green
359118986653Wire AWG16 white
359218986646Lead AWG16 black
359395531257Inner and outer wire joint
359467930412sloper
359567928481Right Angle connector
359667905091joint
359724053910Three stage diversion plate
359824053886Two stage diversion plate
359924053852First stage guide plate
360023385859Three-stage bearing housing
360123385842Bearing shell
360223385834Bearing shell
360322676910Third stage diffuser
3604190357161/2 “head directly
360567846238Inner ring of first stage diffuser
360642381988The piston component
360723738735The flange
360815658867IGV VALVE 8′”‘ DIN 2576
360968106459Intake control valve
361068106442Bypass control valve
361154660154CRANKSHAFT 9 STROKE, AIS
361247625742001The flange
361322412282DIFFUSER FM CV2-29 S1-74
361422382493IMPELLER, MAX 3API S3
361547673504001CENTRIFUGAL BLOWER 675-0
361630561963gasket
36174767547900123976335 Secondary cooler core
36184767547800123976335 Third stage cooler core
36194767547700123976335 First stage cooler core
3620240160322 SEC cooler
3621240121062CII cooler S2
362247675865001Loctite 587 LETAI – 587-85 – g
362347675864001Loctite 495 LETAI – 495-20 g
362439332127DECAL CONTROL AIR
362537980380Retainer ring
362642566992Three-stage rotor assembly
362747675718001Cooler core
362847675717001Cooler core
362924575300The vent valve
363017959125Gasket kit for 12SP895 5
363117959124Gasket kit for 12SP896 5
363294900644Transition tube 4CI S2
363394695194IRIPNEUMATIC ACTUATOR
363470422803ASSEMBLY PACKING CASE WI
363570415922ASSEMBLY CUP 5
363670415914ASSEMBLY CUP 3
363742459735ASSEMBLY PACKING CASE PH
363868235944Three stage diffuser
363967585125PINION 3CII STG.3 50HZ
364024276057dry type coupling
364122686570Second stage diffuser
364217959126Gasket kit for 12SP894 5
364317043381The main coupling
364423729304Y type sealed cooler copper core
364523724552Y type sealed cooler copper core
364623466865element filter
364723448145element set E9300lG
364823448038ELEMENT KIT FOR 23447527
3649KIT-SEAL-350The seals
3650KIT-SEAL-200Fan seal
3651KIT-BRG-350bearing
3652KIT-BRG-200-FANbearing
365396749759M6 * 35 bolt
365496740345M8 * 45 bolt
365567830786Sliding bearing
365647674713001Hangzhou Risheng 105RJ006LRD22C 1
365747673932001Omron intermediate relay
365847672545001XE control upgrade package 5_DEMAKE
365947672544001XE control upgrade package 4_JOY
366047672543001XE control upgrade package 3_4CI_M0
366147672542001XE Control upgrade package 2_C3000_
366247672541001XE Control Upgrade package 1_5CII 5
366347665512001Spare parts, main oil pump seal assembly
366447620661001Oil cooling
366522086110Water gas separator C3000 S2
366696704945Bolt M16X70
366768158518PROBE-PROXIMITY B/N 1X36
366868017151CABLE-EXTENSION B/N 1X30
366967582072Gas seal casing
367047672550001Electrical control box specifications _ Upgrade DEMAKE
367147672549001Electrical control box specifications _ Upgrade JOY
367247672548001Electrical control box specifications _ Upgrade 4CI_M0010
367347672547001Electrical control box specifications _ Upgrade C3000_V82
367447672546001Electrical control box specifications _ Upgrade 5CII5CIIB
367547671968001C950 Control cabinet upgrade kit
367647671967001C700 Control cabinet upgrade kit
367739918362Intake valve
367824493405Intake valve
367922973911Temperature control valve
368022886618Second stage diffuser
368122769426PUMP AUXILIARY OIL
368247673927001TECO motor parts
368347673926001TECO motor parts
368447673925001TECO motor parts
368547673924001TECO motor parts
368647673923001TECO motor parts
368747588575001Brey 12″ inlet control valve
368867934026HEADMACH 2AHPS2-50HZ
368967933804HEADMACH 2AHPS1-50HZ
369047673841001Motor bearing
369147651305001Spare parts for TECO motors
369247653643002oil filter element
369324621443Inlet valve 20″ ANSI 150 HART
369422813000Diffuser S3
369524621450Bypass valve 8″ ANSI-DIN 150
369623512023Impeller -CUT C1000 STG.2
369724093254Rotor assembly 100/125# 2/3rd
3698F1818200868the bare shaft roots blo
369968013838HEADMACH 2AHPS3-60HZ
370067971697COUPLING-DRV-HUB 3X3988
370167614115COUPLING-DRV-SPACER.5X17
370267567677Half coupling
370367559856COUPLING-DRV-HUB
370494578119Gasket ANSI 8 “300 lb
370547671864001Electric cabinet C950
370647671862001Electric cabinet C700
370715657232Gear coupling DIST=600
370843137314Maxi Gasket kit S1-S4
370947671477001Pressure gauge positioner
371068209394Oil temperature switch
371123632631Guide plate C1000
371222555692Rotor 5CIIB class C
3713E47643636001-N5 ciibs3 cooler
3714E47643635001-N5 ciibs2 cooler
3715E47643634001-N5 ciibs1 cooler
3716E24816332-NCooler C400 – S2
3717E24816324-NCooler C400 – S1
3718E24776122-NCooler 3 SEC – S3
3719E24776114-NCooler 3 SEC – S2
3720E24776106-NCooler 3 SEC – S1
3721E24776098-NCooler C980 – S1
3722E24776080-N2 acii cooler/C950 – S3
3723E24776072-N2 acii cooler/C950 – S2
3724E24776064-N2 acii cooler/C950 – S1
3725E24688376-NCooler CV2 C700 – S3
3726E24688368-NCooler CV2 – C700 – S2
3727E24688350-NCooler CV2 C700 – S1
3728E24578320-NCooler 5 SEC – S2
3729E24578312-NCooler 5 SEC – S1
3730E24144842-NCooler 3 cis1 – S4
3731E24144800-N4 cis1 cooler – S4
3732E24016123-NCooler C250 – S3
3733E24012726-NC250S2 / C350S3 cooler
3734E24011009-NC250S1 / C350S2 cooler
3735E23948482-NCooler C3000 – S3
3736E23948474-NCooler C3000 – S2
3737E23948466-NCooler C3000 – S1
3738E22459937-NCooler CV1 – S2
3739E22444301-NCooler CV1 – S1
374039590468The flow valve
374168080225VANE-PLATE 7X14376
374242603803ROTOR 2A-HP S1 325 PSIG
374323577737To take over
374423557416To take over
3745VIBR-BSB-125-60Damping piece
3746CKV-D-5118-16Check valve
374767649640INSERT-BRG, TPJ 5CII S1
374839590286valve
374924072845Diffuser 5CII STG C
375023217375Thrust bearing
375123217342Thrust bearing
375223217318Thrust bearing
375322947790Diffuser 5CIIB STG B
3754293365ROTOR,5CII S2 50HZ 65MM
375567626044Thermometer oil circuit 02
375623626427Vibration detector 70MM
375747588574001Brey 10″ inlet control valve
3758AAP1405555-00801Sealing strip
3759680431573 ci guide plate
376047669715001Xiangtan 1000kW 10KV motor
376147669714001Inlet electric butterfly valve DN500
376247669713001By-pass electric butterfly valve DN200
376347669712001Outlet check valve DN400
376447669711001Gear box lubrication and cooling system
376543077072joint
376624598328Sheet metal parts for housing
376715655343screw
3768CPG-1080-T20Coupling complete
3769A050910200Air filter C2001 /Greata
377095447496Elbow 90
377195056032sloper
377278-04-00-000-H-Fbearing block
377375-15-07-000-A-Fshaft
377470471537GASKET VALVE SEAT, 14.5 9
377570471529GASKET VALVE SEAT 24X9 P
377670467881RING WEARING 9 X 9 PS4
377770467840RING PISTON 9 X 9 PS4
377868231745SEAL-AIR,CV5 BOOSTER
377950-15-07-000-C-Fmain shaft
378047667853001Electric cabinet
378125-17-00-000-0-FDEEP GROOVE SINGLE ROW B
378224504086Impeller, CUT C950 S3 TAPER
378324504078Impeller, CUT C950 S1 TAPER
378423880040Pipe to tee D.12
378523879263Joint angles
378623878945Pipe joint 1/4 “NPTXD. 12
378722521108Impeller, CUT C950 STG2 88
378817269887FILTER AIR INTAKE 12 X 1
378947668750001Motor bearing, Drive end, 3CI
379022834741Impeller C700 2ND STAGE
379143083260DIFF.PRESSURE SWITCH 0-5
379247668749001Bearing, motor, non-drive end, 3CI
379324614711The motor bracket
379467956714KIT-CV1A/REV TH BRGS1 C1
379543005552DIFFUSER, FM CV1A/
379642570762ROTOR, S/A CV1A S2 50HZ
379723652340C1000 nose seal kit
379817958909MAINTENANCE KIT FOR DRY
379917958908MAINTENANCE KIT FOR DRY
3800476668300013ACII Control upgrade kit
3801476661740012K hour maintenance kit C700
3802476661730012K hour maintenance kit C950
3803476661720014K Hour maintenance Kit C700
3804476661710014K hour maintenance kit C950
3805476661700014K Hour maintenance kit C950NA
3806476661690018K hour maintenance kit C700NA
3807476661680018K hour maintenance kit C700
3808476661670018K hour maintenance kit C950NA
3809476661660018K hour maintenance kit C950NA
3810476661650018K hour maintenance kit C950
381122676795diffuser
3812R014092100Kit 2 Bagues porte segme
381380281090Diffuser assembly C3000 Stage 3
381468200732Diffuser stage 3
381568181239Intake valve assembly
381631174667Secondary intake valve seat repair kit: 39
381730550628The seat cushion
381830336317bolt
381924160277Rotor assembly, C1000 S2/3 50H
382023514219Rotor assembly C1000 S1 50HZ C
382122362529The main oil pump
382222228522Diffuser assembly C3000 Class 1
382322227912The transition pipe
382495774550Internal connector.12″ X6.0″
382524577314Temperature sensor gas
382624606642Temperature sensor oil
382722628408Pre-lubricating oil pump
382847664829001BEARING TIMKEN TS
382947664828001BEARING TPR.RLR. #JH2117
383047664827001GASKET BRG RET-S6 RDCR H
383147664825001RETAINER BEARING HS MH60
383247664543001C1000 Field service Kit
383367912337Impeller S3
383449110117Refrigeration compressor RC2-100B-W-T
383568052505Diffuser cover plate
383647592286001C1000 overhaul kit
383742973438CV1A/B cooler seal kit S2
383847651327001Spare parts for TECO motors
383968080217Diffuser body S4
384024160475Rotor assembly, C1000 S2/3 50H
384124050379Option intake group
384224050361Option intake assembly level 1
384394938255Gasket ANSI 16 “150 lb
384494893252Gasket ANSI 14 “150 lb
384594812815[P140] 5CII secondary nose
384649180862Big gear shaft key
384723463029The big gear key
384823279870Large gear C1000 50Hz STD
384947663991001Plate
385047663990001Tuthill Pump
385147663989001Screw
385247663988001Gasket
385347663987001Screw
385447633063001Metal wound gasket 106DP210 D35
385522738868PROBE- VIBRATION
385622368138COOLER- STG 3 AIR EXTERN
3857CKV-D-5118-10Discharge Check Valve
385843142330coupling
385923449838Grade five rear bearing
386022811772Thrust bearing 5CII S3
386119047604600HP star triangle starter cabinet
386294727039Gear coupling 450
386343078211The check valve
386442973990GASKET KIT 3CII 3ST
3865429739743ACII cooler seal kit
386642973958GASKET KIT 3CII 1ST
386723811896Level 3 rotor
386823811888The secondary rotor
386923811870Level of the rotor
387023598634The vent valve
387123427024Diffuser 5CII stage 3
387223189806Diffuser 5CII stage 2
387343192236Complete seal
387423495583The auxiliary oil pump
387523459506The main oil pump
387622492532Impeller 3API level 1
387747663347001Ac contactor 105JCQ127
387847663346001Heating protector 502WDBHQ001
387947663345001Thermal relay 105RJ026
388047650970001Vetli card hoop 10″
388147650969001Vetley clamp 6″
388268118108First stage diffuser 7×14679
388367889535o-rings
388443196351C950 Cooler seal kit S3
388524607731Exhaust expansion joint 12 “150#
388622738769Vibration probe
388724647463Bypass expansion joint 8 “150#
388824607723Exhaust expansion joint 12 “150#
388924604829Intake expansion joint 24″ 150#
389022605265Second stage nose
389122605257First stage nose
389224287013Oil plug
3893KIT-BRG-575-FANBearing Kit
389447589895001SEAL CARTRIDGE ASS’Y AIR
389547589395001SEAL CARTRIDGE ASS’Y AIR
389642916098C1000 to install a
389742586388rotor s1
389842996280Four stage diffuser
389942920959Diffuser 4CI S4
390022531941Three-stage rotor assembly
390168192236Three stage diffuser vortex ring
3902KIT-SEAL-450SEALING KIT FOR SERIES 4
3903KIT-BRG-450-FANBEARING KIT FOR SERIES 4
3904CPG-TSC0135DIRECT FLEX COUPLING JOH
390549194129Exhaust valve
390622821987Diffuser C700 S2 79%
390767512517Gear ring for diffuser
390847625569001Unloading solenoid valve
390967510602Diffuser intake ring
391047660147001Rear cooler,3CI
391123520927Bushing inlet valve
391295446647Pipe joint
391348861066Elbow, 1.25 FNPTX1.25 “FNPT
391448861058joint
391548861041joint
391648860985The tube motor is lubricated and produces oil
391748860977Tube motor lubrication oil intake
391842973396CV1 cooler seal kit S2
391942973370CV1 cooler seal kit S1
392039590435The vent valve
392124321028Rubber gasket
392224321010Rubber gasket
392347590764001PLAIN BEARING N2 ASSEMBL
392447590598001SEAL CARTRIDGE ASS’Y AIR
392522815450Rotor assembly STG-2 C700-HV18
392622795132Rotor assembly STG.1 C700-HV18
392719031269The temperature control switch
3928RSPINIONGear shaft coating repair
3929RGPINIONGear shaft vibration zone grinding
393095987491Pipe joint
393195079778bolt
393294932639CAPSCREW UNI5931-8.8 M8X
393394880648Hexagon head bolt
393494792348GASKET KIT 2ACII S3
39359478160618 “gasket ANSI 150 lb
393694536687The large centrifugal key
393785655355KIT-OVERHAUL-CV1B
393878-12-00-000-0-FCARBON RING SERIES-78
393968164417Intake control valve
394068109156Auxiliary oil pump motor
394167979691Expansion joint 8″
394267904409Right Angle connector
394367902684PUMP- OIL WITH DRIVER
394467693820Muffler 6 * 10
394567652321First stage diffuser
394667500140nozzle
394749093040ROTOR CHX5B -l (1 a 2 ° ST)
394849002462Electric oil mist assembly kit
394947658418001Spare parts electrical control box internal material C3000
395047625184001Bray locator mounting accessories
395147625183001Bray locator Iy module
395247621982001Electric oil mist separator
395347572126001Rear pipe filter
395442935239CAPSCREW
395542935213CAPSCREW
395624771503IV ANSI 150#PN10/16
3957245783125CII first stage cooler
395824263980Pressure transducer
395924050478Deflector stage 2 100%
396024050437Diffuser stage 3 100%
396124050411Diffuser stage 2 100%
396224050395Diffuser class 1 100%
396323992233The center pipe
396423857063The pump belt drives the C3000
396523857022ELETTROPRELUBE PUMP
396623658214Rotor assembly 100#/125# 1S 50
396723633340Guide plate C1000
396823632987Guide plate C1000
396923600901First stage guide plate
397023486525Diffuser stage 2
397123293970Tube 3.0″
397223045107Rotor assembly, S/A C700 S3 50
397323027048Diffuser 5CIIPI stage 1
397422978837COOLER, OIL S.S.SHELL
397522938443Rotor assembly, S/A C700 S2 50
397622915029First stage diffuser
397722900294Rotor assembly, S/A C700 S2 50
397822862528Diffuser S1
397922798615Rotor assembly STG.3 C700 125#
398022797575Rotor assembly STG.2 C700 125#
398122796338Rotor assembly STG.1 C700 125#
398222676738Diffuser C950S1
398322676704First stage diffuser
398422668289Diffuser C700 S1 69%
398522664411Diffuser C700 S1 63%
398622656821Diffuser C700 S2 63%
398722532758GEAR, GEAR, C950/2 acii
398822530794ROTOR 5CIIPI 1ST STG
398922509277Impeller, MAX 3API S3 1BS1
399022349518SEAL- AIR/OIL STG 2-3-4
399122027098Clamp 10″
399222019996Thrust bearing 5CII S2
399322019939Thrust bearing 5CII S1
3994386987ROTOR – CH6 2 SEC 50 hz S1.1
3995379198Wiring duct 40 ft
3996379164Wiring duct 28 ft
3997379123Wiring duct 16 ft
3998248731764 inlet air filter
399947658420001Spare parts joint material C3000 Au Light
400047658419001Spare parts are now equipped with pipe material C3000 AU
400147569273001The motor 3 ciidf
400242973412CV1A/B cooler seal kit S1
400323857055Auxiliary oil pump 10576SP
400447590056Two-stage front bearing
400547579737First stage front bearing
400622772677Bypass valve 8″ ANSI-DIN 150
4007KIT-BRG-100-FANSeal kit
400824050494Deflector stage 3 100%
400924050452Deflector stage 1 100%
401023060122DOUBLE TEMP ELEMENT
401123060056Pressure sensor 0-10 bar
401223060049Pressure sensor 0-5 barg
401385709137actuator
401467502013Diffuser 3C S2
4015KIT-ORINGS-675O-RINGS KIT FOR SERIES 6
4016KIT-BRG-675-FANBEARING KIT FOR SERIES 6
401790-16-40-000-B-FCAST IMPELLER (40DEG VAN
401890-12-ZA-GAS-E-FCAST LABYRINTH SEAL WITH
401922798243Rotor assembly S3,C700
402022796957Rotor assembly S2,C700
402122795595Rotor assembly S1,C700
402223449002Adjustable gap gasket group
402368001197Coupling 1 x21256
402422746028Bypass valve 8″ ANSI-DIN 150
402547655518001Risheng drying machine after cold replacement of stainless steel
4026429740555CII cooler seal kit S3
4027429740305CII cooler seal kit S2
4028429740145CII cooler seal kit S1
402995041588o-rings
403094805603Coupling 5 SEC
403168230671The secondary rotor
403268187194Medium and small centrifugal 3C stage 5 rotor
403368117845Bypass valve
403447655517001Heater inner bladder 106JRQD178
403542522714Level 3 rotor
403642522698Level of the rotor
403743030808Intake valve 24″
403867500637hose
403967500629The hose clamp
404037980976Intake valve
404123542335Level of the rotor
404223401870The secondary rotor
4043222312375CII three stage rotor assembly
404468110782DRIVER, PUMP MOTOR
404568092568PUMP-OIL,WITHOUT DRIVER
404667888453Inlet and outlet pipe assembly
404747655008001Thermal relay
4048F015150100NX8 Roots blower head
4049F014170100NX5 Roots blower head
405067816231Radial bearing
4051248731846 inlet air filter
405222011662Dry coupling
405343105139Bypass valve 4″ hot drain
405423700487Bypass valve
405523614910Two stage diversion plate
405618998450Gate window NEMA12
405722910038diffuser
405847552259001Bray 3″ bypass control valve
405947552257001Bray 8″ inlet control valve
406022934038Rotor assembly C700 S3 50HZ 12
406122897938Plain bearing S2 3CIIB
406222896542Sliding bearing
406367688374HEAD MACHINING (STG 2)
406447651369001Spare parts for TECO motors
406547651366001Spare parts for TECO motors
406647651360001Spare parts for TECO motors
406747651355001Spare parts for TECO motors
406847651354001Spare parts for TECO motors
406947651352001Spare parts for TECO motors
407047651350001Spare parts for TECO motors
407147651349001Spare parts for TECO motors
407247651348001Spare parts for TECO motors
407347651346001Spare parts for TECO motors
407447651344001Spare parts for TECO motors
407547651343001Spare parts for TECO motors
407647651342001Spare parts for TECO motors
407747651341001Spare parts for TECO motors
407847651340001Spare parts for TECO motors
407947651339001Spare parts for TECO motors
408047651338001Spare parts for TECO motors
408147651335001Spare parts for TECO motors
408247651332001Spare parts for TECO motors
408347651331001Spare parts for TECO motors
408447651326001Spare parts for TECO motors
408547651323001Spare parts for TECO motors
408647651322001Spare parts for TECO motors
408747651319001Spare parts for TECO motors
408847651318001Spare parts for TECO motors
408947651316001Spare parts for TECO motors
409047651311001Spare parts for TECO motors
409147651308001Spare parts for TECO motors
409247651307001Spare parts for TECO motors
409323930761The motor
4094AAMB795270-90021KIT.SERVICE.STD-COMP
409524600231Vibration probe
409667927244Actuator diaphragm
409767886721The main oil pump
409823530371Intake filter
409922378244Main oil pump coupling 3CIIB
410095992269screw
410149023864Temperature transmitter
410247653404001Cover plate 1.008.228
410324279655The temperature probe
410423601230Three stage diversion plate
410550-16-74-000-A-FCAST IMPELLER SHORT HUB
410647621848001Integrated vibration (velocity) transmitter
4107429732973CI cooler seal kit
410828-85-00-000-0-FO’RING COIL 1/16 OD DIA.
410923137193Pressure gauge
4110AAP1797600-01850Oil pump drive gear
4111AAA3793923-06052Cooler assembly
4112AAA3793923-02302I/C-BAFFLE.ASSEMBLY
411348999908Screw pump 370
411424784324VALVE ACTUATOR BRAY S93
411522398390coupling
411615641327Diffuser 5CIIB STG C expansion
411795511358pin
411895033619The plug
411967711358screw
412067596965Replaced by 96703962
412147652927001TECO motor 725HP-10kV SF1.1
412247652926001TECO motor AEJE HP – 725-6 p
4123SEAL-99215SPEEDY SLEEVE # 99215
412485709129actuator
4125AAP3404090-00030KIT.SEAL.PUMP
4126AAP1798237-00009gasket
4127AAP1798237-00008gasket
4128AAP1798237-00007o-rings
4129AAP1798237-00006gasket
4130AAP1798237-00005gasket
4131AAP1798237-00004gasket
4132AAP1798237-00003gasket
4133AAP1798237-00002Sealing ring
4134AAP1798237-00001gasket
4135AAP1794461-00421Pressure transmitter (gas pressure)
4136AAP1794461-00403Pressure transmitter (main oil pressure)
4137AAP1794461-00389Pressure transmitter (front oil pressure)
4138AAP1793119-01001Coupling element
4139AAP1404040-00282Filter element
4140AAP1401428-00633PUMP.OIL.PD
4141AAP0540428-00012PUMP. The OIL. The PD w/auxiliary Motor OIL
4142AAP0540428-00010PUMP. The OIL. The PD w/auxiliary Motor OIL
4143AAMB009950-17515KIT.SERVICE.REPAIR (TAP-
4144AAMB009950-17514KIT SERVICE.BOM(6R3MSGEP
4145AAMB009950-17374KIT.SERVICE.REPAIR TAE 5
4146AAA3797125-00010Gear box interface O ring
4147AAP3409756-05000coupling
4148AAP3403893-00429Vibration sensor
4149AAP1793119-01003Coupling element
4150AAMB795270-11007Intercooled maintenance kit
415147651709001Unit cooler 205HLQ001 (carbon
4152AAP3409753-05000DISC.W/HDWARE.CPLG
4153AAP1406064-03602coupling
4154AAP1402068-00777MOTOR.ELEC.PUMP
4155AAP1401435-00228FILTER.ASSEMBLY
4156AAP0540089-00231Pressure Transmitter Bea
4157AAP0540089-00112TRANSDUCER.PRESSURE
4158AAP0540089-00111TRANSDUCER.PRESSURE
4159AAP0540089-00110TRANSDUCER.PRESSURE
4160AAMB795270-22001KIT.SERVICE.STD-COMP
4161AAMB409950-13848Main engine maintenance kit
4162AAMB409810-00600Heat exchanger sealing gasket STAGE=1 2&
4163AAMB409803-00601Tube bundle
4164AAA3793835-57821Rotor assembly. Ta6000.2-end
4165AAA3793835-57621Rotor assembly. Ta6000.1-end
4166AAA3408246-08215Impeller assembly TA38
4167AAA0540324-06001PUMP.OIL.W/_DRIVER
416847553672001BRAY CONTROL VALVE FILTE
416943005537GASKET KIT CH5
417024804171IV 8′”‘ ANSI300#
417124783562BYPASS VALVES ANSI 300#
417223104987MATING FLANGES CV 1450SP
417322320261Coupling C3000 450MM
417468208040First stage diffuser
417524783771Large centrifugal temperature probe
417624716269Instrument gas filter
417794814407Level 3 impeller
417823548837Diffuser C3000 class 2
4179IS-THER-RTD100-01RTD PLATINE 100 OHMS 3 W
418022969752Oil temperature control valve
418122910178Stainless steel diffuser
418224034332Circuit breaker 3P 9A
418323512031Impeller -CUT C1000 STG.2
418494800067Three-stage rotor assembly
418547650186001Cooler core stainless steel 205HL079
418624776098Cooler SS C980S1
4187PAD-70151Cushion 16 moq size is different
418868155134Vibration probe 1X36389
418967829580C950 three stage rotor shaft
41904764643900110 “seal ring Victoria card hoop
41914764643800112 “Seal ring Victoria card hoop
41924764643700114 “seal ring Victoria card hoop
419324054017Temperature transmitter
419424019200Oil pressure switch
4195P168200400HEAD PLATE + PLUGS NX/VT
4196P165222104DEFLECTEUR SA NX EA 173
4197P165212104DEFLECTEUR TOLE BPS NX E
4198P148502042GEARS – SET OF GEARS FOR
4199C170607007ASS.EXPANSIBLE TLK 300 D
4200C120722501JOINT TORIQUE DIA.72 X 2
4201C027007008SEAL PACKING 070X090X10
4202C021010005RONDELLE DE RETENUE DIA.
420396702857nut
420495685897CAPSCREW,HEX SOC 1/4SS
420595587937INDICATOR SIGHT FLOW of 1.5
420695320446Steel ball
420795200945LOCKNUT N13 O.D 3.38mth
42089505185012 “gasket
420995018370O-RING 14 X 14-1/2 X 1/4
421094938073gasket
421194938065gasket
421294900768Transition tube 4CI S4
421394587912tube
421494415676CYLINDER 7″ DIA
421570459599RING PISTON 7X9 PHE-9 NL
421670422399RING WEAR – 4.5
421770422381RING PISTON X9 4.5 CFT is
421868113190DIFF-FM,CH6 2CII VANED,D
421967739193Gasket ANSI 14″ 150#
422067651216Radial bearing
422167618553casing
422267506253The DIFF – GE – 3 c S1.3201 E6-2
422349025943SURGE VOLTAGE SUPRESSOR
422447617508001COUPLING TLKS-0500-X088-
422547606393001GASKET KIT CH5XB
422647595905001OIL PRESSURE GAUGE FOR G
422743153295ELASTIC PIN AISI 301 DIN
422839590237VALVE DISCHARGE
422939488713VALVE-THERMOSTATIC
423039486204GASKET FR/OUTER HEAD PHE
423139329313VALVE DISCHARGE
423239316898RING,PACKING
423339169925Conveyor belt of vulcanized rubber
423437982873VALVE SUCTION W/UNLOADER
423537982196SEAT DISCHARGE
423637980422The seat components
423737980414SEAT SUCTION
423837944550PLATE VALVE
423937897998PLATE VALVE
424037794377SEAL OIL CRANK SHAFT
424134578799NUT PISTON
424234004960PLATE DAMPING
424333426917SPRING CLOSING
424433426412SPRING CLOSING
424530589568WASHER LOCK STAR 7 STK
424630565675NUT JAM 7 INCH STROKE
424730562094GASKET
424830508741SPRING VALVE RELIEF
424930427140The oil pump
425030253892COVER SHAFT
425128-88-00-000-0-FFUSED WINDOW SIGHT 3/4-N
425228-67-00-000-C-FAXIAL FAN PM MOTOR CO. #
425324648214Intake valve
42542408379224 “flange ANSI150
425524016123COOLER-AIR C250 STG.3 ST
425624012726COOLER, AIR C250 S2 C35
425723833395Bearing fastener
425823823123Expansion section 12″ 150#
425923743842DIFFUSER HALF GEAR END 4
426023652639C1000 Shaft seal kit S2 S3
426123652159C1000 Plain bearing kit S3
426223652134C1000 Plain bearing kit S2
426322677785Vibration probe
426422571889OIL FILTER CARTRIDGE
426522372411Transition tube C3000 S3
426622027148Bypass expansion joint 8 “150#
426719012459Circuit breaker 2P 6A
426819012442Circuit breaker 1P 4A
426917958534POSITIONER FOR 19SP1431
427017958533POSITIONER FOR 19SP1430
427117934256Bolts & nuts for coupling
427217277278TRANSFORMER STEP-DOWN CS
427324144842Air cooler 3CI
427424017774Three stage cooler 5CII
427523754336Pressure sensor HART
427690127465Anchor bolt
427724776080Cooler SS C950S3
427824577439Temperature control valve SS304
427923530389Large centrifugal filter element
42802475913619SP2918 BV 4″ ANSI150
428147630554001Oil cooling end plate
428222404313The rotor level 5
4283P158502042NX12 Roots blower standard repair kit
428496767009bolt
428596764485Bolt M5X16
428696764469pin
428796764451pin
428896762174bolt
428996761846screw
429096760418Bolt M10X50
429196760251The elastic pin
429296760244pin
429396756556tee
429496756366Right Angle connector
429596743802Flat mat
429696742507bolt
429796741244bolt
429896741210Bolt socket hexagon M10 X 85
429996740865Nut M8
430096740659Bolt M8 X1.25 X40
430196725130Bolt M16x60 LONG
430296717616bolt
430396713367bolt
430495999678bolt
430595991493Pipe joint 2.0″
430695990743Bolt. 38 x. 75″
430795990727bolt
430895990370bolt
430995567319GASKET VALVE SEAT
431095253852The pipe clip
431195210365PACKING,R&S
431295051827gasket
431395023461o-rings
431494943743Non-standard muffler
431594938198gasket
431694938081gasket
431794938057Gasket ANSI 1/2 “150 lb
431894938032Gasket ANSI 1-1/2 “150 lb
431994815099Hexagon socket set screw M10x15-1
432094813573Bearing cover S3
432194812153Gasket ANSI 12 “150 lb
4322947941532 SEC rotor
432394427697ROD PISTON 17 X 9 HSE
432490169715screw
432590148594GASKET KIT 4CI S5
432690125840The nozzle
432785647881SEAL,PUMP SHAFT
432885640472Non-drive end bearing 902-60
432970477005RING-WEARING 4 X 5 ESV
433070476999RING-PISTON 4 X 5 ESV NL
433170459623RING-WEAR
433270459615RING,PISTON
433370459607RING-WEAR
433470452958Double piston rod PHE-7
433570430889RING- WEAR 9
433670430871RING- PISTON
433770430855RING- PISTON 17′”‘
433870334636ASSEMBLY ROD PISTON 7 &4
433970268602Level of China
434070268594First stage crosshead
434168249267IGV body
434268241256bolt
434368232057Diffuser c950 S3
434468225580Diffuser c950 S2
434568215003The MOP ring C3000
434668212752Diffuser C950 S1
434768202985Impeller screw, Grade 1
434868192186Gas water separator CV2 STG3
434968179688Thrust bearing
435068090489Coupling protection cover
435167980524joint
435267970467coupling
435367946665Pinion shaft 4C150 stage
435467904649Big gear 5CII 50HZ LP
435567867549ROTOR-2ACII 2ND 50HZ.7X1
435667844571IMPELLER-MAX CV2 STG.3 3
435767782755Main oil pump support
435867778241Pin 6 mm X 20 mm
435967763508Tee connection pipe
436067739201The gasket
436167728147Clamp connector 10″
436267631192VALVE-CHECK LIQUID 1X489
436367590430Seal cover big gear 5CII
436467582353Coupling protection cover
436567581066Big gear shaft key
436667573196Impeller level 4CI
436767513747RING-INT-DIFFUSER INTAKE
436854577440RING-WEAR-4′”‘
436954503115RING SCRAPPER 2.0 INCH R
437054416417The filter
437154370697First stage intake valve gasket repair kit: 38
437254370663GASKET VALVE SEAT A28
437354365648Secondary intake valve gasket repair kit: 38
437454364104TRANSDUCER,HP, 0-500PSIG
437549199805Diffuser option first stage
437649199714Diffuser first stage
437749196561The tubing
437849196553The tubing
437949137805CMC Control System
438049133259Gear box of 50 hz
438149002819Vibration of cable
438249002801Vibration probe
438349002553Oil level sensor
438449002546Temperature sensor 0-500F
438549002538Differential pressure sensor 0-30psi
438649002520Pressure sensor 0-200psi
438749002512Pressure sensor 0-50psi
438849000912The rotor
438947634202001tube
439047631066001Bearing spare parts
439147618579001ASC components
439247612305001Risheng desiccant 104XFJ201
439347612304001Air source filter core 180LX1379
439447606353pressure transducer
439547597908001OIL COOLER E7094295
439647597747001Rubber ring
439747597746001Rubber ring
439847595904001OIL PUMP FOR GEARBOX MH6
439947595903001OIL SLINGER FOR GEARBOX
440047593938001LOW SPEED GEAR SET MH600
440147593937001HIGH SPEED GEAR SET MH60
440247593267001Low speed drive end bearing
440347593266001High speed non-drive end bearing
440447583238001Cooler copper tube copper fin S1 C100
440547578493001Pipe line
440647578492001Pipe line
440747578491001P[140] Lubricating oil pipeline
440847578490001hose
440947570258001Heater C950
441047566369001Temperature control valve
441147559568001The nose
441247554375001COUPLING-JOHN CRANE TSC-
441347550835001LIP SEAL LUFKIN E9020300
441447549227001Motor C700 {P140}
441546865655Oil inlet hose 1/2″
441646848057Joint M27
441743190503GASKET KIT 2CIIPI S3 N2
441843176874COUPLING 3.500.935-1
441943167873DISCH.VALVE 4′”‘ 2576 DI
442043099134bolt
442143095017The steam trap
442243078658CONDENSATE TRAP BEKOMAT
442343051135Check valve 14″ ANSI 150 H
442442973859GASKET KIT 2ACII 2ND STG
442542973834GASKET KIT 2ACII 1ST STG
442642973495GASKET KIT CV2 3RD STG
442742973479GASKET KIT CV2 2ND STG
442842973453GASKET KIT CV2 1ST STG
442942641183Second stage diffuser option
443042611160Rotor assembly C950 S/A S3
443142608836Rotor assembly – C950 S/A S2 15
443242589861Two stage diffuser option
443342589218ROTOR, 3CIIB SC 50HZ TA
443442587071ROTOR, 3API S3 50HZ 2AS
443542437921Piston rod assembly
443639914791VALVE INLET WITH U/L
443739656202UNLOADER INSIDE OPERATED
443839592688VALVE DISCHARGE HCA 55-3
443939592324VALVE DISCHARGE 7 X 7 PH
444039590278VALVULA DE DESCARGA EXCL
444139550199GASKET FRAME HEAD PHE
444239550090GASKET OUTER HEAD PHE
444339487038COOLER-370PSI
444439331368VALVE,SAFETY-90 PSI
444539323332PACKING,R&S
444639322334RING,PISTON
444739322318RING,WEAR
444839321690RING-PISTON-7′”‘
444939321245RING PACKING,R&S
445039249339SET MATCHED BANDED BLTS,
445139169933Vulcanized rubber transmission belt
445238326898Primary air valve limiter
445337995529Secondary intake valve spool repair kit: 39
445437982907VALVE SUCTION
445537982287PLATE SPRING
445637982279PLATE VALVE
445737982121O-RING
445837982113SPRING
445937981933RING CRUSH
446037980612GASKET
446137980588SEAL
446237980570O-RING
446337980554SPRING
446437163755First stage exhaust valve
446537038064GASKET VALVE COVER
446633426024SPRING CLOSING
446733013889NUT LOCK
446830678452VALVE INLET COMP A28CS1E
446930586127GASKET PACKING CASE
447030551253VALVE DISCHARGE A28CS2EW
447130550842GASKET VLV COVER CU SHRO
447230550636GASKET VALVE COVER 20X11
447330549885GASKET VALVE SEAT
447430336887GASKET PACKING CASE PROC
447524776122Cooler SS 3CIIS3
447624776106Cooler SS 3CIIS1
447724776064Cooler SS C950S1
44782477151112 “intake valve
447924764714Bypass valve 8″
448024721359Protective cover coupling 3ACII
448124688376Cooler CV2 STG3
448224688368Cooler CV2 STG2
448324688350Cooler CV2 STG1
4484246441893 aciidf big gear
448524524811Electric cabinet
448624518763PRESSURE TRANSMITTER 0-7
448724518755Pressure transducer
448824492712Over 2 “NPT
448924474413Large centrifugal bearing
4490244720295CII three stage diffuser
449124314510HSG-PUMP, C950 OIL 50 HZ
449224279648temperature transmitter
449324267429Bearing RTD
449424263972Pressure transducer
449524262974DIFFUSER, MACH 3CII S3
449624144800Air cooler 4C150
449724083743Flange 12 “ANSI150
449824083727Flange 8 “ANSI150
449924054009Temperature sensor
450024034571Expansion joint 12″
450124034381Oil cooler
450224028508COOLER, AIR 2ASB S2 STD
450324027773Cooler core group 3S C1000
450424017758First stage cooler 5CII
450523985120DIFFUSER 5CIIPI 3RD STG
450623948482C3000 three stage cooler
450723948474C3000 secondary cooler
450823948466C3000 stage cooler
450923897465DRY MAIN COUPLING
451023878952Pipe joint 1/4 “NPTXD. 6
451123872864KIT, SS N12 3CIIM3
451223872856KIT, SS N12 2ACIIM3
451323872823KIT, SS N12 2ACIIM2
451423804263SUPPRESSOR TRANSIENT SUR
451523790439Differential pressure switch
451623749823Clamp 8 inches
451723688716OIL COOLER
451823652621C1000 Shaft seal Kit S1
451923652118C1000 Plain bearing kit S1
452023626245Vibration detector 280MM
452123577695Coupling bushing 437mm
452223547029Three stage diversion plate
452323547011Two stage diversion plate
452423547003First stage guide plate
452523542970Air cooler copper tube bundle assembly
452623515265Diffuser S3 stainless steel
452723484371Oil mist separator electrically driven
452823458425Impeller 5CIIPI stage 1
452923447113Adjustable gap gasket group
453023440852gasket
453123421795Temperature control valve
453223417140COUPLING
453323170608VALVE- CONTROL BYPASS 2′
453423148364Big gear shaft seal housing
453523123391Rotor assembly 3CII STG.3 50HZ
453623100654BULL GEAR C950
453723031784Intake valve
453823027089hose
453922970040Rotor assembly STG.1 C700SV09
454022922546Gear coupling
454122847255ROTOR C3000 3RD STG
454222839716Diffuser C700 S3 75%
454322810428FLEXIBLE HOSE
454422724298ROTOR C3000 3RD STG
454522723761ROTOR C3000 1ST STG
454622708622ROTOR C3000 2ND STG
454722690119Three stage diffuser C980
454822678130Diffuser C700 S2 74%
454922677793cable
455022676746diffuser
455122670954Diffuser C700 S1
455222650311diffuser
455322619464Rotor assembly STG. 13 CII
455422613772Rotor assembly 3API S3
455522606719Rotor assembly C3000 class 3
455622605232First stage bushing
455722605224Second stage bushing
455822568653Rotating shaft C3000 class 3
455922557607PINION, MACH 2ASB S1 325
456022557599PINION- 2ASB S3 50HZ 325
456122557573PINION, MACH 2ASB S2 325
456222557532Gear C950 STG.1 50HZ 150
456322541247Impeller, MAX 3CII S2 J210
456422533251Spacer C950 S2 & S3 TAPER P
456522524946Gasket 3 SEC S1
456622516520Rotating shaft C3000 class 1
456722513543Rotating shaft 5CIIB class A
456822493027Gasket rotor 5CII stage 1
456922471304Gear shaft 5CII class 1
457022347256coupling
457122299721DIFFUSER 3RD STG
457222289177Assembling vibration probe
457322238083Impeller -COM CV1B STG2 5-AXI
457422234769IMPELLER, CUT 2CII S1 1
457522227920Nose C3000 class 3
457622099279Converter bridge
457722027304MINI GASKET KIT C950 S3
457822011316DIFF. PRESSURE TRANSM.
457919068261Oil mist separator shell is high
458019055656Cooler gasket II
4581190464163ACII hot connection pipe machine processing
458219045350Control transformer 500VA
458319027820Capacitance 100 u
458419025295Sealed gas pipe 0.5″
458519011568Outlet pipe assembly
458619011501Intake pipe assembly
458718991166Tube Assembly (Oil filter differential pressure meter HP)
458818991158Tube Assembly (Oil filter differential pressure gauge LP)
458917934573Motor bearing
459017934572Motor bearing
459117926286CMC Program Upgrade
459217436833Oil mist separator
459317328378VALVE SAFETY 6010HGM01-K
459417285149VLV SAFETY SET AT 960 PS
459517276841GASKET WATER COVER 6.5c
4596379180Wiring duct 36 ft
459722676787Second stage diffuser
459824684417joint
459923476518The thrust block
460067979609Exhaust expansion joint
460124776114Cooler SS 3CIIS2
4602R015210100KIT, GC135 STD MAINTENAN
4603R015092100NX12 Roots blower standard repair kit
4604P155206902VTB810XL Roots blower tee connection
4605AAP1404961-30060Embrace hoop
4606476482090018″ seal ring Victoria card hoop
460722823694Diffuser C700 S3
460822822290Impeller -CUT C700 S3 85%
460947646252001Channel 14 # B (140 * 60 * 8)
461022696835Vibration probe
461140-01-00-DR0-A-FINLET HEAD SERIES-4, 12
461223780554CMC to Xe-145F PnP kit
461322542526Impeller -COM C700 STG3 5-AXI
461423873037The controller
461547640691001Spare parts, oil filter 47630723001 oil
461647640690001Spare parts package, oil filter 47630723001
461747632868001The pipe
461847632867001Door plank
461947632866001Door plank
46202472401520 “150 # flange
462149109531Refrigeration compressor SZ185
462294590312screw
462394589322The gasket
462467646331GEAR 1CII 2ND 5X108
462547630849001Pressure transducer
462637995511VALVE SUCTION W/UNLOADER
462723914914Coupling cover plate
462822435259Coupling bracket
462922411805Hexagon socket set screws M6X6
463047630851001Temperature sensor
463167651224Thrust bearing
463224662777Thrust bearing 3ACIIDF
4633248731502 inlet air filter
463447557569001[large centrifugal P140] check valve 6″
463547612303001Rear filter core 108LXXX098
463647609823001Oil pump with motor 380V-415V 50H
463724793689Standard filter IRG-66-8H-360
463824793671Standard filter IRG-42-8H-360
463924793663Standard filter IRG-126-8H-25
464024793655Standard filter RG-66-8H-250
464124793648Standard filter IRG-42-8H-250
464224793622Standard filter IRG-126-8H-1
464324793614Standard filter IRG-66-8H-120
464424793572Standard filter IRG-126-15H-0
464524793382Standard filter IRG-66-8D-360
464624793374Standard filter IRG-42-8D-360
464724793366Standard filter IRG-126-8D-25
464824793358Standard filter IRG-66-8D-250
464924793341Standard filter IRG-42-8D-250
465024793325Standard filter IRG-126-8D-12
465124793317Standard filter IRG-66-8D-120
465224793309Standard filter IRG-42-8D-120
465324793275Standard filter IRG-126-15D-0
465415871817Oil removal filter IRG-1800-50H-
465515871809Oil removal filter IRG-1800-50H-
465615871791Oil removal filter IRG-1800-50H-
465715871775Oil removal filter IRG-900-40H-5
465815871767Oil removal filter IRG-900-40H-
465915871759Oil removal filter IRG-900-40H-35
466015871742Oil removal filter IRG-480-25H-7
466115871734Oil removal filter IRG-480-25H-5
466215871718Oil removal filter IRG-480-25H-35
466315871692Oil removal filter IRG-180-15H-5
466415871684Oil removal filter IRG-180-15H-4
466515871676Oil removal filter IRG-180-15H-3
466615871650【C675】 Dust filter IRG-18
466715871643【C675】 Dust filter IRG-18
466815871635【C675】 Dust filter IRG-18
466915871619【C675】 Dust filter IRG-90
467015871601【C675】 Dust filter IRG-9
467115871593【C675】 Dust filter IRG-90
467215871585【C675】 Dust filter IRG-48
467315871577【C675】 Dust filter IRG-48
467415871569【C675】 Dust filter IRG-48
467515871551Dust filter IRG-480-25D-35
467615871536Dust removal filter IRG-180-15D-5
467715871528【C675】 Dust filter IRG-18
467815871510【C675】 Dust filter IRG-18
467915866650【C675】 High pressure cold drying machine D306HP
468015866619【C675】 High pressure cold drying machine D102HP
468115866601【C675】 high pressure cold drying machine D51HP7
468215866270【C675】 High pressure cold drying machine D554HP
468315866262【C675】 High pressure cold drying machine D475HP
468415866247【C675】 High pressure cold drying machine D316HP
468515866239【C675】 High pressure cold drying machine D237HP
468615866221【C675】 High pressure cold drying machine D158HP
468715866213【C675】 High pressure cold drying machine D92HP5
468815866015【C675】 High pressure cold drying machine D2850H
468915865868【C675】 High pressure cold drying machine D499H
469015865835【C675】 High pressure cold drying machine D285HP
469115865827【C675】 High pressure cold and dry machine D214HP
469215865819【C675】 High pressure cold drying machine D143HP
469315865686【C675】 High pressure cold drying machine D1027H
469415865629High pressure cold drying machine D2706HP35A
469515865454【C675】 High pressure cold drying machine D385HP
469615865447【C675】 High pressure cold dry machine D321HP
469715865421【C675】 High pressure cold drying machine D193HP
469815865413【C675】 High pressure cold and dry machine D128H
469915865405【C675】 high pressure cold drying machine D74HP3
470015865397【C675】 High pressure cold and dry machine D36HP3
470115865116【C675】 High pressure cold drying machine D636HP
470215865074【C675】 High pressure cold drying machine D405HP
470315865066【C675】 High pressure cold drying machine D347HP
470415865058【C675】 High pressure cold drying machine D289HP
470515865041【C675】 High pressure cold drying machine D232HP
470615865033【C675】 High pressure cold drying machine D173HP
470715865025High pressure cold drying machine D116HP30A
470815865017【C675】 High pressure cold and dry machine D67HP3
470915865009【C675】 High pressure cold and dry machine D32HP3
471015871726Oil removal filter IRG-480-25H-4
4711AAA3793923-06062Cooler assembly
471224886343coupling
471324886335coupling
4714C1000S01C1000-1st Dynamic balance S140
471523826472At the top of the panel
471623818461The door on the left side of the
471768156462Retainer CV2S1
471868156421Retainer CV2S2
471922853253Impeller CUT C700 SV41
472046851622Control transformer 1000VA
472149159254LOVEJOY COUPLING C700
472249159247LOVEJOY COUPLING C700
472347620276001Pressure sensor 105CGQ085 MEAS
472447620270001Drain valve 104ZJF301 1/2′
472547620268001Valve position feedback 104XWKG203 KP
472647620243001Muffler 104XYQ102 3/4′
472747620225001Two position five-way solenoid valve 104EWTF106
472847620205001Blower suction filter 104GFJPJ
472947620177001Inner bladder of electric heater 106JRQD183
473047620172001Pneumatic butterfly valve 104QDDF57 DN125+
473147620098001Control air source filter element 108LX1
473247621203001Dew-point meter
473347621201001Temperature sensor
473447621197001Two five way solenoid valve
473547621192001Porcelain ball
473615476757Precision water system scale remover :SE0
473715476765Water system rust and scale remover (D99)
473868244771Three stage diffuser
473924876690Solberg electric oil mist separation core
4740AAA3793923-06061Cooler assembly
4741AAA3793923-06051Cooler assembly
4742AAA3793835-57710Rotor assembly. Ta6000.2-end
4743AAA3793835-56710Rotor assembly. Ta6000.1-end
474423433220SHIM 3 SEC S2S3 3.716 MM
474523433212gasket
474623433204SHIM 3 SEC S2S3 3.419 MM
474723433196gasket
474867931063joint
4749AAP3404090-00134KIT.SEAL.PUMP
4750AAP1403601-01128Diaphragm of main motor coupling
4751AAMB800070-00600Cooler maintenance bulk material
4752AAMB796119-00600Fourth stage intercooler repair kit
4753AAMB792320-00600Cooler maintenance bulk material
4754AAMB409847-00600Cooler maintenance bulk material
475547610620001Positioner, bypass valve
475647615780001Non-standard filter
475747612937001The meter on the self-cleaning filter is inflated
4758AAMB794340-00002MSG Rotor assembly hydraulic tool kit
475947577785001Large centrifugal oil filter element
476047549402001[P674] Heater 30KW
476147611136001Muffler 104 xyq106
4762AAP3793119-00134Auxiliary oil pump coupling
476347553397001Oil cooling water hose
476476505720ELEMENT.FILTER
476524876682Solberg electric oil mist separator
4766AAA3408596-06001IGV drive assembly
476719047554HUADA motor 600 HP / 380 v
4768AAP1407030-00025Vibration probe element
4769AAP1405680-00012Gasket for oil cooler
4770AAA3797125-00005O bar in gear box
477123486509Diffuser S2
4772AAP3404090-00125KIT.SEAL.PUMP
4773AAP1401428-09050PUMP.OIL.PD
477424356495Standard filter FA30ID
477524232159Standard filter FA190IA
477649073075Person D342INRI – A
477749110729Standard drying machine HCR6H ZP D
477849110620Standard drying machine HCR6H D
477949073067Person D294INRI – A
478049073042Person D108INRI – A
478149073034Person D72INRI – A
478249029242Standard suction dryer DM312IER D
478349029234Standard suction dryer DM282IER D
478449029135Standard drying machine DM312ILR D
478549029127Standard cold drying machine DM282ILR D
478647545761001Micro thermal regeneration adsorption dryer _D31
478747545760001Micro thermal regeneration adsorption dryer _D28
478847545759001Micro thermal regeneration adsorption dryer _D21
478947545758001Standard post-processing _D126IERI40
4790
479147545757001Standard suction dryer D72IERI40
479247545740001No heat regeneration adsorption dryer _D31
479347545739001No heat regeneration adsorption dryer _D28
479447545738001No heat regeneration adsorption dryer _D21
479547545737001No heat regeneration adsorption dryer _D12
479647545736001No heat regeneration adsorption dryer _D72
479724489775High pressure drying machine D126IHPD360
479824489767High pressure drying machine D66IHPD360
479924489759High pressure drying machine D42IHPD360
480024489742High pressure drying machine D126IHPD250
480124489734High pressure drying machine D66IHPD250
480224489726High pressure drying machine D42IHPD250
480324489718High pressure drying machine D198IHPD120
480424489700High pressure drying machine D126IHPD120
480524489692High pressure drying machine D66IHPD120
480624489684High pressure drying machine D42IHPD120
480724489650High pressure drying machine D126IHPD080
480824489585High pressure drying machine D126IHPD055
480924489577High pressure drying machine D66IHPD055
481024489510High pressure drying machine D126IHPD035
481124356511Standard filter FA30IH
481224356487Standard filter FA30IA
481324349607Standard filter F216IU D
481424349599Standard filter F150IU D
481524233124Standard filter FA110IG
481624232274Standard filter FA230IG
481724232258Standard filter FA230ID
481824232233Standard filter FA230IA
481924232217Standard filter FA190IH
482024232191Standard filter FA190IG
482124232175Standard filter FA190ID
482224232134Standard filter FA150IH
482324232118Standard filter FA150IG
482424232092Standard filter FA150ID
482524232076Standard filter FA150IA
482624232027Standard filter FA110ID
482724232001Standard filter FA110IA
482824231938Standard filter FA75ID
482924231912Standard filter FA75IA
483024231896Standard filter FA40IH
483124231854Standard filter FA40ID
483224231821Standard filter FA40IA
483319049535D350IL non-thermal adsorption dryer
483415866627【C675】 High pressure cold drying machine D153HP
483595106548tee
483668185362The pipe
483767929679Connect the head
483847586142001High efficiency heat exchanger C950 stage
483940049942Unloading solenoid valve
484018998054Pins for baseboard ports
484118998047Baseboard signal receiving socket 4 lines
484296740832Nut M6
484368061407Bolt socket hexagon M6X45
484447547238001Micro thermal regeneration adsorption dryer _D31
484547547237001Micro thermal regeneration adsorption dryer _D28
484647547236001Micro thermal regeneration adsorption dryer _D21
484747547235001Micro thermal regeneration adsorption dryer _D12
484847547185001No heat regeneration adsorption dryer _D31
484947547184001No heat regeneration adsorption dryer _D28
485047547183001Blot machine D216ILRI20
485147547182001No heat regeneration adsorption dryer _D12
485247547181001No heat regeneration adsorption dryer _D72
485324356503Standard filter FA30IG
485424231870Standard filter FA40IG
485523693856Standard cold drying machine D360INA D
485623693849Standard cold dry machine D300INA D
485723693831Standard cold drying machine D240INA D
485823693815Standard cold drying machine D144INA D
485923693781Standard cold dry machine D54INA D
486023693773Standard cold drying machine D42INA D
486123693765Standard cold drying machine D25INA D
486223693757Standard cold drying machine D12INA D
486319049527Standard suction dryer D275IL D
486419049501D150IL non thermal adsorption dryer
486523569346Sealing ring
486623600588Auxiliary oil pump 380/440 V 50/60
486724231953Standard filter FA75IG
486847580181001Selected switch
486967872333The center pipe
487067872325The center pipe
487167777953The cap
487223601719shell
487323586761shell
487422421903Cover oil tank gold processing
487594761749Metal hose
487647577326001108 lx1004 filter element
487796734025Bolt M22 * 80
487867766014Anchor bolt
487967835702COLLAR – TH – THRUST CH6.3 X1
488022575419Gasket rotor C3000 class 1
488196720172Bolt M8 X 20
488247562662001The filter element
488349110158Expandable filter CD2203
488449110018Expansion valve TER35N
488537034931Primary intake valve seat repair kit: 38
488623433055gasket
488723433048gasket
488823433071gasket
488923433063gasket
489024019945gasket
4891C9500003C950-3 rd of dynamic balance
4892C9500002C950-2 nd dynamic balance
4893C9500001C950-1 st of dynamic balance
4894C7000003C700-3 rd of dynamic balance
4895C7000002C700-2 nd dynamic balance
4896C7000001C700-1 st of dynamic balance
4897C4000002C400-2 nd dynamic balance
4898C4000001C400-1 st of dynamic balance
4899C3000S01C3000-1st Dynamic balance S140
4900C3000003C3000-3 rd of dynamic balance
4901C3000002C3000-2 nd dynamic balance
4902C1000003C1000-3 rd of dynamic balance
4903C1000002Centrifugal balance
49046CH000016 ch 1 st of dynamic balance
49055CII00035 SEC (B) – 3 rd of dynamic balance
49065CII00025 SEC (B) – 2 nd dynamic balance
49075CII00015 SEC (B) – 1 st of dynamic balance
49085CH000015 ch 1 st of dynamic balance
49094CI000054 ci – 5 th dynamic balance
49104CI000044 ci – 4 th dynamic balance
49114CI000034 ci – 3 rd dynamic balance
49124CI000024 ci – 2 nd dynamic balance
49134CI000014 ci – 1 st of dynamic balance
49143CII00033 SEC (B) – 3 rd of dynamic balance
49153CII00023 SEC (B) – 2 nd dynamic balance
49163CII00013 SEC (B) – 1 st of dynamic balance
49173CI000053 ci – 5 th dynamic balance
49183CI000043 ci – 4 th dynamic balance
49193CI000033 ci – 3 rd dynamic balance
49203CI000023 ci – 2 nd dynamic balance
49213CI000013 ci – 1 st of dynamic balance
49222CV000032 CV – 3 rd of dynamic balance
49232CV000022 CV – 2 nd dynamic balance
49242CV000012 CV – 1 st of dynamic balance
49252CII00032 SEC – 3 rd dynamic balance
49262CII00022 SEC – 2 nd dynamic balance
49272CII00012 SEC – 1 st of dynamic balance
49282ACII0032 acii – 3 rd dynamic balance
49292ACII0022 acii – 2 nd dynamic balance
49302ACII0012 acii – 1 st of dynamic balance
49311CV000021 CV – 2 nd dynamic balance
49321CV00001CV – 1 st of dynamic balance
49331CII00021 SEC – 2 nd dynamic balance
49341CII00011 SEC – 1 st of dynamic balance
49351ACV00021 acv – listed 2 nd dynamic balance
49361ACV00011 acv – 1 st listed dynamic balance
49371ACII0021 acii – 2 nd dynamic balance
49381ACII0011 acii – 1 st of dynamic balance
49390CV000020 CV – 2 nd dynamic balance
49400CV000010 CV – 1 st of dynamic balance
494196741715Double end stud M20X150
494224231987Standard filter FA75IH
4943679796253 inch expansion joint
494422509640Flange tubing S2 TO S3
494567863688The rivet
494624252777Pressure sensor 0-500 pSIG
494795720330Cooler gasket
4948A050910350Empty filter
494996760137Right Angle bend
495023703291Bypass valve DN150 PN10
4951SLT10024Rear cooler KLQ388.4
4952SLT10021Self-cleaning filter RH-600 contains present
495368114693Applique warned
495467878793Plug 1.313″
495567561183Flange 3″
495667559039Flange 8″
495739132279Conduit. 75. “”
495819058080applique
495918994327Hair with double stud bushing
496018993972Desiccant 0.5 Kg
496118990432Decal Warning (Chinese and English)
496218989301Seal wire
496318989293seal
496418982298Large gear locking label (Chinese)
496518982280Desiccant Label (Chinese)
496623356553bolt
496795720314o-rings
496823584071o-rings
496922738819Vibration probe
497049161383Centrifuge service wrench set
497185564516F71IH 042SCFM-BSPT filter
497295452215Inner and outer wire joint
497396764170o-rings
497496764162o-rings
497596764154o-rings
497696742499Screw machine screw M4 X 10 FSHC
497795946174Pipe joint
497895934923gasket
497995420279Retaining ring
498095135505Retaining ring
498195051843gasket
498295051835Gasket 8.0″
498395023172o-rings
498495023081o-rings
498595021812o-rings
498695008215O-ring 7X7-.25 X.12
498794789542ROTOR 2CII S3
498894572948GASKET KIT 3ACII 3STG
498994523685Flexible Hose
4990944754805″ flange gasket
499190171778Gasket 6.0″
499285687028KIT-PARTS- OVHL- C250
499368250372Gaskets main pump
499468249671Gasket nose cover
499568245158Two stage diffuser
499668244557Three stage diffuser
499768209931Take over NPT2″
499868209303INSERT-BRG,FLEX-S2-NITRO
499968209139SEAL – AIR/OIL, DCC S2, 3 NI
500068198654SEAL-BOLT,6MM NOM I.D.
500168187525DIFF-FM,C950 S1 2API94
500268185263First stage nose
500368184233Lubricating oil hose
500468106657Control the intake valve
500568104280Bypass valve
500668099027IGV intake valve
500768088566Intake valve
5008679795918 “expansion joint
500967952572Air intake filter differential pressure switch
501067940460Hose Assembly 1.0 X 46″
501167923250Blind flanges
501267903336Hose Assembly 1.0 X 51″
501367903138hose
501467901025Hose Assembly 1.25 X 30″
501567893958Sliding bearing
501667881938Bolt socket hexagon M6X30
501767829317seal
501867792945Oil pump without drive
501967746834Adjustable gap gasket
502067739128The gasket
502167728139Clamp connector 8″
502267693838Bypass muffler
502367671586Thrust bearing 3CI-4CI
502467671578Thrust bearing 3CI-4CI
502567649632Seal nitrogen 4CI S1
502667590299Reverse thrust bearing big gear 5CII/B
502767590042O-ring bushing ID41.227″
502867589994Gasket thrust bearing cover
502967585851Pin 3 mm X 10 mm
5030675609954 ‘flange
503167515973Low oil level switch
503267504944Seal gas 3 ci ci – 4
503354766712SEAL OIL SHAFT 5.00 X 6.
5034490552392 “joint
503543151653u-bolt
503642973313GASKET KIT 4CI-4C150
503742900068GASKET KIT 3C S4 NO/SIL
503842608810Rotor assembly C950 S2 50 HZ
503942591446Rotor assembly 2ND STAGE 3CII
504042589283Rotor assembly STAGE.3
504142531178ROTOR,S/A C250 S3 50HZ
504242531152ROTOR,S/A C250 S2 50HZ
504342531137ROTOR,S/A C250 S1 50HZ
504438440947PNLD control line assembly
504538326880Primary intake valve spool repair kit: 38
504637189669ROD CONNECTING 11 STK
504730203384BUSH X HD PIN 11 STK
504830203335BUSHING CRANK PIN 11STK/
504924822066cooler
505024784340VALVE ACTUATOR BRAY S93
5051247784253 “by-pass valve
505224764029ELECTROPNEUMATIC POSITIO
505324680431Auxiliary oil pump motor
505424575334THERMOSTATIC VALVE
505524366924Temperature transmitter
505624186082Flange 8 “ANSI300
505724054033Temperature sensor
505823856495The auxiliary oil pump
505923854862IMPELLER,3CII STG-3 50HZ
506023834443GASKET KIT 2AHP 3ST
506123777402The tubing
506223777196The tubing
506323772106Air cooler C1000 STG2
506423772098Air cooler C1000 STG1
506523653058The tubing
506623646870FLEXIBLE HOSE ‘1.25 “‘ O
506723618408Adapter flange
506823599632coupling
506923590847The tubing
507023590839The tubing
507123557689Connecting pipe
507223552896coupling
507323539786Oil filter assembly
507423499940Exhaust valve 6″
507523479967Oil cooler
507623457690Radial bearing 5CII S3
507723449812Sliding bearing
507823449796Sliding bearing
507923449770Sliding bearing
508023408990The relief valve
508123273816OIL COOLER
508223235831COOLER, AIR MOD 3C RIVET
508323164692Oil cooling support
508423131212ROTOR C3000 3RD STG
508523130503Rotor assembly C3000 class 1
508623064231OIL COOLER 3 ACII
508723033145rotor 5CII
508823025828Multiphase ac motor
508922933329Metal hose
509022933022hose
509122921407Diffuser S1 3CII
509222910186diffuser
509322839419Impeller CUT CC700 STG.3
509422824155SEAL KIT 3RD STG
509522824148SEAL KIT 2ND STG
509622824130SEAL KIT 1ST STG
509722815476Diffuser C700 S2 95%
509822801070Thurst Bearing 3CI 4TH
509922800981FLEXIBLE HOSE
510022795207Rotor assembly STG.1 C700SV22
510122783328Impeller -CUT C700 STG.2
510222698013VALVE, CHECK GAS 10′”‘
510322676894diffuser
5104226126263ACII 3RD STG ROTOR
510522608202Rotor assembly 3CII STG.2 50HZ
510622575435Gasket rotor C3000 class 3
510722569602Metal hose
510822533418IMPELLER, CUT 2ACII S3,
510922524953Gasket 3CII S2 & S3 TAPER
511022515431Rotor assembly S/A C700 S2 125
511122515423Rotor assembly STG.1 C700-SV31
511222435580VALVE- CONTROL BYPASS
511322425029Four stage diffuser
511422409312Sliding bearing
511522373567BEARING-BG C250 COMPR. S
511622369540COUPLING POP
511722271639Thrust ball bearing
511822271621BEARING-TH-FIXED/TAPERED
511919068279Oil mist separator housing low
512019032929Rolling bearing 6220C3
512119002880Hose assembly pipe inner diameter 1″ total length 31
512217283698Shaft seal spindle alloy steel
512316527533The oil pump
512416510307SWING CHECK VALVE 2′”‘NP
512516510281The SWING CHECK VALVE 1.1/2 ‘
5126465922hose
5127379131Wiring duct 18 ft
5128379073Wiring duct
5129304402ROTOR-4C150 S2 50HZ FE 7
513095038147Inside and outside the joint NPT3/8 – NPT1/4
513119025568C700 probe takes over 3S
513249002439Bearing temperature measurement RTD Teco
513349002421Bearing temperature measurement RTD Teco 3W955C
513467675959Nose bolt 3CI-4CI
513567504852Nose bolt
513623686873Spindle oil pump seal
513722953590Rotor assembly STG.3 C700SV22
513819002880Hose assembly INNER diameter 1″ total length 31″
513995950341Inner and outer wire connector 1.50″X1.25″
514095156410O-ring 16 X16.38 X.188
5141232181342CV secondary air cooler core
514222SP1877Pressure transmitter
514324518748Pressure transmitter
514495160123o-rings
514595156394o-rings
514695000139o-rings
514768242684Three stage diffuser vortex ring
514867798744Impeller nose
514967536896Impeller nose
515067505057Impeller nose cap
515185646842BODY-2′”‘ VALVE
515285647667switch
515368237338Large gear shaft seal assembly
515468237346The secondary shaft seal
515568237353SEAL,AIR/OIL DCC S1
515668237379Two-stage front bearing
515768237387PLN,BEARING C250/350 S1
515868226216KIT-GASKET, C350 3S-3C
515968212489Gasket assembly MAXI 3S-3C C250
5160488643KIT-VALVE-CONTROL-INLET
5161488593KIT-POSITIONER-VALVE C23
5162488536KIT-VALVE-CONTROL-BYPASS
5163468520KIT-OIL PUMP-OIL PUMP 2A
5164416834KIT-BEARING-TH-2CV/2CC 3
5165416826Sliding bearing
5166416818KIT-BRNG-TH-2CV/2CC 2ND
5167416800Sliding bearing
5168415729Three-stage rear bearing assembly
5169400531Three-stage front bearing
5170400606Two-stage front bearing
5171400614Bearing assembly
5172278523Level 2 seal
5173264713KIT-SEAL-DBL-LIP CV1 C19
5174264721Vulcanized rubber seals
517567947770KIT-B/G SEAL-DBL LIP-3 C
517667937292KIT,GASKET,3CII 3STG BOO
517767910562Vulcanized rubber seals
517867841056gasket
517967834614Mechanical seal
518067791152Double rear bearing
518167791145Three-stage rear bearing
518267777896KIT-GASKET- CH6 C1762
518367765842KIT-BEARING-TH-2ND STG C
518467765859KIT-BEARING-PLN-2ND STG
518567768473KIT-BEARING-PLN-1ST STG
518667750752Secondary seal
518768242601Triple seal
518867696187Service seal assembly
518967658120KIT,GASKET,5CII-MAXI
519067611681KIT-GASKET-MAXI-FII-DF-2
519167603670Seal assembly
519267501346KIT,GASKET,C110/1
519367501338Service seal
519422757850OIL MAIN PUMP POP-MOP 2C
519522743959Pump auxiliary belt drive
519622675201ELETTROPRELUBE 50HZ
519717047788The main oil pump
519816527574The main oil pump
519980279847Pump belt drive
520022274542Gasket Kits Gasket Kits
520116515355DOUBLE OIL FILTER KIT
520243197623GASKET KIT CH6 W/SEAL K
520343199306GASKET KIT 4CI S5
520443199181GASKET KIT S1-4 N2
520542969436Complete seal assembly
520642935148Gasket package 5CII S3
520794517372KIT DOUBLE OIL FILTER
520894530979GASKET KIT 3ACII 3ST
520994796232KIT OIL FILTER ELEMENT
521094866936GASKET KIT CV1A S2
521194535739Full set of sealing assembly 3CII
521290170887Gasket Kits Gasket Kits
521390151986Vent valve maintenance kit
521490148222Full set of sealing assembly 3CI
521515641707DIFFUSER C3000 2ND STG
521622027833DIFFUSER 3API 3RD ST
521743154541Rotor Assembly 6CH
521822403232Rotor assembly S2
521994528585Level 3 shaft seal
522094794377The rotor
522194794237ROTOR 2CII 1ST STG
522290147521SEAL KIT 2CII 2ST
522390147455KIT SEAL AIR/OIL STG-1
522467512624Diffuser cover plate
5225290221ROTOR-2CII S3 50HZ 8X157
522667551044Diffuser cover plate 3CI-4CI
522767995183HSG-BRG-PLN 2ACII S3 325
522867645929Diffuser 4CI S4
522967677807The HEAD – MACH FRIII S1.8 X105
523042989509The auxiliary oil pump
5231675133093 ci ci – 4 oil seal
523267668038Sliding bearing
5233402115ROTOR-3CII S3 50HZ 2A2 7
523467719492ROTOR-4C90-5TH-50HZ.7X31
523568131580Nose C700 HOT STG3
523668191659SEAL-BG-OIL DCC250/350 7
5237681876732 asb cooler
523868191626SEAL-AIR-OIL-DCC 250/350
523968191642The primary shaft seal
524068188317Big gear
524168188358Large gear bearing, main engine side
524268196559Thrust ball bearing
524368196567BEARING-TH-FIXED DCC250
524468196575Thrust ball bearing
524568196583BEARING-PLN-FIXED C250 7
524668196591BEARING-PLN-FIXED C250 7
524768196609BEARING-PLN-FIXED DCC250
524868196617ADAPTER-PROX-PROBE DCC
524968176965Back plate of diffuser
525068167170Diffuser S3 3CII
525168167113Diffuser S2
5252462747ROTOR-3API S2 50HZ 2API
5253460568ROTOR-3CII S2 50HZ 45MM
5254460477ROTOR-3CII S1 50HZ 55MM
525568157080First stage plain bearing
525668121532Diffuser S1
525768178136ROTOR-CV1B S2 77% 50HZ *
525868080530CVR-DIFF-4C S4 2A2100-CV
525968047299BUSHING, TILT PAD
526068051432DIFFUSER MACHINING (2ACI
526168051424VANEPLATE 4C STG.3 2A
526268104116LINEBORE-SAE
526368030196HEADMACH 6CC/CH6
526467965756VANEPLATE – 3 c S2 2 a1112. 7
5265242792BRG THRUST 3A S3
526667905810BEARING-PLN-3CIIB3PLN 2&
526767905802Plain bearing 3CIIB
526867884189BEARING-BG-2ACII-325# TH
526967874628Sliding bearing
527067869958Sliding bearing
527167903757Big gear
527267818989Diffuser cover S1
527367833871ROTOR-2ACII 2ND 50HZ 7X1
527467834002Air compressor accessories – rotor
527567802603Large gear and shaft assembly
5276677820943ACII Hothead Secondary and tertiary connections
527767907519gear
5278454884Third stage rotor assembly
527967792580The big gear set
528067771741IMPELLER,4C100 1ST K409X
528167768713CR-OVER-CROSSOVER CV1A.7
528267771824Cast iron inner ring for three stage diffuser
528368223460Rotor assembly -C950 S1 50HZ 94
528467768945RING-INT-MACH CV2-31 3RD
528567773002Cast iron inner ring for secondary diffuser
528667773010Two stage diffuser inner ring
528767754234Big gear assembly
528867678052Gas seal casing
528967688309Thrust bearing
529067582064Gas seal casing
529167582106Thrust ball bearing
529267582163Radial bearings for large gears
529367582213Sliding bearing
529467512335Gasket oil pump
529567512392Four-stage diffuser diversion tube
529667512376Two stage diffuser diversion pipe
529794847837MAIN OIL PUMP
529868242569Three stage diffuser
529967804229Stage 2 diffuser
530067769273Diffuser CV1 – S1
530195336921Joint sensor
530222742670Temperature transmitter
530322671333PRESSURE TRANSMIT. 0-25
530415646490Pressure transducer
530567528737Sealing gas 3CI-4CI S5
530668008366DEMISTER,2CFM ELIMINATOR
530767976845Coupling bushing
530867968016Coupling liner
530967968024Coupling bushing
531067508275Sliding bearing
531167653048Sliding bearing
531267654335Sliding bearing
531367643205seal. air&oil
531467643213Steel seals
531567638981Sliding bearing
531667637421Sliding bearing
531767629196Seal stop ring 5CII S2-S3
531867612929Big gear bearing
531967606418Sliding bearing
532068137603Water gas separator STG2
532168137595Water gas separator STG1
532268147313Nose end bolt impeller
5323680854305 x16153 shaft seal
532468080555DIFF-ASM-4C S4 2A2100-DI
532568080571IMPELLER-CUT 4C S4 2A210
532668074715BEARING-TH,ASSY CV1B-S2
532768071133BEARING-PLNASSY CV1B-S2
532868076470BEARING-PLNASSY CV1B-S1
532968056787ASSEMBLY THRUST BEARING
533068037647Air compressor accessories – components
533168051440IMPELLER-CUT 4C S2 5X158
533267514372Sliding bearing
533368017490Sliding bearing
533468017482BEARING-THASSY 2A 325#
533568017474BEARING-TH-ASSY 2A 325#
533668015981Sliding bearing
533767996322IMPELLER-CUT 4C-S4 CV2S1
533867995175Steel threaded bearing bush
533967995209Sliding bearing
534067995217BUSHINGTPJ MACH 2AS1-32
534167929133Seal stop ring 5CII S1
534267909614Gasket – Waffle
534367882498IMPELLER-CUT 4C 3RD 2A19
534467854265Sliding bearing
534567854257Sliding bearing
534667845982Sliding bearing
534767839787Gear – Cv2-125 # S3 50HZ 5X
534867839761Gear -CV2-125# S2 50HZ 5X
534967839332Gear – Cv2-150 # S3 50HZ 5X
535067840579GEROTOR CH5 CH.5X13478
535167841734Sliding bearing
535267834812BEARING-PLNASSEMBLY CH6
535367834978BEARING-THTHRUST CH6
535467819052Radial bearing 4CI S1 TPJ
5355677988503ACII Hothead three-stage nose
535667507699Sliding bearing
535767771766TUBE-TRN,4C S3 2ACII
535867771782IMPELLER-CUT 4C-S3 73% 2
535967763235Radial bearing
536067763227Radial bearing
536167757997Transition tube C700 S3
536267751487IMPELLER-CUT 4C-S3 112%
536367766691SEPARATOR MOISTURE STG 3
536467766683SEPARATOR MOISTURE STG 2
536567766675SEPARATOR MOISTURE STG 1
536667750539Sliding bearing
536767750554Radial bearing 4CI S4 TPJ
536867727909Four-stage front bearing
536967718916IMPELLER-2ACII S3 130% 5
537067700401Radial bearing
537167685487Third stage water gas separator
537267683458Second stage water gas separator
537367677658Thrust ring STAGE 1 5X11294
537467676593Radial bearing 3C S5 TPJ
537567677781First stage water gas separator
537667676601Radial bearing 3C S1 TPJ
537767677716Gasket – Waffle
537867662049Reverse thrust bearing 3C 4C S5
537967650036Seal nitrogen 5CIIB
538067651265Sealed gas – oil 3CIIB
538167543918SEAL AIR-OIL_2CII-1ST_SE
538285688539Sliding bearing
538395256533tee
538422677744VIB.TRANSMITTER SHINKAWA
538516524001TRANSMITTER VIBRATION X/
538615646987The sensor
538780282874PROBE VIBRATION RAM 3300
538843009190Vibration probe
538942964791PROBE BENTLY AXIAL 4248S
539042951376Sensor extension cord
539142951350PROBE VIBRATION BENTLY N
539242951335Vibration sensor
539316525107FLEXIBLE HOSE 1-1/2′”‘
539416525081FLEXIBLE HOSE 2″ L=1110
539516518326COUPLING M.O.P.
539616563751Bypass valve body
539767559823GASKET,COUPLING F-3
539867541391Thrust washer 3CI-4CI
539967544718Thrust block 3 ci – 4 aci
540067531079gasket
540168182286The main oil pump
540268172626The main oil pump
540367544114SEAL AIR 2CII STG.1
540467544122SEAL OIL 2CII STG.1
540568116102The flange gasket
5406376921Probe to take over
5407379156Wiring duct 24 ft
5408379149Wiring duct 20 ft
5409379099Wiring duct – 14 ft
5410379081Wiring duct to 12 ft
5411355792Check valve 1.25″
541267544080Small centrifugal thrust block
541367971531COUPLING-DRV-HUB.3X3991
541467969840Motor end coupling
541567970418COUPLING-DRV,HUB
541667978593COUPLING-DRV-PHENOLIC H3
541767978577COUPLING-DRV-PHENOLIC H2
5418681668752 s1c exhaust valve
541968166867Check valve 6″ 3X30028
542067707430VALVE CHECK 3-CENT 1A/CV
542167662460Air seal
542267662452SEAL,N2-3CII LP STG 1
542367649624Seal nitrogen 5CII S2 S3
542467649616Seal nitrogen 5CII S1
542567640599Inner ring seal 5CIIB
542668090208o-rings
542768027259Thrust ring CV1B STG. 13 x 1268
542867977751BOLT – ROTOR – 3/8 x5 SOC. 50
542967836908Rotor leading edge cone 3CII S3 3X119
543067811547The thrust ring 2 a – 150 #. 3 x11709
543167783647Thrust ring MODIF. 3X11542
5432677587223S2C three-stage connection pipe
543367766667Gasket CV2 S1
543467761908Impeller bolt STG. 2 3/8″ X 4
543567762179Impeller gasket
543667767723Tie rod
543767695841Impeller nose
543867670349COLLAR-TH-THRUST 2CII1ST
5439676681945 ciib nose ring
544067687806The thrust ring C950/2 acii
544167661975Thrust gasket 3CI-4CI
544267659748COLLAR THRUST 2CII STG.3
544367658757Steel tapping screws
544467645077Steel tapping screws
544567645093Square head screws of steel
544667677955o-rings
544767677971o-rings
544867627083Impeller bolts
544967622803Water gas separator 5CII S2 after
545067622811Water gas separator 5CII S2 front
545167622852Water gas separator 5CII S1 after
545267622860Water gas separator 5CII S1 front
545367580894The gasket
545467587311Bearing cover gasket
545567581108Large gear bearing cover gasket
545667573535Seal nitrogen 3CI-4CI
545767590091Steel bolt
545885667582RING- MOTOR OIL.3A236C02
545985667574bearing
546085668754SEAL- BEARING DE/ODE 3A2
546167739268Gasket 3.0″
546267739284The gasket
546367739219The flange gasket
546485671154Main oil pump oil seal
546567506287Air compressor accessories – diffuser diversion pipe
546624360166seal air switch
546795990735The plug
546867514067Fixed clip vibration probe
546967514174Variable diameter set
547090136607Oil heater
547142958371WATER/OIL COOLER
547294761400Oil cooler
547394812369Level 3 impeller
547416563702COUPLING
547594775772COUPLING CV2/C700
547694895497Stage 3 condensation net
547794895430Stage 2 condensation net
547894895372Stage 1 condensation net
547994571296coupling
548043142983Coupling 3ACII (MM400)
548194786688Coupling 2 acii
548295647194COUPLING-DRV,FLEXIBLE
548323398472Temperature transmitter
548417042375AUXILIARY TRANFORMER
548523027147Air switch
548623341324FOUR RELAY MODULE
54871034768CABLE-EXTENSION B/N.2790
548895533543pin
548923575038PNEUMATIC ACTUATOR SR60
549023458912Oil pump bearing and seal 24SP5222
549117052044BOLTS KIT 3.500.933 X
549222703573Sealed air regulating valve
549343120914Sealing gasket for main oil pump
5494148239DIFFUSER-ASM-3C47-1ST 24
549567504068Diffuser 3C S1
549624518730Pressure transducer
549722629158Diffuser C700 S1
549822907265Gasket rotor C3000 class 3
549922907257Gasket rotor C3000 class 3
550022907240Gasket rotor C3000 class 3
550122907232Gasket rotor C3000 class 3
550222547699Diffuser C700 S3
550322227482ROTOR 3CI 5?   STG
550422227441Rotor 3 ci S1
550567503581GASKET-GASKET-COOLER 216
550667503573GASKET,CASE-TO-COOLER
550767503565GASKET,CASE-TO-COOLER
550867503557GASKET,COOLER-TO-COVER
550967503508GASKET-GASKET-COOLER.215
551067503490GASKET,CASE-TO-COOLER
5511图号The name of the
551267503433GASKET-COOLER-TO-COVER 2
551367503383WASHER-THRUST 2120B6-1
551495211645O-rings ID28 X0.25 “”
551595332961O-rings ID19.5 X0.25 “”
551695041760O-RING,14-1/2X15X3/16
551795030342O-rings ID14 X0.25 “”
551895041448O-rings ID10.5 X0.25 “”
551995023982O-rings ID9.0 X0.25 “”
552095027843O-rings ID7.75 X0.25 “”
552195026993O-rings ID5.5 X0.188 “”
552295026951o-rings
552395041927O-rings ID9.5 X0.125 “”
552495024022o-rings
552595044772o-rings
552695022398o-ring
552795915682O-RING 20A11EM167
552895023164o-rings
552995028809o-rings
553095210290o-rings
553194677994Pressure gauge
553280275381MAIN OIL PUMP COUPLING 2
553342983973Metal hose
553494762184FLEXIBLE HOSE 1.7/16 ‘”‘ X
553543151992OIL PUMP
553643010453FLEX.HOSE 2 L=600′”‘
553794905783THRUST BEARING 3CI-4CI
553894899119FINAL DEMISTER CV1 S2
553994899051PRIMARY DEMISTER CV1 S2
554094898996FINAL DEMISTER CV1 S1
554194898939Oil mist filter
554242956508Screw diffuser
554390171018The valve device
554494500352ACTUATOR PNEUMATIC BLEED
554590145046Gasket 4.0″
554667728121Clamp connector 6″
554767722041RTD-W/O TRANSMITTER.1X83
554867731182ELEMENT, INLET AIR FILTE
554967500892Filter parts – filter element
555067700260PUMP-OIL,WITHOUT DRIVER
5551675404271*60 vibration probe
555267654343coupling
555367654350COUPLING-DRV-NUTS & BOLT
555467654418The coupling comes with screws
555567654368COUPLING-DRV,NUTS/BOLTS
555667646489Separator element
555767637561VALVE, CHECK LIQUID
555867633396VALVE-THERMOSTATIC 1X501
555967626028GAUGE-TEMPERATURE.1X4670
556067772608bolt
556167772616bolt
556267623223SCREW CAP M22X2. 5 x60 HEX
556367623165Bolt M8X40
556467620534CABLE-EXTENSION B/N 1X44
556567619288ELEMENT,OIL FILTER
556668197839Vibration probe
556768197268HEATER,OIL RESERVOIR
556868196898DRIVER,PUMP MOTOR
556968196872Oil pump coupling
557068196666HOSE-FLEX.1X37565
557168195056PUMP-OIL,WITHOUT DRIVER
557268188473SUPPRESSOR TVSS
557368157254KIT,THERMOSTATIC ELEMENT
557468155597VALVE-CONTROL-BYPASS.1X3
557568155423Vibration probe
557668155100PROBE-PROXIMITY B/N.1X36
557768153972Air compressor accessories
557868149145The valve core
557968119312GAUGE-PRESSURE 1X35246
558068103126Vibrating transmitter
558168095538Oil filter differential pressure switch
558268091099HOSE ASMBLY,DRY TECH
558367919712Double stud M16X260
558468088582Bypass valve 4″ 1X33458
558567587790Sealing gasket
558668039254The relief valve
558767598391CAP SCREW M10X1. 5 x55mm
558867587980bolt
558967597005bolt
559068019686Safety valve 200 PSIG
559168014919VALVE-THERMOSTATIC.1X302
559268014695VALVE-PRES RELIEF 1X3020
559368219880HOSE HYDRAULIC 3/4′”‘ TU
559468198589HOSE-1 FLEX – 31LG.1X232
559568198563HOSE HYDRAULIC 1 TUBE 40
559668198555HOSE HYDRAULIC 1′”‘ TUBE
559768181429hose
559868181411hose
559968179464THERMOSTAT,OIL HEATER
560068155274Elastic washer
560168093426Bolt M6x1 55 l
560268081587bolt
560368153543M6 * 40 bolt
560468013762PUMP OIL WITHOUT DRIVER
560568010545TOOL-5CII.1X21739
560668010537Seal gear 5CII-5CIIB
560767996892Right Angle connector
560867993808The differential gauge
560967994244VALVE, CONTROL-BYPASS
561067991497Lock washer
561168132026Bolt M10X70
561268153535Bolt M10X50
561367996181O ring 3 c / 5 ciib
561467987289The main oil pump
561567984435GAUGE, DP DWYER 0-20′”‘
561667979492Expansion joint
561767979500Intake expansion joint
5618679779754 “expansion joint
561967977553Exhaust expansion joint
562067969816The oil pump
562167988998diaphragm
562267958975Big gear shaft seal
562367951012Sealed big gear 3CI-4CI
562467945113Auxiliary oil pump motor
562567947853Big gear seal
562667940478Hose Assembly 1.0 X 20″
562767933382Type mechanism diaphragm
562867913798hose
562967917708Oil pressure drive valve
563067991133VALVE,REPAIR PARTS
563167917161Air filter
563267910331POSITIONER,REPAIR PARTS
563367906628Temperature sensor
563467675421Seal 1/2″
563567903849ROTOR-2AS3-325# 50HZ.1X1
563667924092tee
563767922211Directly to the head
563867904466Directly to the head
563967902940Temperature control valve
564067901009Direct head 1.25 X 1 STR
564167889634Resistance type temperature sensor
564267888016Temperature sensor
564367880559gasket
564467879163OIL-CV-O-5 GAL..  1X15023
564567876920Temperature control valve
564667865782VALVE-THERMOSTATIC 1X141
564767864090Pressure transmitter (air 0-500 psi)
564867516948Sliding bearing
564967856351Pressure transducer
565067535658The heater
565167843912Two-stage rotor assembly
565267843557ROTOR-CV2 33 S1 50HZ.1X1
565368192095bolt
565467822718The auxiliary oil pump
565567839639Level 3 rotor
565667532622PROBE
565767853036Heater tank
565867792119Main oil pump coupling
565967793315coupling
566067973552COUPLING-DRV LOVEJOY L-0
566167962480Auxiliary oil pump coupling
566268188937pin
566367975151pin
5664342980ROTOR,CH6 2CII 50HZ S1
566568185891pin
566615646433The check valve
566715646359Bypass valve 4″ ANSI 300#
566843187855The relief valve
566943031061By-pass valve 8″ ANSI 300# C
567043031046Inlet valve 20″ ANSI 150# C
567143030964Pneumatic drive valve
56724303094919 sp558 intake valve
567343030923Bypass valve
56744303090719 sp556 intake valve
567542980409Check valve DN150 PN10/16
567643063569POSITIONER.19SP419
567743038710Oil temperature control valve
567823442536IV 6
567923380116EL. / PNEUM. POSITIONER
568023109697TEMPERATURE CONTROL VALV
568122677082TEMP.CONTR.VALVE 2′”‘ANS
568217047598locator
568317044686CHECK VALVE
568416562191Bypass valve
568516562175Intake valve
568694742632VALVE RELIEF PSV 2-3
568794724119Bypass valve
568895465050Pipe joint
568967503052GASKET-GASKET-COOLER.187
569067503045GASKET,GASKET-COOLER
569195749222The retaining ring
569295738449Hole with ring
569395738431Hole with ring
569494864881Temperature control valve 2 “ANSI
569590217019The valve
569624054041Temperature converter
569722018287Secondary air filter element
569822018261First stage air filter element
569994720968Oil mist separator electrically driven
570094907748Check valve 10″ ANSI 300
570194907193Check valve 6″ 300LB H PED
570222715486coupling
570394941499Expansion joint 6″ ANSI300
570494573102Expansion joint DN200 PN25
570516558181Five stage air cooler
570695739397Flat washer
570795824686bolt
570895233326CAPSCREW,HEX SOC 1/4X2 S
570995067732bolt
571022786792Water flow switch
571143006998Condensing drain water collector
571242964379The steam trap
571323843675The oil level switch
571424479594Oil pump 399 LPM
571595005807Check valve 1.5″
571695005799Check valve 1.25″
571794575909Manual valve – OD6mm 1/8″
571890160433The relief valve
571990160227Pneumatic drive valve
572094941663VALVE-CHECK 1042SP
572194526225Check valve 10″ 150LB C PED
572290151176C.V.8IN ANSI 150LB C
572394524444Check valve 6″ 300LB C
572480280944Thrust block 4CI S5
572543119684Radial bearing 5CIIPI S2
572643119668Radial bearing 5CIIPI S1
572743118967Thrust bearing 3C S4
572843096510The check valve 2″
572980280498The check valve 3″
573080280480The check valve
573194810371Gasket cooler
573294810314Gasket cooler
573394810256Gasket cooler
573494822988Gasket cooler
573594811833Gasket cooler
573694817277o-rings
5737379081Shielded copper wire stranded
57383X4727-10Shielded copper wire stranded
5739379073Shielded copper wire stranded
574024776072Cooler SS C950S2
574168157056Third class plain bearing
574267988493Coupling motor end
574367970475Coupling host end
574467931584Auxiliary pump
574567618728Condensing discharge tray
5746676125231 SEC 2 nd nose
574767500090Condensing discharge tray
574824845547Rotor assembly, 3API S3 50Hz
574924473027Rotor assembly, 3API S2, 50HZ T
575022619498Rotor assembly STG. 13 CIIP
575167693911CV 1 st nose
575296740014bolt
575396703681Nut m2-m24
575468156751The gasket
575567626309Impeller washer 3CI
575667590158Gasket for 5 SEC
575767570325Rotor washer 1ACII
575868153105Steel bolt
5759678393812 nd nose
576067792515Rotor leading edge cone-2ACII -S3
576167782292Rotor leading edge cone 2ACII STG.2
576267695858Rotor leading edge cone 2ACII/C950
576367629089Nose end block impeller
576485564516Standard filter F71IH D
576567745588Gasket impeller 5CII
5766229412642CII 1ST impeller bolt
576768192921Rotor washer DCC STG.1
576867792507Rotor gasket 2AS3 LP 3X11670
5769SE003709Differential pressure transmitter Rosemont 3051
5770SE003694Pulse switch ZB2BZ101C
5771SE002929The handwheel M12
5772SE003682Pulse controller DMK-4CSA
5773SE003679The differential gauge 0-2000 pa
5774SE003673Coil 400325-642?  24VDC
5775SE002923E type seal ring φ 418
577668156736Gasket impeller
577767633479The impeller 3 aciis2 nose
577867687764Steel washer
577967544072Small centrifugal steel washer
578067762187Rotor washer 2ACis 1.3 x 11359
5781SE002926Solenoid valve 1.0 “, 24VCD
578222676977Diffuser C700 S1
578368014364Small centrifugal C400 dynamic balance bolt
578467917807Gasket cooler
5785SE003652Self-cleaning filter core (including 2 filter cartridges)
5786SE003643Self-cleaning filter core (including 2 filter cartridges)
5787SE003640Self-cleaning filter core
5788SE003637Self-cleaning filter core
5789SE003634Self-cleaning filter core (fast card type)
5790SE003631Self-cleaning filter core (fast card type)
5791SE003628Self-cleaning filter core (fast card type)
5792SE003625Self-cleaning filter core
5793SE003622Self-cleaning filter core
579424705485Self-cleaning filter core
5795SE003616Self-cleaning filter core
579622796684Rotor assembly STG.2 C700SV22
579795359691o-rings
579868192160Gas water separator CV2 STG1
579943069194Water gas separator
580096739891Bolt M20X60
580167758896Thrust ring CV2 ALL 3X11393
580267500793Siamese
580324873143Secondary air filter element replacement 67731158
580424873135Primary air filter element replace 67731166
5805237769742 PASS oil cooling
580622676720First stage diffuser
580768205723C950 secondary hot drain housing
580868205715C950 first stage hot exhaust housing
580967758730C950 secondary hot core tube
581067758698C950 first stage hot core tube
581122796841Rotor assembly, S/A C700 S2 50
581222795314Rotor assembly STG.1 CC700HV1
581322780613Diffuser C700 S3
581422779649Diffuser C700 S2
581522675904Diffuser C700 S1
581618990614Pipe assembly (up to 3ST water collector)
581723599004Coupling bushing
581823546757Coupling motor end
5819680989385/8 “nut – 11 unc’s BRASS
582067839472Three-stage impeller nose
582167768903C950 three stage hot core tube
5822SE003430Self-cleaning filter core φ 350*660
582323764210First stage tubesheet inlet C3000
582423764186First stage tubesheet exhaust end C3000
582522204820Tube plate exhaust end 3CI SS
582622204390Tube plate air inlet 3CI SS
582796716337Bolt M20X60
582867970327coupling
582995023156O-ring.101″WX 5.399″ I.D.
583095021747o-ring
583168092014Key.25 X.25 X.62″
583268091735Key.62 X.62 X 2.50″
583367970319coupling
583467909309Oil pump shell
583567764076Spacer ring oil pump CV2
583667763532Cycloid ring
58372472402312 “150 # flange
583867919654C950 water cooled oil cooler
5839247240496 “150 # flange
584018989343Motor 500 HP / 380 v / 50 / ODP
584168017961Impeller bolts, stage 3
584219066901Communication module PM-160
584394588456nut
584468017987Impeller bolts, Grade 1
584567829358Bolted rotor 1/2″-13UNC
584667589564Bolted rotor 1/2″-13UNC
584722532733Gear C950/2ACII STG. 350
584895008256o-rings
584967927830Retainer 3 ci
585024773418Coupling bolt
585167669150Gasket cooler
585268214592Tube plate exhaust end 5CII S1
585368214584Tubeplate inlet 5CII S1
585468214493Tube plate inlet 5CII S2
585568214485Tube plate exhaust end 5CII S2
585668214436Tubesheet intake end 5CII S3
585768214428Tube plate exhaust end 5CII S3
585867965699Impeller bolt 3CIib-S1
585923453624Bolt the impeller
586023453616Bolt the impeller
586123453608Bolt the impeller
586223829757Bypass valve
586367965707Dynamic balancing bolt
586468097799Low flow differential pressure switch
586567988980Intake valve leather bowl
586618991174Pipe assembly (oil cooler inlet)
586767707422Check valve
586847003348Standard maintenance component GC173
586968194133Central tube C250 S2
587024751901Temperature sensor dual support
587124739427Impeller 5CII stage 3
587224739419Impeller 5CII stage 2
587324739401Impeller 5CII stage 1
587424773442Motor bearing
587524773368Gasket for oil cooler
587624751737Self – operated pressure regulating valve
587795060125O-rings. 125. “”
587823431141Brazed plate oil cooler
587968026673Bolts -IMP 5/16 X 5.37
588095428124o-rings
588195022331O-ring 82.14×3.53 SAE AS
588296952064Gasket ANSI 16 “150 lb
588395786885O-rings ID47.0 X0.25 “”
588468147511Radial bearing 5CII S2 TPJ
588567956268Thrust bearing 5CII S1
588667945139Thrust bearing 5CII S2
588767906735Thrust bearing big gear 5CII/B
588867904664Big gear 5CII 50HZ
588967793224Thrust bearing 5CII S3
589067666388Radial bearing
589167662163Radial bearing 5CII S1 TPJ
589267649608Sealing oil 5CII S1
589367649590Seal gas 5CII S1
589467628883Sealing oil 5CII S2 S3
589567622555O-ring cooler ID45.5″
589667590968Thrust bearing big gear 5CII/B
589767590059O-ring cooler ID40.160″
589867589911Sealing gas 5CII S2 S3
589942974501Gasket 5CII class
590015654569o-rings
5901238169030-60 psid gauge
590223408982plunger
590324680936Motor rear bearing
590424680928Motor front bearing
590542919324Seal gasket M10
590646836045Cooler C400 S2
590768220805C350-s1 exhaust end tube plate
590868220797C350-s1 inlet end tube plate
590968216019C350-s3 exhaust end tube plate
591068216001C350-s3 inlet end tube plate
591168215631C350-s2 end tube plate 7X15318
591268215623C350-s2 inlet end tube plate
591367867135C980 three stage oil gas seal
591468107259C980 two-stage radial bearing
591568107242C980 three stage radial bearing
591668107234C980 grade radial bearing
591723268667C980 three stage thrust bearing
591823268659C980 first stage thrust bearing
591923268642C980 two stage thrust bearing
592023480692460/60 hz auxiliary oil pump
592168024017C980 first stage oil gas seal
592224680910Motor bearing 9-80
592324680902Motor bearing 9-90
592424667719Temperature sensor
592546846572Temperature controller oil heating
592668155092The probe
592767590182Air seal
592867590018Oil seal
592967580944Air seal
593067580936Air seal
593167580928Oil seal
593295051801gasket
593324684482Set the filter material
593467795211Driver oil pump motor
593522086169Tubesheet exhaust end stage 1
593622086136Tube plate air inlet stage 1
593795034559Internal connector.12 X2.50″
593824326720Temperature measuring element for motor bearing
593995603163o-rings
594095438909o-rings
594195295879o-rings
594267917146The pressure regulating valve
594367895466Fixed rod
594467755447Thrust bearing assembly
59452463794451 kw heater
59462463789427 kw heater
594724637662Muffler 3″
594824637597Check valve 6″
594967750745C950-s1 oil gas seal assembly
595067750703C950-s1 rear thrust bearing
5951400598C950-s1 front bearing assembly
595242964668Vibration probe RAM330
595324577298Pressure sensor 0-200psig
595442964684Vibrating cable RAM
5955SE002170Non-standard self-cleaning filter core φ 324
595624623795Self-cleaning filter core
595724623787Self cleaning strainer assembly
595824623761Self cleaning strainer assembly
595924623753Self cleaning strainer assembly
596024623746Self cleaning strainer assembly
596124623738Self cleaning strainer assembly
596224623720Self cleaning strainer assembly
596324623712Self cleaning strainer assembly
596424623704Self cleaning strainer assembly
596524623696Self cleaning strainer assembly
596624623688Self cleaning strainer assembly
596724623670Self cleaning strainer assembly
596822831788Vibrating transmitter
5969681943077 x15320 retainer
597024054025Temperature sensor
597124627200Two stage air filter core
597224627192First stage air filter core
597324008641Large centrifugal oil gas seal
597424597643Oil cooler
597522376602Tube plate exhaust end 4CI
597622376388Tube plate inlet 4CI
5977SE002098Water system rust and scale remover (Agent B)
5978SE002095Water system rust and scale remover (Agent A)
597924525115RTD 9S-80
598095937801Right Angle connector
598124017766Secondary cooler 5CII
598296738646gasket
598368157064Second stage plain bearing
598468105956Valve positioner
598567982413Plain bearing S3 3CII
598667796300Plain bearing S1 3CII
598767677674First stage thrust bearing
598895958450bolt
598996720446Nut M20
599095156386O-rings ID7.75″
599167757914Thrust bearing CV2
599268017946Bolted rotor 1/2″-13UNC
5993676451193CI impeller bolt
599468055128Radial bearing 4CI S4 TPJ N2
599567720367Oil level indicator
599623797327Integrated multi-machine controller
599767501247Thrust bearing 3CI-4CI
599822696827Vibration probe
599968005362Bolt rotor M20
600068055110Radial bearing
600168055102Radial bearing 4CI S2 TPJ N2
600268055094Radial bearing 4CI S4 TPJ N2
600367819466Cv0 dynamic balance bolt
600467750513Radial bearing 4CI S5 TPJ
600567662064Thrust bearing 3CI-4CI
600667589473Small centrifugal 2CII rear thrust bolts
600767522599Thrust bearing 4CI S1
600824471625PTFE high flow sterilizing filter element
600995058194O-rings 5.50 X. 137
601068157924Bolted impeller S1
601168157718Bolt, IMP – M12X110MM SOC
601296740964Bolt M5X35
601322532816Impeller MAX. DIA. 2ACII S3
601495656823o-rings
601595656336o-rings
601695603148o-rings
601795438990o-rings
601895135471O-ring 19.0 X19.38 X.188
601995041893o-rings
6020SE001453Dynamically balanced packing boxes
6021SE001450Dynamically balanced packing boxes
602295990396Lock washers
602395641734O-rings ID10.5 X0.188 “”
602495254173Flange 4 x150
602595106100Right Angle connector
602695067674Hexagon socket bolt
602795005815Check valve
602894949641GASKET KIT 5CII S3
602994925476Three stage back thrust seal gasket
603094899630Pneumatic drive valve
603194892809Switch valve
603294880887Locking gasket 8,4 SS
603394761467Oil cooler
603494679255Pneumatic actuator
603594590130Assemble vibration probe 5CII
603694589660Air compressor accessories
603794588837PIN DOWELL D40XL70
603894581600ELEMENT-FILTER.14SP009
603994562808The positioning pin
6040945454728″ GASKET ANSI 8″
604194532884The oil filter
604294524774PUMP – OIL. 2.503.178-3
604390171562joint
604485699916Ac motor (380
604585696771The oil filter
604685686988KIT-PARTS- OVHL- 2ACII
604785686939KIT-PARTS- OVHL- 2CV S3
604885686921KIT,PARTS, OVHL, 2CV S3
604985686905KIT-PARTS- OVHL- 1ACV
605085676807Vulcanized rubber block
605185651156Indicator light
605285651149Indicator light
6053856478736 “clamp seal ring
605485646354Indicator Pilot Light
605585644482GASKET, VICTAULIC 8 INCH
605685644474GASKET, VICTAULIC 10 INC
605785641751POWER SUPPLY,DC
605868249820O-rings ID781X6. 98
605968249812O-rings ID946X6. 98
606068249572Diffuser baffle ring
606168249556Thrust bearing C3000 S3
606268249523Thrust bearing C3000 S2
606368249366Thrust bearing C3000 S1
606468249317Thrust bearing
606568249309Thrust bearing
606668248269Bearing C3000 S3 TPJ
606768248244Bearing C3000 S2 TPJ
606868248137Bearing C3000 S1 TPJ
606968247105Big gear C3000 50HZ
607068244821Three stage diffuser
607168243757O-rings ID1056X6. 98
607268242502Thrust bearing 5CIIB A B C
607368224823Air cooler – cooling core
607468224781Air cooler – cooling core
607568224740AIR COOLER ASSY-C250 S1/
607668223445Two stage diffuser
607768219633Large gear bearing, motor side
607868217371Cover plate CV2
607968216316Sealed big gear C3000
608068214071Three stage diffuser
608168213537Oil pump shell
608268213180BEARING-THR-FIXED C250
608368213172BEARING-THR-FIXED C250
608468213164BEARING-TH-FIXED C250
608568211374Two stage diffuser
608668205731C950 three-stage heat discharge housing
608768204684Nose first stage
608868204635First stage diffuser
608968204619Drive gear
609068202977Bolt dynamic balance
609168202837DIFF-FM,C950 S3 2A3130,D
609268200807Dynamic balancing bolt
609368200799DIFF-FM,C950 2ND
609468200252SEPARATOR,MOIST DCC C350
609568199405Three-stage rear bearing
609668199397Double rear bearing
609768199389First stage back bearing
609868197680Nose second stage
609968197672Nose stage 3
610068195791Third stage thrust bearing
610168195783Second stage thrust bearing
610268195767Impeller bolts
610368195700COUPLING-DRV,HUB H2 FLEX
610468195692COUPLING-DRV,HUB H2 FLEX
610568193804Impeller bolts
610668192178Gas water separator CV2 STG2
610768192145SEPARATOR,MOIST DCC250 S
610868192137SEPARATOR,MOIST DCC250 S
610968187582DIFF-C950 S2 2API
611068187517Diffuser diversion jacket
611168187038Diffuser diversion jacket
611268185628Hot head secondary and tertiary connecting pipe
611368185305Hot head Second stage nose
611468185289Second stage nose
611568185248Third stage nose
611668185222Nose joint pipe
611768106319Air way check valve
611868074707BEARING-THASSY CV1B-S1
611968013788Oil pump bushing
612067904623Big gear
612167904441Right Angle connector
612267763136Large gear and shaft assembly CV2
612367704395Rotor 3 ci S5
612467676585Radial bearing 3C S4 TPJ
612567676577Radial bearing 3C S3 TPJ
612667676544Radial bearing 3C S2 TPJ
612767503425Thrust block
612854491386RING SCRAPPER 1.5-inch R
612954491378RING SCRAPPER 1.5-inch R
613043190644OIL COOLER
613143184795CONVERTER PT100/4-20MA
613243153105BODY VALVE 3 300LB'”‘
613343136894Bolt M8x50 SS
613443119163Gasket cooler
613543119148Gasket cooler
613643119122Gasket cooler
613743119106Gasket cooler
613843099209screw
613943098748Locking gasket A10,5 SS
614043098201Locking gasket A6 SS
614143069251liner
614243032861TRANSMITTER-VIBRATION.42
614343017086Elastic pin 6×50 SS
614442974543ROTOR 3CI 5TH STG
614542964080Vibration probe
614642935163GASKET KIT 5CII S2
614742695924The rotor
614842692731ROTOR- FR-III S3 50HZ
614942610790Rotor assembly C950 S3
6150426095522ACII three stage rotor assembly
6151426030432ACII primary rotor assembly
615242597062ROTOR 3CII STG.3 50HZ New
615342597054ROTOR- S/A 3CII S1 50HZ
615442590497Rotor assembly S/A 3CII S1 50H
615542590463Rotor assembly 3CII S1 50HZ
615642589838ROTOR- S/A 3API S2 50HZ
615742539924ROTOR C950 STG.2
615842533489ROTOR-S/A 2ACII S3 50HZ
615939592613VALVE DISCHARGE HCA
616038440962Ball valve
616137068293GASKET COVER CORK
616223677677The main oil pump C1000
616323666530Diffuser C3000 class 3
6164236642122ST.STAINLESS STEEL DIFF
616523456742Adjustable gap gasket group
616623449036Adjustable gap gasket group
616723447055Adjustable gap gasket group
616823446719Adjustable gap gasket group
616923441900Oil mist separator core
617023257827Main oil pump repair Kit (mechanical seal)
617123243769MAXI GASKET KIT
617223186679GASKET KIT 4C150 (1 TO 4
617323185671Oil mist separator
617423170798Bypass valve
617523145311Gasket package
6176231311702ND ROTOR ASSEMBLY C3000
617723081128150# large gear assembly
617823066905Oil pump bushing
617923064223Oil cooler
618023032972RTD KIT FOR MOTOR BRGS
618122980098VALVE- CONTROL-BYPASS
618222980080VALVE- CONTROL-INLET
618322968028Metal hose
618422873095Diffuser C700 S3
618522832422Diffuser C700 S3 110%
618622829220Diffuser C700 S2 107%
618722791438ROTORE 5CII 3ST LP
618822790265Rotor 5CII stage
618922773097Rotor assembly, S/A C700 S3 12
619022772669INLET VALVE
619122766182Metal hose
619222764500GASKET KIT 3CIIB STG.AB
619322757835MAIN OIL PUMP COUPLING
619422745103FLEXIBLE HOSE
619522744874FLEXIBLE HOSE 1′”‘ 1/4
619622709505Diffuser C3000 class 2
619722690739FILTER ELEMENT
619822677769Vibration of cable
619922658686Hose Assembly 1-7/16 X 23″
620022645642Gasket C1050-950 S1, S2
620122644454Second stage diffuser
620222631246SS diffuser S3
620322631188Diffuser S2
620422631162DIFFUSER- MACH C950 S2
620522627483Seal assembly
620622619449Rotor assembly 3API S1
620722616478Diffuser C700 S2
620822614614Spare gasket package 5CII
620922614556GASKET KIT 5CIIB 2ST
621022608731Rotor assembly 3API S2
621122608699Rotor assembly 3API S2
621222608152Impeller assembly STG-2 3CII
621322606644Rotor assembly C3000 class 3
621422606453Rotor assembly C3000 class 2
621522606222Rotor assembly C3000 class 1
621622591994The auxiliary oil pump
621722585343The main oil pump
621822573836Oil filter 3″
621922573828Oil filter 2″NPT
622022571095Oil filter core
622122545461COUPLING FOR POP
622222545370KIT OIL PUMP
622322516710Radial bearing seat
622422516702Radial bearing seat
622522516694Radial bearing seat
622622501399Gasket rotor 5CII stage 3
622722482483Hose MOP inlet pipe A10
622822470660Rotating shaft 5CIIB class b-c
622922464382OIL FILTER ELEMENT – RB
623022454573Gear coupling
623122408363GASKET KIT C3000 3ST.W/A
623222396154DIFF STG3 C3000
623322383327aftercooler
623422379242IMPELLER- 3API S3
623522377519Air compressor accessories – rotor
623622375851Connect the hose
6237223717773CI washer whole piece 3CI Maxi
623822369532COUPLING M.O.P
623922362461KIT MINI C3000 S3
624022362453KIT MINI C3000 S2
624122362446KIT MINI C3000 S1
624222362396PLAIN-BRG KIT C3000 S3
624322362388PLAIN-BRG KIT C3000 S2
624422362370PLAIN-BRG KIT C3000 S1
624522362362Seal C3000 S3
624622362354SEAL KIT C3000 S2
624722362347SEAL KIT C3000 S1
624822357859Air compressor accessories – diffuser
624922329254COUPLING P.O.P.
625022312920coupling
625122309736Water gas separator
625222309728Water gas separator
625322308720Radial bearing 5CII S1 N2
625422307847Radial bearing 5CII S2 N2
625522306898Radial bearing
625622291041Rotor assembly S4 4CI
625722289193Assembling vibration probe
625822289086Rotor assembly S5 4CI
625922289045Rotor assembly S3 4CI
626022267900GASKET KIT 2CII 3ST
626122219125Complete machine gasket
626222206460Double oil filter
626322162382O-ring cooler
626422162374O-ring cooler
626522162366O-ring cooler
626622162358O-ring cooler
626722162341O-ring cooler
626822162333O-ring cooler
626922086367Cooler gasket C3000
627022086102Water gas separator C3000 S1
627119055201Heater 2.1 kW440V60Hz
627216523987VIBRATION TRANSMITTER BE
627315641145Diffuser S2 3CII
627467563460Diffuser 3C S2
627523309586OIL COOLER
627624145880Muffler RSXSQ – I
627724145666Diffuser RSKS – DN100A
627824145641Diffuser RSKS – DN200
6279959534850.44 * 1.5 nut
628095703070O-rings ID16.5 X0.25 “”
628195675443Hole with ring
628295603155o-ring
628395333423Pipe joint. 75″
628495160115O-ring 14 X17.38 X.18
628595135489o-rings
62869504197620 a11em277 o-rings
628795041463O-rings ID11.5 X0.25 “”
628895024139o-ring
628995023420o-ring
629095000089o-rings
629190145111gasket
629285643682Motor bearing
629385641678Motor bearing
629468212117Oil mist separator core
629568210624Cooler C950
629668210418PAS dynamic balance bolt
629768208545PAS dynamic balance bolt
629868208537PAS dynamic balance bolt
629968207315Impeller gasket
630068199421Siamese
630168194588PAS dynamic balance bolt
6302681941177 x15328 retainer
630368194059retainer
630468193093gasket
630568172014Bypass control valve
630668167188Bolt impeller S3
630768165513Cooler C950
630868165505Cooler C950
630968158617Check valve (grade 3 outlet)
631068157957PAS dynamic balance bolt
631168156199Bolt -IMP-SOC M18X165MM 3
631268156181Bolt the impeller
631368153824Gasket heater
631468152842Oil filter core
631568147883Gasket preheat oil pump
631668147305Bolt rotor M20
63176814049055 gallons of centrifuge coolant
631868122001Plain bearing S1 N2
631968121995Plain bearing S3 N2
632068121987Plain bearing S2 N2
632168117613Thrust bearing
632268112051Temperature control valve
632368105964Intake valve
632468104868Pressure transmitter
632568088558Resistance type temperature sensor
632668088095Resistance type temperature sensor
632768066711Adjustable gap gasket
6328680639731291004-001 Bolt, IMP-SOC M10X115MM
632968052695Oil filter
633068049154Bolt, M10X108
633168024363Bolt rotor M20
633268022573PAS dynamic balance bolt
633368019223Bolted rotor 1/2″-13UNC
633468017979PAS dynamic balance bolt
633568017953PAS dynamic balance bolt
633668013150Bolt,IMP 2A S3 1/2
633768013051Large centrifugal 3C/4C PAS dynamic balance
633868012343PAS dynamic balance bolt
633968012269Bolt the impeller
634068011717Bolts 3 aciis3
634168011709PAS dynamic balance bolt
634268011691PAS dynamic balance bolt
634368010941Bolt, IMP – 12 x150mm SOC
634468010933PAS dynamic balance bolt
634568009778PAS dynamic balance bolt
634668005172Bolt rotor M20
634767999896PAS dynamic balance bolt
634867970368Motor side coupling
634967969824coupling
635067964270Bolt rotor M20
635167955146Bolts,ROTOR 1ACII S
635267939603Big gear shaft seal
635367931212Big gear shaft seal
635467928739Retainer 4 c
635567927657Cooler shield
635667927368Three-stage rotor assembly
635767919662Oil cooler
635867909341Three-stage plain bearing
635967909333Two-stage plain bearing
636067909325First order plain bearing
636167909192The primary shaft seal
636267909184Secondary seal
636367909176Triple seal
636467908558Seal stud
636567902973The oil filter
636667902965Oil filter core
636767893040Oil cooler water cooled
636867875146Corrugated hose
636967861500Sealing stud.38″
637067847384nut
637167844290Large centrifugal 4C2 PAS dynamic balancing screw
637267839431Rotor washer CV2 S1
637367838599Class 3 rear bearing
637467829564Bolted rotor 1/2″-13UNC
637567829325Seal STG3
637667829309seal
637767819474PAS dynamic balance bolt
637867819250Nut NPT2
637967813220Gasket components
638067800920Nut M10
638167792499Bolt -IMP SOC 3/8 X 3.75
638267765453Table of the differential
638367765362Intake air filter core
638467758904Bolt, THRUST CV2 M8x1.25
638567758631Thrust bearing CV2 new :00416800
638667754101Empty filter
638767739524Clip 2″
638867739276Gasket 2″
638967739250Shim 4″
639067739227Gasket 8.0″
639167732826Big gear bearing
639267731364Gaskets gasket
639367731166Air filter replacement :24873135
639467731158Air filter replacement :24873143
639567707380Exhaust valve
639667690057gasket
639767687798Bolt, THRUST 2 acii
639867682732First class shaft seal kit
639967661959Bolted rotor 3/4″-16 UNf
640067653063Class 2 front bearing
640167647636Sliding bearing
640267647107Bolted rotor 1/2″-13UNC
640367647099Bolt the rotor
640467647073Bolt rotor M20
640567645085PAS dynamic balance bolt
640667645051PAS dynamic balance bolt
640767632463Impeller gasket 3ACIIS2
640867590083Gasket impeller 5CII
640967581256Gasket – Waffle
641067580910Oil seal
641167570713Service seal assembly
641267550921Gasket nestle
641367545673Big gear bearing
641467543801Class 2 rear bearing
641567543793Class 1 rear bearing
641667541383BEARING,REVERSE THRUST 3
641767531061PAS dynamic balance bolt
641867514117Secondary shaft seal kit
641967508234Gasket cooler
642067500181Table temperature
642146869731Sealing kit C1000
642243083427Oil mist filter core
642343083401Oil mist separator core
642443063486thermocouple
64253845959020 liters of centrifuge coolant
642624189508Motor ointment NLGI 2
642724036352Flat-bottomed taper filter 24″
642824036345Flat-bottomed taper filter 20″
642924036337Flat bottom tapered filter 18″
643024036329Flat bottom taper filter 16″
643124036311Flat-bottomed taper filter 14″
643224036303Flat bottom tapered filter 12″
643324036295Flat bottom tapered filter 8″
643424036287Flat bottom tapered filter 6″
643524036212Inlet cone filter for trial run
643624019978gasket
643723948409Cooler core group 2S C1000
643823947666Time relay
643923947609Circuit breaker 2P 16A
644023940919Cooler core group 1S C1000
644123909948joint
644223909930tube
644323758964Temperature control valve
644423605397Heater 380 V
644523586431First stage thrust bearing option
644623533532Control module FMM
644723533524Display module DCU
644823500275Vibration probe
644923500259Vibration probe
645023500242Vibration probe
645123485543Check valve
645223483456Three-stage radial bearing
645323483449Two-stage radial bearing
645423483431First grade radial bearing
645523441892Oil mist separator assembly
645623426711Temperature control valve seal
645723412935Intake valve
645823393994Thrust bearing
645923367535Oil and gas sealing
646023367469Oil and gas sealing
646123148356Large gear thrust bearing
646223067184The main oil pump
646322738751Vibration probe
646422683569Vibration of cable
646522682868Vibration sensor
646622677777Vibration sensor SEC
646722677751The vibration probe
646822676886diffuser
646922663819Flow down the plate
647022658835Diffuser C700 S3 65%
647122488167Gasket tank cover
647222419394Spare gasket package S5
647322419386Spare gasket package S1-S4
647422300149Complete set of gaskets
647522123566PAS dynamic balance bolt
647619030253Tank heater 4.0kW
647719030246Tank heater 2.1kW
6478190194130-160 psi pressure gauges
64791901243424V DC power supply 100W
648015654627Oil filter core
648115654544Oil filter core
6482329771gasket
648368026681Bolt – 5/16 x4 SOC. 12.3 X126
648418998146Seal the air pressure gauge head
648518998120Sealed air pressure switch 6psig
648618997858Selection switch 110V
648718997791Intermediate relay seat
648818997783Overcurrent protector 2.8-4A
648918997775Ac contactor 16A
649067730671Temperature sensor
649118998443Grating window with fan NEMA12
649296950696gasket
649396745864Hexagon socket round head bolt M10
649496742721Double end stud M24X3X80
649596740915M20 bolts * 90
649696735238Inner hexagon stud M10
649796719745Flat gasket M8
649895994018bolt
649995980835Pin 3/16 “X2”
650095973434Flange clamp hoop
650195853602Hexagon socket bolt 5/16″
650295796371Hexagon socket bolt 5/16″
650395758751O-rings 6 x6. 38 x0. 188
650495720280o-rings
650595631610Locking gasket 5/16″
650695531240The internal and external screw
650795529210O-rings. 062 “W
650895452017Double threaded pipe couplings.25″
650995337127Motor steering plate
651095272761joint
651195232419Inner hexagon stud.38
651295025409o-rings
651395023115o-rings
651494824612Cooling water inlet pipe
651590180720Gasket 3.0″
651690171711Gasket 2.0″
651780280159Starting from the secondary
651880277726Secondary head C400 60Hz
651980277718The nose level
652068231307Rotor assembly C400 S1 50HZ 91%
652168166859Control valve
652268136241Diffuser S1
652368109958Thrust bearing stage 2
652468109909Diffuser stage
652568106814IGV intake valve C400
652668102730Diffuser stage C400
652768090844Thailand SCG CV1 first stage diffuser
652868077403Bearing gear
652968047976diffuser
653068031699Sealing ring
653168013879Coupling guard
653267970301Coupling compressor end
653367906230Main oil pump housing
653467902650Hose.75″ X 49.0″
653567902502Elbow 1.0″
653667893032Oil cooler
653767890368Main oil pump housing C400 60Hz
653867791921Rod C400
653967789891Large gear lock tabs
654067777524Retainer C400 S2
654167777425Retainer C400 S1
654267764340Tank heater
654367755421Big gear 50 hz
654467748285Big gear C400 60Hz
654567748251Water gas separator level 1
654667748244Water gas separator stage ii
654767745430No rear cooling head class ii
654867726109Intake filter
654967709881Pin 0.18 X1.25
655067696302Thrust bearing stage
655167693804CV1 bypass valve muffler
655267653493Reducing over
655367643577Plain bearing stage
655467570069Bushing main oil pump
655567569798Waffle gasket S1
655667568261No motor for main oil pump
655767561167The flange
655867544049Main oil pump C400 60Hz
655967500827Directly to the head
656067500785Condensing discharge tray
656146846044Elbow 0.12 “SS
656246845996tee
656346845988cross
656446843934Adjust the gasket
656546831178Motor standard 450HP
656646830451Packing wooden case cover
656743055623Cooling water outlet pipe
656843030667Intake valve
656943007020Exhaust check valve
657042644476Rotor assembly CV1B S2 60HZ 95
657135815802Door warning decal
657223763048Fumigation in intake filter packing boxes
657323763030Muffler packing box fumigation
657423763022Fumigation in bulk packing boxes
657523763014Machine package wooden case fumigation
657623568447Cable USB 2 meters long
657723557192Gearbox C400 50HZ
657823486533Diffuser stage
657923486491Diffuser S2
658023486475Diffuser S2
658123480882Rotor assembly S/A CV1B S1
658223441934Plain bearing stage 2
658322388151Rotor assembly S/A CV1B S2 50H
658422388136Rotor assembly S/A CV1B S2 50H
658522388110Rotor assembly S/A CV1B S2 50H
658622373864Rotor assembly CV1B S1 50HZ 22
658722203434Flange 6″150# DIN DN150
658822203418Flange 4 “150 # DIN DN100
658922203400150 # (DIN flanges 2.0″
659019055649Cooler gasket I
659119030238Tank heater 2.1kW
659218998138Pressure regulator
659318997874Indicator light yellow 110V
659418997866Indicator light red 110V
659518997841Emergency stop button 110V
6596428219Rotor assembly C400 S1 50HZ 210
6597427740Rotor assembly C400 S1 60HZ 170
6598423871Rotor assembly C400 S1 50HZ 200
659967570051Big gear seal
660022229702Refrigerating compressor
660146848446Gasket kits C400
660219002153CV1 Auxiliary oil pump (blue)
660319001932CV1 auxiliary oil pump motor
660496745385Double end stud M16X 2 X 90
660596741699Double end stud M16X 2 X 100
660696741202Hexagon countersunk head bolts M10X35
660796739883Hexagon countersunk head bolts M20X 70MM
660896704663Gasket M6 X18MM
660996704309Bolt M10 * 35
661095992392Plug. 50 “NPT
661195929782nut
661295899175Pipe joint
661395869806Round head drive screw
661495857520Spring pin 3/32 X 1/4
661595670725T connector.75″
661695439006O-ring 17 X 17.38 X.18
661795438917O-ring 15 X15.38 X.188
661895373775Woodruff key
661995333282Hexagon thread bush 1.50″
662095333209Catheter. 50. “”
662195326039bearing
662295269320O-ring 13 X13.38 X.188
662395256913Right Angle joint 1/8×1/8
662495223038Hole with ring
662595223012Hole with ring
662695156402O-ring 11.5 X11.87 X.18
662795148599Pipe joint
662895101150Direct head.75x.75″
662995058053O-ring 5 X 5.25 X.12
663095026977O-ring 5.25 X 5.62 X.18
663195026860O-ring 3.88 X4.25 X.188
663295026845O-ring 3.62 X4.0 X.188
663395023149O-ring fluororubber 5.25X.44 X
663495022364O-ring fluororubber
663595005781Check valve
663694932357Radial bearings for large gears
663794932290Large gear thrust bearing
663894589488M16 X 70MM
6639922814273.5 MMX200MM TIE WRAP
664090171695The flange gasket
664185668366Contactor normally closed Ui690V/10A
664285668333Emergency stop button 110V
66438566818424V DC power supply 100W
664485668101Circuit breaker 2P 6A
664585668085Circuit breaker 1P 10A
664685650950Disturbance suppressor 10A 120V
664785647600Relay 2 110V coil package
664885645455Pressure regulator
664968241736Relay mounting base frame
665068188978Hexagon countersunk head bolts M10 X 25
665168187434Manual valve
665268173947The auxiliary oil pump
665368144013hose
665468142462Vibration sensor 0-4mils
665568135052Vibration probe
665668135045cable
665768132653Retainer CV1S2 STD
665868109354Directly to the head
665968095488Resistance type temperature sensor
666068093251Wiring duct – 8 ft
666168087675Pressure transducer
666268087485Resistance type temperature sensor
666368054469Temperature control valve
666468047919diffuser
666568009786Rotor stud
666668009760Rotor bolt
666768007277Pressure switch action setting 6PSIG
666867992834Liquid level indicator
666967991505Lock washer
667067932517Large gear shaft seal
667167919167sloper
667267902635Right Angle connector
667367889642Check valve
667467889626Lubricating oil filter
667567889618hose
667667889592hose
667767889576hose
667867889550hose
667967889519Directly to the head
668067889477Directly to the head
668167880070Right Angle connector
668267878785Plug 1.125″
668367878777Plug. 75. “”
668467878769plug
668567877050Oil cooler
668667876912The relief valve
668767869990Temperature sensor
668867829895Pressure sensor 0-200psig
668967829887Pressure sensor 0-50psig
669067820910Quick insert right Angle coupling.25″ X.25″
669167793190Oil filter
669267773499Oil filter core
669367765370pin
669467761221Gasket waffle CV1
669567754259Rotor washer CV1 S2.3×11332
669667752568pin
669767748616Radial bearing
669867748475Adapter (probe)
669967744656Non-asbestos gasket 2″
670067742825Thrust bearing
670167739235gasket
670267735761shim
670367730721seal
670467730143Quick insert direct head 1/4″ X1/8″
670567729707Quick insert direct head 1/4″ X1/4″
670667729699Quick insert direct head 1/2″ X1/2″
670767729665Quick plug T connector 1/2″
670867729657Quick insert reducer 1/4″ X1/2″
670967727750The nylon pipe 1/2″
671067727743Nylon tube 1/4″
671167719583Graphite seal ring
671267649368Stud seal.25″
671367643585Bushing seal assembly 1.25
671467642835seal
671567638932Bearing flange gasket
671667638155button
671767584920Bolt, THRUST
671867561001The flange
671967544064The nozzle
672067541011The wire
672167516963conductor
672267516112Manual valve
672367502914button
672454364096Pressure transducer
672543030642Bypass valve
672643030626Intake valve
672739571310The thermal resistance
672839185038Screw warning board
672939140785Rubber plug. 50
673038446076Insulated housing ENL 6HP
673138441192High liquid level alarm assembly (6.89 BAR)
673236854925bearing
673322516017Condensing filter
673418997916Disturbance suppressor 10A 250V

Related Products

Get In Touch With SMK

Contact Form Demo (#3)
